Multi-application - LiFePO4 Power
UE-12Li10
Issued Date
Issued Version
1. General Information
This specification defines the performance of rechargeable LiFePO4 battery pack
MASTER BATTERY, S.L., describes the type, performance, technical characteristics, warning and caution of the
battery pack.
2. Specification
NO.
Items
Normal Specification
1
Nominal Voltage
2
Normal Capacity
3
Internal Resistance
Standard Charge
4
Battery operation temperature range @charging
5
Normal charge voltage
Recommended float charge voltage
6
(for Standby use)
7
Allowed MAX constant charge current
8
Recommended charge current
>
2016-06-03
>
V00
Polígono industrial La Dehesa
C/ Dehesa Vieja,nº2 Nave 16
28052 Madrid (Spain)
Tel. (+34) 918 021 649
Fax. (+34) 917 750 542
info@masterbattery.es
LITHIUM IRON PHOSPHATE BATTERY
UE-12Li10
Description
12.8V
10Ah
≤60mΩ
0~45°C
14.6±0.2V
13.8±0.2V
10A @ Battery initial Temp 25±5°C
≤6A
www.masterbattery.es
manufactured by
01
Advertisement
Table of Contents
Related Manuals for Master Battery UPOWER Ecoline UE Series
Summary of Contents for Master Battery UPOWER Ecoline UE Series
- Page 1 Issued Version > 1. General Information This specification defines the performance of rechargeable LiFePO4 battery pack manufactured by UE-12Li10 MASTER BATTERY, S.L., describes the type, performance, technical characteristics, warning and caution of the battery pack. 2. Specification Items Description Normal Specification Nominal Voltage 12.8V...
- Page 2 UE-12Li10 www.masterbattery.es Items Description Standard Discharge Battery operation temperature range -20~60°C @discharging Output Voltage Range 10~14.6V Allowed discharge current 10A @Battery initial Temp 25±5°C Peak discharge current undertake 22A/20s Discharge Cut-off voltage Mechanical Characteristics Length: Max 135.0mm Dimension Width: Max 40.0mm Height: Max 140.0mm Weight About: 1.3Kg...
- Page 3 UE-12Li10 www.masterbattery.es 3. Electrical Characteristics & Test Condition Testing Conditions: Ambient Temperature: 25±5ºC; Huminity: 45%~75%. Items Criterion Condition Test the internal resistance of 50% SOC battery pack Internal Impedance ≤60mΩ with 1 kHz AC internal resistance test instrument. Rest for 1 hour after fully charged, then discharge with 0.33C current until the battery reaches the discharge cutoff voltage.
- Page 4 UE-12Li10 www.masterbattery.es 4. Dimensional Drawing Note: PH2.0-5P white ribbon cable leakage length to 100±5 mm. XT60 banana plug exposed by the terminal for actual length shall prevail 5. Storage & Transportation • Based on the character of cell, proper environment for transportation of LiFePO4 battery pack need to be created to protect the battery.
- Page 5 Please read and follow the specification and caution remarks on battery surface before use the battery. Improper use may cause heat, fire, rupture, damage or capacity deterioration of the battery. MASTER BATTERY, S.L. Describes is not responsible for any accidents caused by the usage without following our specification.
