BYPASS FOOTSWITCH

Press the BYPASS Footswitch to toggle the C9 between buffered Bypass and Effect
mode. The status LED lights when in Effect mode.

DRY OUTPUT JACK

DRY outputs the signal present at the INPUT Jack through a buffer circuit. The dry
signal is outputted regardless if the C9 is in Effect or Bypass mode. The DRY Volume
knob does not change the volume at the DRY Output jack.
ORGAN OUTPUT JACK
ORGAN outputs the mix set by the DRY and ORGAN controls.

PRESET DESCRIPTIONS

1. Tone Wheel - Classic tone wheel-esque organ sound.
CLICK sets level of click sound.
2. Prog – Paying homage to the massive sound of Keith Emerson of Emerson
Lake and Palmer. MOD type:
intervals: a fifth above and an octave below.
3. Compact - This preset imitates a sound similar to Ray Manzarek's tone on
the Door's "Light My Fire." MOD type: Vibrato.
upper harmonics.
4. Shimmer - This preset is based on an effect made popular by Brain Eno
and Daniel Lanois. MOD adjusts the attack time. CLICK controls the sustain
amount.
5. Lord Purple – Our salute to the Jon Lord-ish type organ sound of Deep
Purple. The ORGAN level controls the level of one set of 3 drawbars.
Type: Chorus. CLICK adjusts the level of a second set of 3 drawbars.
6. Mello Flutes – A tribute to the classic Mellotron flute tape sound of The
Beatles' song "Strawberry Fields Forever."
adjusts the depth of the vibrato.
7. Blimp - Led Zeppelin type sound
level of upper harmonics.
8. Press Tone – EHX's nod to the great organ sound found on The Beatles'
MOD type: Chorus.
song "Let It Be."
9. Telstar - Envisions the legendary sound of a Clavioline as used on The
MOD Type: Vibrato.
Tornadoes song "Telstar."
upper harmonics.
Note: On presets 2, 3, 5 and 7; the CLICK knob is a volume control that works
independently of the main ORGAN volume knob.

NOTES AND SPECIFICATIONS

•
C9 has buffered bypass.
•
Input impedance is 1MΩ.
•
Output impedance for both output jacks is 500Ω.
•
Current draw of the C9 is 100mA.
MOD type: Chorus.
Chorus. CLICK adjusts the level of two
CLICK adjusts the level of
MOD
MOD Type: Vibrato. CLICK
. MOD Type: Chorus. CLICK adjusts the
CLICK sets level of click sound.
CLICK adjusts the level of
