HWC - SERIES
4
Door Sold
Seperately
3
Item
Number
1
HWC - REAR MOUNT ASSY
2
HWC - CENTRE SECTION
3
HWC RAIL - TAPPED
4
HWC - WINDOW DOOR ASSY
2
Title
INSTRUCTIONS FOR
Quantity
1
1
2
visit our website:
1
visitez notre site Web:
HWC
1
www.hammondmfg.com
BUL87423
C
REV.
PAGE
1
OF
9
Advertisement
Related Manuals for Hammond Manufacturing HWC Series
Summary of Contents for Hammond Manufacturing HWC Series
- Page 1 BUL87423 INSTRUCTIONS FOR HWC - SERIES REV. PAGE Door Sold Seperately Item Title Quantity Number HWC - REAR MOUNT ASSY HWC - CENTRE SECTION HWC RAIL - TAPPED visit our website: www.hammondmfg.com HWC - WINDOW DOOR ASSY visitez notre site Web:...
-
Page 2: Important Safety Cautions
BUL87423 INSTRUCTIONS FOR HWC - SERIES REV. PAGE IMPORTANT SAFETY CAUTIONS NOTE : Read all instructions before installing and using the product. Installation and assembly must be performed by qualified personnel. Ensure that the floor/wall structure is able to withstand the weight of the cabinet while fully loaded. -
Page 3: Wall Mount Instructions
BUL87423 INSTRUCTIONS FOR HWC - SERIES REV. PAGE WALLMOUNT INSTRUCTIONS OPTIONAL : Remove front section of wallmount to allow for an easier install. ENSURE NYLON STRIP IS AT BOTTOM TOOL BOX LEVEL NIVEA U visit our website: www.hammondmfg.com visitez notre site Web:... - Page 4 BUL87423 INSTRUCTIONS FOR HWC - SERIES REV. PAGE OF 9 LEVEL NIVEAU 16" TEMPLATE / MODÈLE ENGLISH Different wall materials require different types of screws. Mount back pan using 3/8" dia lag bolts and standard flat washers. FRANÇAIS Les différents matériaux de paroi murale nécessitent différents types de vis.
- Page 5 BUL87423 INSTRUCTIONS FOR HWC - SERIES REV. PAGE OF 9...
- Page 6 BUL87423 INSTRUCTIONS FOR HWC - SERIES REV. PAGE OF 9 REVERSE MIDDLE SECTION INSTRUCTIONS...
- Page 7 BUL87423 INSTRUCTIONS FOR HWC - SERIES REV. PAGE OF 9 GROUNDING AND BONDING INSTRUCTIONS Included within optional grounding kit (GRDKIT01): 4 x 1/4-20 4 x 1/4-20 4 x 10-32 4 x 1/4" 4 x 10-32 4 x #10 Locking Nut Slotted Screw Flat Washer Phillips Screw...
- Page 8 BUL87423 INSTRUCTIONS FOR HWC - SERIES REV. PAGE OF 9 Bonding Connection Main Protective Grounding When grounding the rack system or enclosure it is essential that the main protective ground is connected and secured first with its own nut before any bonding connections are made on top.
- Page 9 BUL87423 INSTRUCTIONS FOR HWC - SERIES REV. PAGE OF 9 KNOCK-OUTS AND CABLE WAYS • Knock-outs are located on the top/bottom and sides of the rear section. • The openings allow for cable entry, mounting of conduits, and fan mounting. 3", 2", 1.38", and 1.12"...
