ECLIPSE SERIES
O 0.281
7.14mm
CENTER HOLES
REQUIRED WHEN
ENCLOSURE HEIGHT
GREATER THAN 42"
0.994
25.25mm
MINIMUM
TOOL BOX
3/8,7/16" Socket
Wrench
PART #
QTY.
1
1
2
1
VERTICAL RAIL LOCK SIDE
3
1
VERTICAL RAL HINGE SIDE
4
4 OR 6
5
2, 3 OR
6
4 OR 6
7
4 OR 6
8
8 OR
1/4-20 BUTTON HEAD SCREW
9
8 OR
1/4-20 SEALING WASHER
10
8 OR
11
1
12
2, 3 OR
13
2
2.000
50.8mm
L
C
2.000
50.8mm
4.370
111mm
FIG. 1
Centre
3/8 or 7/16
Drill, use
Punch
Open
.281(7.1mm) BIT
Wrench
ASSEMBLY INSTRUCTIONS FOR
SWING PANEL & SWING FRAME
DESCRIPTION
SWING PANEL/FRAME
C-CHANNEL
HINGE PIN
1/4-20 SCREW
1/4-20 C-CHANNEL NUT
1/4-20 KEP NUT
FINGER PULL
HINGE PIN CAP
1/4 TURN LATCH
1) DRILL HOLES IN ENCLOSURE FOR FIELD INSTALLED KITS (FIG. 1)
a) MARK AND DRILL 0.281" (7.1mm) DIA HOLES 4 or 6 PLACES
BOTH SIDES
Hammer
5/32 ALLEN KEY
PAGE 1 OF 3
BUL10120
REV. F
HAMMOND
MANUFACTURING
ENCLOSURES
TM
Advertisement
Related Manuals for Hammond Manufacturing ECLIPSE Series
Summary of Contents for Hammond Manufacturing ECLIPSE Series
- Page 1 BUL10120 ECLIPSE SERIES ASSEMBLY INSTRUCTIONS FOR SWING PANEL & SWING FRAME REV. F PART # QTY. DESCRIPTION SWING PANEL/FRAME VERTICAL RAIL LOCK SIDE VERTICAL RAL HINGE SIDE 4 OR 6 C-CHANNEL 2, 3 OR HINGE PIN 4 OR 6 1/4-20 SCREW...
- Page 2 BUL10120 ECLIPSE SERIES ASSEMBLY INSTRUCTIONS FOR SWING PANEL & SWING FRAME REV. F 2) MOUNT C-CHANNELS (FIG. 2): a) PLACE 1/4-20 BUTTON HEAD SCREWS THROUGH SEALING WASHERS THEN THROUGH HOLES IN ENCLOSURE WITH RUBBER SIDE FACING ENCLOSURE. b) INSTALL C-CHANNEL ONTO 1/4-20 SCREWS c) INSTALL 1/4-20 NUTS ONTO 1/4-20 SCREWS FIG.
- Page 3 BUL10120 ECLIPSE SERIES ASSEMBLY INSTRUCTIONS FOR SWING PANEL & SWING FRAME REV. F 4) MOUNT SWING PANEL / FRAME TO HINGE VERTICAL RAIL (FIG. 4) a) PLACE SWING PANEL / FRAME HINGE BARRELS BETWEEN VERTICAL RAIL HINGE. b) INSERT PINS THROUGH HINGE AND BARREL.
