- Page 1 Instruction manual Negative pressure unit D 610 in ex-protection design Manufacturer: deconta GmbH Im Geer 20, 46419 Isselburg Description / Type-No.: Negative pressure unit D 610 in ex-protection design Typ 418 Serial-No.: ....
-
Page 2: Table Of Contents
Instruction manual Negative Pressure Unit D 610 EX Table of contents on page Introduction Basic safety advice Transport und storage Delivery Transport Storage Volume of delivery at purchase and rent Volume of delivery Return delivery after renting Technical description Intended use Unit description 5.2.1... -
Page 3: Introduction
• Pleasing design • Command with technical „acuteness“ With products of deconta you are sure to be one step ahead of your competitors. As a result of our experiences in the asbestos removal industry our equipment technology is designed according to current safety standards TRGS 519. -
Page 4: Basic Safety Advice
Negative Pressure Unit D 610 EX 2 Basic safety advice As an operator, you are obliged by deconta to follow the instruction manual and to use this engineered technology equipment only in accordance with the regulations and its suitability! In the event of non-observance, deconta assumes no liability. -
Page 5: Transport Und Storage
Instruction manual Negative Pressure Unit D 610 EX 3 Transport and storage 3.1 Delivery In order to protect the device against climatic influences it is wrapped with a plastic film. Transport damages have to be documented at once during the handing over of the carrier or another supplier. -
Page 6: Return Delivery After Renting
Instruction manual Negative Pressure Unit D 610 EX 4.2 Return delivery after renting For the protection of our clients and in accordance with the rules for hazmat transport, we must insist on the following return delivery conditions: • cleaned thoroughly (ready for use) •... -
Page 7: Unit Description
Instruction manual Negative Pressure Unit D 610 EX 5.2 Description D 610 The negative pressure unit D610 features powder-coated housing made of hard aluminium, in which an electric fan, a main filter, an intermediate filter and a pre filter find a place. -
Page 8: Control On/Off
Instruction manual Negative Pressure Unit D 610 EX 5.2.1 Control ON / OFF The Unit D610 is delivered in series with an ON / OFF control for the power regulation. Seite 8... -
Page 9: Filter Description / Classification
Instruction manual Negative Pressure Unit D 610 EX 5.3 Filter description / classification Integrated in the unit is a 3-step filtering combination. In particular: Pre and intermediate filter Pre-filter Intermediate filter Filter class pursuant DIN 24185 / EN 779 G3 / EU3... -
Page 10: Filter Change
Instruction manual Negative Pressure Unit D 610 EX 5.4 Filter change The frequency of the change of filter depends on the degree of pollution of the filter. If the sealing up of the filter increases (contamination of the filter), the air capacity decreases. -
Page 11: Technical Data
Instruction manual Negative Pressure Unit D 610 EX 6 Technical Data 6.1 Fan characteristic curve Technical Data: Voltage: 400 V Frequency: 50 Hz Air discharge: 6000 m³/h free exhaust Speed: 2800 U/min max. discharge temperature: 45°C Seite 11... -
Page 12: Performance Data
Instruction manual Negative Pressure Unit D 610 EX 6.2 Performance data Air performance free-blowing 6.000 m³/h Air performance with 1x S-filter 4.500 m³/h Air performance with 2x S-filter 4.000 m³/h Power connection 230 Volt, 50 Hz Power consumption 16 Ampere... -
Page 13: Power Loss In Hose Lines
Instruction manual Negative Pressure Unit D 610 EX 6.4 Power loss in hose lines Following factors have adverse influence: • Hose lines too long • Bends and bows in the hose lines • Cross-section narrowing of the hose lines. 6.5 Resistance diagram for hose lines •... -
Page 14: Assembly Instructions
Instruction manual Negative Pressure Unit D 610 EX 7 Assembly instructions The negative pressure unit is delivered ex-works and ready for immediate operation. If there are visible damages, do not operate the device. Please contact the deconta GmbH at once. -
Page 15: Assembly Of Optional Attachment Housing
Instruction manual Negative Pressure Unit D 610 EX 7.2 Assembly of the optional attachment housing (SNAP) Optionally for a second Hepa filter (Double filtration), additional activated carbon filter or pocket filter • Dismount the pre filter and unscrew the safety corners Safety corner •... -
Page 16: Initial Operation
„Schleifgeräusche“ am Lüfter untersuchen. Sollten Sie diese feststellen, darf das Gerät nicht in Betrieb genommen werden! The negative pressure unit D 610 is delivered in series with an ON / OFF switch. • Connect to power • Turn ON/OFF switch Negative pressurisation •... -
Page 17: Maintenance
Instruction manual Negative Pressure Unit D 610 EX 9 Maintenance 9.1 Maintenance The ventilator plants (deduster, industrial vacuum cleaners and devices for the deaeration or negative pressurisation) have to be overhauled or controlled once a year at least or if necessary by an expert. -
Page 18: Main Filter Change
Instruction manual Negative Pressure Unit D 610 EX 9.4 Change of Hepa filter Attention: • Contaminated filters has to be changed under all corresponding safety measures • Filter change only when machine is switched off • Use only approved filters •... -
Page 19: Possible Failures And Their Repairs
Instruction manual Negative Pressure Unit D 610 EX 10 Possible failures and their repairs Failure Possible reason Repair Negative pressure to Pre- / intermediate Change of filters as described under filters dirty 9.3 and 9.4 Power source out of Have power source examined and... -
Page 20: Circuit Diagram
Instruction manual Negative Pressure Unit D 610 EX 11 Circuit diagram Seite 20... -
Page 21: Sound Level Measuring
Instruction manual Negative Pressure Unit D 610 EX 12 Sound level measuring Value in dB(A) Status: Engine power 100%, free exhaust, outside Seite 21... - Page 22 Betriebsanleitung ist für das Montage-, Bedienungs-, und Überwachungspersonal bestimmt. Sie enthält Vorschriften und Zeichnungen technischer Art, die weder vollständig oder auszugsweise noch zu Zwecken des Wettbewerbs unbefugt verwendet oder anderen mitgeteilt werden dürfen. Sie finden uns auch im Internet unter der Adresse http://www.deconta.com. Seite 22...
