1997 Cartridge
Service Addendum
Judy Fork Models
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Judy cartridge 1997 and is the answer not in the manual?

Questions and answers

Summary of Contents for RockShox Judy cartridge 1997

  • Page 1 1997 Cartridge Service Addendum Judy Fork Models ®...
  • Page 2 (oil change) to maintain optimal performance.When servicing the cartridge,keep in mind that the best performing cartridges have the least amount of air.Cartridge service is easiest with a RockShox cartridge tool kit available from your dealer.The following instructions are written for use with the cartridge service tool kit, but the cartridge can be serviced without these tools.
  • Page 3 1. Install snap ring, sharp outside edge up, and plastic shaft guide washer into upper end of cartridge body. 2. Lightly coat inside of cartridge body with RockShox oil.Apply grease to upper cartridge seal inside and out. Slide seal, pocket side down, onto upper seal installation tool.
  • Page 4 6. Let assembly set for minimum of 5 minutes to allow any residual air to escape. 7. Install top-out o-ring and seal washer onto shaft. 8. Fill cartridge body with RockShox oil to within 5mm of body edge. Fig. 12 Fig.
  • Page 5 Tightening Torque Table Crown Bolts 60 in-lb 6.8Nm Top Cap Assemblies 30 in-lb 3.4Nm Fork Brace Bolts 60 in-lb 6.8Nm Brake Posts 60 in-lb 6.8Nm Shaft Bolts 60 in-lb 6.8Nm Warranty WARRANTS ITS FORKS FOR A PERIOD OF ONE YEAR FROM ORIGINAL DATE OF PURCHASE TO BE FREE FROM DEFECTS IN MATERIALS OR WORKMANSHIP HOX FORK THAT IS RETURNED TO THE FACTORY AND IS FOUND BY HOX TO BE DEFECTIVE IN MATERIALS OR WORKMANSHIP WILL BE REPAIRED OR REPLACED AT THE OPTION OF...
  • Page 6 FAX: 65 466 7610 Phone: 598 241 8450 FAX: 598 241 2514 Korea Slovakia KS Trading Velo Gepard Ltd. RockShox, Inc. Phone: 822 548 5408 Phone: 4202 243 15631 FAX: 822 512 3230 FAX: 4202 243 16189 401 Charcot Avenue...
  • Page 7 ® Bushing Service Addendum, PN 950-000187-00 © RockShox, Inc. January 1997...
