Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
300-POUND CAPACITY
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
BAR STOOL
Model # 73014
bit.ly/wenvideo
(M-F 8AM-5PM CST)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wen 73014 Series
Summary of Contents for Wen 73014 Series
- Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
- Page 2 TABLE OF CONTENTS Technical Data Rules for Safe Operation Assembly Exploded View Warranty TECHNICAL DATA Model Number: 73014 Maximum Capacity: 300 pounds evenly distributed Seat Height: 29 inches Foot Rest Height: 13-1/2 inches Weight: 14 lbs...
- Page 3 GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFE- TY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not use your item until the following steps have been read and understood. These safety rules cannot address every possible scenario you may encounter, so please use common sense and caution when using the item.
- Page 4 ASSEMBLY 1. Attach the foot pad (12) to the bottom of both the upper (8) and lower legs (7). 2. Set the upper legs (8) over the lower legs (7) as shown in the following diagram. 3. Slide the upper ring (9) into the leg assembly and connect the three pieces with four round head bolts (10). Make sure the bolts are inserted from the outside of the stool towards the inside.
- Page 5 EXPLODED VIEW AND PARTS LIST PART DESCRIPTION QUANTITY 73014-01 Seat 73014-02 Swivel 73014-03 Flat Washer Round Phillips 73014-04 Head Bolt M6x14 Round Phillips 73014-05 Head Bolt M6x35 73014-06 Nut M6 73014-07 Lower Leg 73014-08 Upper Leg 73014-09 Upper Ring Round Phillips 73014-10 Head Bolt M6x50 73014-11...
- Page 6 LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
