Teldat S.A.
Front of the double-port TBC1-GFAST card
Fig. 3:
The front board elements are as follows:
Elements table for the front of the TBC1-GFAST card
Item
A and A'
B and B'
C and C'
TBC1-GFAST card
Description
xDSL port 0 and 1
Port 0 and port 1 enabled LED.
Port 0 and port 1 xDSL link status LED.
2 TBC1-GFAST Expansion Card
5
