2 TBC1-GFAST Expansion Card
Downstream Speed
Upstream Speed
Transfer Mode
VDSL2
Standards
Downstream Speed
Upstream Speed
Transfer Mode
G.Fast
Standards
Downstream Speed
Upstream Speed
Transfer Mode

2.2 TBC1-GFAST expansion card: Connectors

Figure 2a shows the front board of the single-port TBC1-GFAST card:
Front of the single-port TBC1-GFAST card
Fig. 2:
Figure 2b shows the front board of the double-port TBC1-GFAST card:
4
G.992.5 (ADSL2+):
• Annex A: ADSL2+ over POTS.
• Annex B: ADSL2+ over ISDN.
• Annex M: ADSL2+ with extended upstream over POTS.
• Annex J: ADSL2+ all digital over ISDN.
27 Mbps.
3 Mbps.
ATM ( Asynchronous Transfer Mode ).
ITU-T G.993.2 and G.993.5:
• Profiles: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a, 35b
• Vectoring and super-vectoring
Up to 300 Mbps.
Up to 50 Mbps.
PTM (Packet Transfer Mode ).
ITU-T G.9700 and G.9701:
• Profiles: 106a and 212a
Up to 1.2 Gbps.
Up to 600 Mbps.
PTM (Packet Transfer Mode ).
Teldat S.A.
TBC1-GFAST card
