Chapter 2 TBC1-GFAST Expansion Card
This manual focuses on the TBC1-GFAST expansion card.
This expansion card supports:
For further information on ADSL, VDSL2 and G.Fast technologies, please see the Teldat- Dm741-I ADSL-VD-
SL2-GFAST manual.
TBC1-GFAST card
Fig. 1:

2.1 TBC1-GFAST expansion card: Characteristics

The main characteristics of the TBC1-GFAST expansion card are as follows:
TBC1-GFAST xDSL Characteristics
Ports
ADSL
Standards
TBC1-GFAST card
• G.Fast 212a and 106a, as defined in the ITU G.9700 and G.9701 standards.
• VDSL2 up to 35b supervectoring, as defined in the ITU G.993.2 and G.993.5
standards.
• ADSL2+ for POTS and ISDN, as defined in the ITU G.992.5 standard.
• ADSL2 for POTS and ISDN, as defined in the ITU G.992.3 standard.
• ADSL for POTS and ISDN, as defined in the ITU G.992.1 standard.
Up to two RJ-45 GFAST/VDSL2/ADSL ports
ANSI:
• T1.413 Issue 2.
ITU-T G.992.1 (G.DMT):
• Annex A: Full Rate ADSL over POTS.
• Annex B: Full Rate ADSL over ISDN.
ITU-T G.992.2 (G.Lite).
G.992.3 (ADSL2):
• Annex A: ADSL2 over POTS.
• Annex B: ADSL2 over ISDN.
• Annex L: RE-ADSL2 over POTS.
• Annex M: ADSL2 with extended upstream over POTS.
• Annex J: ADSL2 all digital over ISDN.
ITU-T G.992.4 (ADSL2.Lite).
