INSTRUCTION MANUAL
PACKING LIST
Make sure to take out all contents and accessories. Do not discard the packaging until everything
is removed. Check the packing list below to make sure you have all of the parts and accessories.
If any part is missing or broken, please contact customer service at 1-800-232-1195 (M-F 8-5
CST), or email techsupport@wenproducts.com.
Wheel Assembly Parts
Wheels (2)
Axles (2)
Washers (2)
Cotter Pins (2)
NOTE: You will need a wrench to tighten the nuts onto the bolts.
WARNING! Do not turn on the generator until it is fully assembled according to the
instructions. Read through and become familiarized with the following procedures of handling
and adjusting your tool. Failure to follow the safety instructions may result in serious personal
injury.
WARNING! Never use the handle as a lifting point to support the entire weight of the
generator. Only use the handle to pull the generator with the help of the wheels.
WARNING! Use caution when collapsing the handle. Hands and fingers could get caught
and pinched.
WHEEL AND HANDLE KIT
Handle Assembly Parts
Handle
Stopper (1)
Axle
M6x55
Bolt/Nut (1)
Handle Bracket (1)
Flip page for assembly instructions.
Compatible with WEN Generator Model GN4500
Handle (1)
Bolt/Nut (1)
Leg Assembly Parts
M6x40 Bolts/Nuts (4)
8/M6x40
Bolts/Nuts (2)
GNA410
v.2019.07.03
Legs
(2)
M8x35
