About the camera

EN
Front / Back / Top / Bottom View
Wrist strap
loop
LCD
screen
Zoom Lens
Power button
Tripod
mount
001
Flash
Self-timer LED
Zoom Lens
Microphone
Zoom button
Playback button
Menu button
Four-way navigation
buttons
OK button
Scene button
Shutter button
Battery/SD card
compartment
©2008 BenQ Corporation. All rights reserved.
Left / Right View
Wrist strap loop

Installing Battery and Memory Card

Inserting the battery

1. Open the battery compartment of the camera.
2. Insert the battery into the battery compartment, observing the correct polarity,
and close the battery compartment.

Inserting an SD Memory Card

1. Open the SD card compartment of the camera.
2. Insert the SD card into the memory card slot, observing the correct
orientation.
3. To remove the SD card, gently push the SD card till it pops out and then pull
out the card.

Turning the Camera On and Off

1. To turn on the camera, press and hold down the Power button. The
initialization screen is displayed and the camera is now ready to capture
photos or video clips.
2. To turn off the camera, press the Power button. The camera is powered off.

First Time Use

1. Press the Power button, a BenQ logo displays on the LCD screen
momentarily.
2. If the camera is turned on for the first time, the Language menu pops up
automatically after powering on the camera.
3. After the desired language is selected, the Date and Time menu pops up.Use
the Navigation buttons to select each field and adjust the value. Press the
OK button to confirm.
EN
Speaker
USB/AV port
DC Jack
