GF HE ALTH PROD U CT S , I N C .
O P E RATIN G M AN UA L
Hausted® Surgi-Stretchers
Models: 578 (Hydraulic Models)
5E8 (Electric Models)
5D8 (Electric Models)
5E7 (Electric Models with
Hydraulic Hi/Lo)
5D7 (Electric Models with
Hydraulic Hi/Lo)
GFH1300077RevB13

Advertisement

Table of Contents
loading

Related Manuals for GF Health Products Hausted 578

Summary of Contents for GF Health Products Hausted 578

  • Page 1 O P E RATIN G M AN UA L Hausted® Surgi-Stretchers Models: 578 (Hydraulic Models) 5E8 (Electric Models) 5D8 (Electric Models) 5E7 (Electric Models with Hydraulic Hi/Lo) 5D7 (Electric Models with Hydraulic Hi/Lo) GFH1300077RevB13 GF HE ALTH PROD U CT S , I N C .
  • Page 2 WARNING - COPYING PROHIBITED This manual is protected by Federal Copyright Law, which provides for damages of up to USD $20000, as well as criminal fines and imprisonment, for unauthorized copying.
  • Page 3 Section 1 of this manual. Do not oper- ate or service the equipment until you have be- GF Health Products, Inc. carries a complete line of come familiar with this information. accessories for use with this stretcher. Your rep- resentative will gladly review these with you.
  • Page 4 Manufactured by: GF Health Products, Inc. 336 Trowbridge Drive Fond du Lac, WI 54937 678.291.3207 Main 770.368.2386 Fax www.Hausted.com Class 1 Equipment Type B Equipment Equipment not suitable for use in the pres- ence of flammable anesthetic mixture with air or oxygen or nitrous oxide.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS 1 Listing of Warnings and Cautions .............1-1 2 Uncrating Instructions ................2-1 3 Operating Instructions ................3-1 3.1 Stretcher Specifications .................3-1 3.2 Features, Warnings, and Proper Operation ............3-2 3.3 Braking and Steering ..................3-4 3.3.1 Applying the Brakes ................3-4 3.3.2 Releasing the Brakes ................3-4 3.3.3 Applying the Steering Lock/Fifth Wheel ..........3-4...
  • Page 6 TABLE OF CONTENTS 3.9 Eye Headrest ....................3-12 3.9.1 Pre-Op/Post-Op Head Extension - Pushbar ........3-12 3.9.2 Adjusting the Eye Headrest ..............3-12 3.9.3 Mounting the Wrist Rest ..............3-13 3.10 Permanently-Mounted I.V. Rod Operation ...........3-14 3.10.1 Putting I.V. Rod in Up Position ............3-14 3.10.2 Extending I.V.

  • Page 7: Listing Of Warnings And Cautions

    Fifth wheel remove the cover. For service options contact steering functions can be influenced by floor GF Health Products, Inc. irregularities (bumps or dips) greater than 1/2” To avoid the risk of electric shock, this (13 mm) across the span of the stretcher.
  • Page 8 LISTS OF WARNINGS AND CAUTIONS WARNING — CAUTIONS AND To turn electic controls on, plug into wall receptacle. To turn off, remove plug from PROPER OPERATION (Continued): wall receptacle. The electric powered stretchers do not have a seperate on/off Portable and mobile RF communications switch.

  • Page 9: Uncrating Instructions

    This will help step 5. If any of the features do not work properly, avoid personal injuries frequently incurred call GF Health Products, Inc. at 678.291.3165. when bands are cut and tension is released. Note: Although the equipment has been fully...

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS 3.1 S SPECIFICATIONS NOTE: All dimensions are specified in inches. All dimensions are +/-.375. GF Health Products, Inc. reserves the right to change specifications without notice. Electrical Specifications Electrical Specifications (Applies only to 5E7 and 5E8 Models) (Applies only to 5D7 and 5D8 Models) Product Classification: Product Classification: Input Voltage: 120V~, 60Hz Input Voltage: 230V~, 50Hz Amperage: Max. 4.0A Amperage: Max. 2.0A...

  • Page 11: Features, Warnings And Proper Operation

    Operating inStruCtiOnS 3.2 FeatureS, warningS anD prOper OperatiOn warningS– warningS– CautiOnS anD prOper relateD tO SerViCe OperatiOn: anD repair: Do not sit on end – tipping may occur. J. to turn electric controls on, plug into wall a. the stretchers have a warning label located receptacle.
  • Page 12 Operating inStruCtiOnS 3.2 FeatureS, warningS anD prOper OperatiOn tHree - pOSitiOn SiDe railS See warning C & g See Warning C & G FOwler BaCKreSt StanDarD tHree - inCH See warning F See Warning F tHiCK paD nurSe COntrOl BOX ( unDer tOp ) See warning H See Warning H Built - in OXygen tanK...

  • Page 13: Braking And Steering

    Operating inStruCtiOnS 3.3 BraKing anD Steering OperatiOn 3.3.1 applying the Brakes the four wheel central braking system is acti- vated by depressing the red pedal at any of the four corners of the unit (Figure 3-1). to fully engage the brakes, the pedal should be pressed Figure 3 - 1 to approximately 45º.

  • Page 14: Stretcher Top Height Adjustment (Hydraulic Models)

    Operating inStruCtiOnS 3.4 StretCHer tOp HeigHt aDJuStMent ( HyDrauliC MODelS ) 3.4.1 Height adjustment press the pump pedal to the floor (Figure 3-4), then release. repeat this process until desired height is obtained. use smooth strokes on the pedal to ensure patient comfort. Figure 3 - 4 3.4.2 lowering litter top press down on the two release pedals at the...

  • Page 15: Backrest/Knee Flex Operation (Hydraulic Models)

    Operating inStruCtiOnS 3.5 BaCKreSt/Knee FleX OperatiOn ( HyDrauliC MODelS ) 3.5.1 raising the Backrest/Knee Flex to elevate the backrest or knee flex, flip the crank handle upwards, and rotate the crank handle clockwise (Figure 3-8). when the desired position is reached, stop the rotating motion and return the crank handle to its original position (Figure 3-9).

  • Page 16: Electric Control Locations (Electric Models)

    Operating inStruCtiOnS 3.6 eleCtriC COntrOl lOCatiOnS ( eleCtriC MODelS ) 3.6.1 nurses Control panel to access the nurses control panel pull out on the handle located at the foot end of the unit, under the top. (Figure 3-10 and Figure 3-11). 3.6.2 patient pendant Figure 3 - 10 the patient pendant has an adjustable...

  • Page 17: Emergency Electric Backrest Override

    Operating inStruCtiOnS 3.6 eleCtriC COntrOl lOCatiOnS ( eleCtriC MODelS ) 3.6.4 emergency electric Backrest Override the unit is equipped with a fowler backrest quick drop handle which is located under the stretcher top on the patient right. (Figure 3-14). Figure 3 - 14 this option is only to be used in an emergency situation.

  • Page 18: Stretcher Top Adjustment (Electric Models)

    OPERATING INSTRUCTIONS 3.7 STRETCHER TOP ADJUSTMENT (ELECTRIC MODELS) Caution: The lock-out deactivates pendant and control panel. 3.7.1 Hand Pendant Functions FIGURE 3.16 Foot Section Adjustment: Raising - Press the first button on the second row of buttons on the pendant (Figure 3.16). Hold until the desired angle is achieved.

  • Page 19: Trendelenburg Adjustment

    OPERATING INSTRUCTIONS 3.7 STRETCHER TOP ADJUSTMENT (ELECTRIC MODELS) 3.7.1 Hand pendant Functions Cont. Trendelenburg Adjustment Lockout: See “Lockout” in the Section 3.7.3 Height Adjustment Instructions. Nurse: Trendelenburg: Press the second but- FIGURE 3-20 ton on the bottom row of buttons (Figure 3.19).
  • Page 20 OPERATING INSTRUCTIONS 3.7STRETCHER TOP ADJUSTMENTS (ELECTRIC MODELS) 3.7.2 Nurse Control Functions Cont. Trendelenburg Adjustment Press and hold down the last button on the top row (top right). At the same time, press and hold down the UP or DOWN arrow but- ton which corresponds to the desired direc- tion of travel FIGURE 3-25...
  • Page 21 OPERATING INSTRUCTIONS 3.7 STRETCHER TOP ADJUSTMENT (ELECTRIC MODELS) 3.7.3 Lockout When a function of the stretcher is Locked Out, a lock out indicator light located above that function will become illuminated (Figure 3.28). In order to initiate the Lock FIGURE 3-28 Out of a function, press and hold down the Lock button (row 2, column 1).

  • Page 22: Patient Rail Operation

    Operating inStruCtiOnS 3.8 patient rail OperatiOn CautiOn: alwayS Be Sure rail iS lOCKeD intO pOSitiOn BeFOre leaVing tHe patient unattenDeD 3.8.1 raising the rail FIGURE 3-33 grasp the rail top cap in the middle of the rail (Figure 3-33) and lift. 3.8.2 Half Height grasp the rail, lift up on the red trigger FIGURE 3-34...

  • Page 23: Eye Headrest

    Operating inStruCtiOnS 3.9 eye HeaDreSt 3.9.1 pre-Op/post-Op Head extension – pushbar to remove the head extension, rotate both knobs on the ends of the extension, counter- clockwise (Figure 3-35). with both knobs FIGURE 3-35 loosened, pull out on the extension. to install the extension, slide the ends of the tubes of the extension over the pins on the fowler (Figure 3-36).

  • Page 24: Mounting The Wrist Rest

    Operating inStruCtiOnS 3.9 eye HeaDreSt 3.9.3 Mounting the wrist rest place the wrist rest into one of the three square sockets under the headrest (Figure 3-39). rotate the “t” knob on the back of the rest (Figure 3-40) clockwise. FIGURE 38A nOte: Be sure the wrist rest is secure before applying any pressure.

  • Page 25: Permanently Mounted Iv Rod Operation

    Operating inStruCtiOnS 3.10 perManently MOunteD iV rOD OperatiOn warning - perSOnal StainleSS Steel inJury HaZarD: Bag HOOK Be sure i.V. rod is inserted completely into socket up to the arrow before applying any load. SCrew COllar 3.10.1 putting iV rod in up position grasp i.V.

  • Page 26: Trouble Shooting Guide

    4.2. run on battery backup Illustrated Part(s) breakdown is provided in Section 7 of this manual. GF Health Products, Inc. may be contacted at 678.291.3165 for additional information required to service or repair the equipment.
  • Page 27 TROUBLE SHOOTING GUIDE 4.2 BATTERY REPLACEMENT INSTRUCTIONS WARNING - SHOCK HAZARD WARNING - PERSONAL INJURY HAZARD To reduce the risk of electric shock, do not remove the cover. Unit is to be serviced by The batteries are wired in series, failure to qualified service personnel (minimum 1 year connect the same way can cause batteries medical equipment service and repair experi-...

  • Page 28: Preventive Maintenance For The User

    NOTE: For more detailed information, please contact GF Health Products, Inc. at 678.291.3165. NOTE: In addition to the User Preventive Maintenance, a more detailed Preventive Maintenance Program is also required to keep the equipment in good working order.

  • Page 29: Optional Accessories

    SA0786-00 Full U (over the brow) wrist rest It is recommended that only accessories approved by GF Health Products, Inc. be used with this device. The use of accessories, transducers, and cables other than those specified by the manu- facturer may result in increased emissions or decreased immunity of the Hausted equipment.
  • Page 30 replaCeMent partS Significant assemblies and components of the Hausted® Surgi-Stretchers are illustrated and identified in this sec- tion. the part number, the description and the quantity required for each usage are given. each indentation in the description represents the assembly level. the unitS per aSSeMBly column is specific for the given assembly or subassembly level.
  • Page 31 reCOMMenDeD replaCeMent partS Figure 7 - 1. HyDrauliC BaSe aSSeMBly – witH/witHOut FiFtH wHeel aSSeMBly ( part 1 OF 2 ) Figure 7 - 1. HyDrauliC BaSe aSSeMBly – witH/witHOut FiFtH wHeel aSSeMBly ( part 1 OF 2 )
  • Page 32 reCOMMenDeD replaCeMent partS Figure 7 - 1. HyDrauliC BaSe aSSeMBly – witH/witHOut FiFtH wHeel aSSeMBly ( part 2 OF 2 ) Figure 7 - 1. HyDrauliC BaSe aSSeMBly – witH/witHOut FiFtH wHeel aSSeMBly ( part 2 OF 2 )
  • Page 33 reCOMMenDeD replaCeMent partS Figure 7 - 1. HyDrauliC BaSe aSSeMBly – witH/witHOut FiFtH wHeel aSSeMBly item no. part no. C Description units per assembly 075322 578 HYDRAULIC BASE ASSEMBLY - NO 5TH WHEEL 075322 578 HYDRAULIC BASE ASSEMBLY - WITH 5TH WHEEL 075322 PC 578 HYDRAULIC BASE ASSEMBLY - NO 5TH WHEEL 075322...
  • Page 34 reCOMMenDeD replaCeMent partS Figure 7 - 1. HyDrauliC BaSe aSSeMBly – witH/witHOut FiFtH wHeel aSSeMBly item no. part no. C Description units per assembly 069492 BuMper, Stop 150830 linK, Head end release 150830 linK, Foot end release 150830 SCrew, Set, #10-32 035122 SCrew, Hex Head Cap, 1/4”-20 x 1-5/8”...
  • Page 35 reCOMMenDeD replaCeMent partS Figure 7 - 1. HyDrauliC BaSe aSSeMBly – witH/witHOut FiFtH wHeel aSSeMBly item no. part no. C Description units per assembly 075316 SHrOuD, Column, #2 069280 COVer, Horizon, Bottom, Foot end 069281 COVer, Horizon, Head, Foot end 065387 SCrew, Self tapping, 1/4-20 x 3/4”...
  • Page 36 illuStrateD partS BreaKDOwn Figure 7-2.5E8/5D8 ELECTRIC BASE ASSEMBLY(Prior to July 1, 2013) iMpOrtant nOte: To reduce the risk of electric shock, do not remove the cover. Unit is to be serviced by qualified personnel only. For detailed plug locations, see Figures 7-9 & 7-7. For detailed label locations, see Figures 7-11.
  • Page 37 illuStrateD partS BreaKDOwn Figure 7 - 2. 5e8/5D8 eleCtriC BaSe aSSeMBly item no. part no. Description units per assembly 075457 aSSeMBly, Base Frame 062672 CaSter, tente, Brake 062671 CaSter, tente, Swivel lock 062672 plate, Caster Bolt lock 062685 SCrew, Hex Head Cap, M8 x 1.25 x 12.00” long 065041 BOlt, eye, 5/16-18 031058...
  • Page 38 illuStrateD partS BreaKDOwn FIGURE 7-3. 5E8/5D8 ELECTRIC BASE ASSEMBLY (After July 1, 2013) IMPORTANT NOTE: To reduce the risk of electric shock, do not remove the cover. Unit is to be serviced by qualified personnel only. For detailed plug locations, see figures 7-13 &...
  • Page 39 ILLUSTRATED PARTS BREAKDOWN FIGURE 7-3. 5E8/5D8 ELECTRIC BASE ASSEMBLY (After July 1, 2013) Item Part No. Description Units Per Ass’y 080435 Base Frame Assembly Weldment 056397897 Tente Caster - Brake 081682008 5/16 Lock Washer 150830554 M8 X 1.25 X 16mm LG. Hex HD Cap Screw 068338 Worm Collar 065041...
  • Page 40 reCOMMenDeD replaCeMent partS . 578 tOp aSSeMBly ( part 1 OF 2 ) Figure 7 - . 578 tOp aSSeMBly ( part 1 OF 2 ) Figure 7 - 7-12...
  • Page 41 reCOMMenDeD replaCeMent partS . 578 tOp aSSeMBly ( part 2 OF 2 ) Figure 7 - Figure 7 - . 578 tOp aSSeMBly ( part 2 OF 2 ) 7-13...
  • Page 42 reCOMMenDeD replaCeMent partS FIGURE 7-4. 578 TOP ASSEMBLY item no. part no. C Description units per assembly 578 TOP ASSEMBLY 150830 welDMent, top 075330 aSSeMBly, roller Bracket, right 075331 aSSeMBly, roller Bracket, left 031057 nut, lock, 5/16”-18 068481 plate, Foot end Support 067958 BuMper, Corner 061195...
  • Page 43 reCOMMenDeD replaCeMent partS FIGURE 7-4. 578 TOP ASSEMBLY item no. part no. C Description units per assembly 075357 StOp, Fowler 031212 HOOK, Velcro 030918 nut, Hex, 3/8”-16 030923 waSHer, Split lock, 3/8” 031080 waSHer, Flat, 5/16” 030919 BOlt, Shoulder 141210 aSSeMBly, Crank, Fowler 065258 COtter pin, locking...
  • Page 44 reCOMMenDeD replaCeMent partS . 5e8/5D8 & 5e7/5D7 tOp aSSeMBly ( part 1 OF 3 ) Figure 7 - (Prior To July 1, 2013) . 5e8/5D8 & 5e7/5D& tOp aSSeMBly ( part 1 OF 3 ) Figure 7 - 7-16...
  • Page 45 reCOMMenDeD replaCeMent partS . 5e8/5D8 & 5e7/5D7 tOp aSSeMBly ( part 2 OF 3 ) Figure 7 - (Prior To July 1, 2013) . 5e8/5D8 & 5e7/5D& tOp aSSeMBly ( part 2 OF 3 ) Figure 7 - 7-17...
  • Page 46 reCOMMenDeD replaCeMent partS . 5e8/5D8 & 5e7/5D7 tOp aSSeMBly ( part 3 OF 3 ) Figure 7 - (Prior To July 1, 2013) . 5e8/5D8 & 5e7/5D& tOp aSSeMBly ( part 3 OF 3 ) Figure 7 - 7-18...
  • Page 47 reCOMMenDeD replaCeMent partS FIGURE 7-5. 5E8/5D8 & 5E7/5D7 TOP ASSEMBLY (Prior to July 1, 2013) item no. part no. C Description units per assembly 5E8/5E7 TOP ASSEMBLY 5D8/5D7 TOP ASSEMBLY 150830 welDMent, top p75071 aSSeMBly, Fowler, electric 150830 pan, Seat 150830 aSSeMBly, Knee Section p66257...
  • Page 48 reCOMMenDeD replaCeMent partS FIGURE 7-6. 5E8/5D8 & 5E7/5D7 TOP ASSEMBLY (Prior to July 1, 2013) item no. part no. C Description units per assembly 068986 aCtuatOr, Foot Section 068985 aCtuatOr, Fowler rest 075402 COVer, Controller top 031500 SCrew, truss Head Machine, 10-24 x 1” long 031090 waSHer, lock, internal 000990...
  • Page 49 reCOMMenDeD replaCeMent partS . 5e8/5D8 & 5e7/5D7 tOp aSSeMBly ( part 1 OF 3 ) Figure 7 - (After July 1, 2013) . 5e8/5D8 & 5e7/5D& tOp aSSeMBly ( part 1 OF 3 ) Figure 7 - 7-21...
  • Page 50 reCOMMenDeD replaCeMent partS . 5e8/5D8 & 5e7/5D7 tOp aSSeMBly ( part 2 OF 3 ) Figure 7 - (After July 1, 2013) . 5e8/5D8 & 5e7/5D& tOp aSSeMBly ( part 2 OF 3 ) Figure 7 - 7-22...
  • Page 51 reCOMMenDeD replaCeMent partS . 5e8/5D8 & 5e7/5D7 tOp aSSeMBly ( part 3 OF 3 ) Figure 7 - (After July 1, 2013) . 5e8/5D8 & 5e7/5D& tOp aSSeMBly ( part 3 OF 3 ) Figure 7 - 7-23...

  • Page 52: Illustrated Parts Breakdown

    ILLUSTRATED PARTS BREAKDOWN FIGURE 7-6. 5E8/5D8 & 5E7/5D7 TOP ASSEMBLY (After July 1, 2013) Item Part No. Description Units Per Ass’y 5E8/5E7 TOP ASSEMBLY 5D8/5D7 TOP ASSEMBLY 150830-648 EYE Top Weldment 080512 ASSY, Fowl Horiz Elec Reg Width - 720 lb. Cap 150830-645 Seat Pan 150830-541...
  • Page 53 ILLUSTRATED PARTS BREAKDOWN FIGURE 7-6. 5E8/5D8 & 5E7/5D7 TOP ASSEMBLY (After July 1, 2013) Item Part No. Description Units Per Ass’y 080457 Pendant BL1/CB14 - HBB5 Hausted 068481 Foot End Support Plate 075330 Roller Bracket ASSY RH 075331 Roller Bracket ASSY LH 067958 Corner Bumper 080454...
  • Page 54 reCOMMenDeD replaCeMent partS Figure 7 - . eye FOwler aSSeMBly Figure 7 - . eye FOwler aSSeMBly 7-27...
  • Page 55 reCOMMenDeD replaCeMent partS FIGURE 7-7. EYE FOWLER ASSEMBLY item no. part no. C Description units per assembly 075101 EYE FOWLER ASSEMBLY p75128 welDMent, Model 578 Backrest 031175 plug, Hole, 18 gauge 075124 CaSting, pivot plate 075120 aSSeMBly, Head Board Support plate 075148 BOarD, Head 031320...
  • Page 56 reCOMMenDeD replaCeMent partS FIGURE 7-7. EYE FOWLER ASSEMBLY item no. part no. C Description units per assembly 067828 HOOK, Velcro, 2” x 5” 031314 pin, Spring, 3/16” x 3/4 075152 Mounting 755717 aSSeMBly, Head Section 7-29...
  • Page 57 reCOMMenDeD replaCeMent partS Figure 7 -8 . patient rail aSSeMBly ( leFt anD rigHt ) patient rail aSSeMBly ( leFt anD rigHt) Figure 7. 7-31...
  • Page 58 reCOMMenDeD replaCeMent partS FIGURE 7-8. PATIENT RAIL ASSEMBLY (LEFT AND RIGHT) item no. part no. C Description units per assembly 075067 PATIENT RAIL ASSEMBLY, LEFT 075066 PATIENT RAIL ASSEMBLY, RIGHT 150830 aSSeMBly, top Cap 075065 leg, rail 075064 leg, lock 056397 plate, lock, left 056397...
  • Page 59 reCOMMenDeD replaCeMent partS FIGURE 7-9. 5E8/5D8 & 5D7/5E7 CONTROLLER ASSEMBLY (AFTER 7.1.13) iMpOrtant nOte: To reduce the risk of electric shock, do not remove the cover. Unit is to be serviced by qualified personnel only. For detailed plug locations, see Figure 7-13. plug and wiring Diagram (after 06/01/98) and Figure 7-14.
  • Page 60 ILLUSTRATED PARTS BREAKDOWN FIGURE 7-9. 5E8/5D8 & 5E7/5D7 CONTROLLER ASSEMBLY (AFTER 7.1.13) Item Part No. Description Units Per Ass’y 5E8/5E7 CONTROLLER ASSY 5D8/5D7 CONTROLLER ASSY 080455 CB-16 Controller 120V Elec ST - 720 lb. Cap 080456 CB-16 Controller 230V Elec ST - 720 lb. Cap 061159 10-24 X 5/8 THMS 068786...
  • Page 61 reCOMMenDeD replaCeMent partS FIGURE 7-10. 5E8/5D8 & 5E7/5D7 CONTROLLER ASSEMBLY (AFTER 5.1.00, PRIOR TO 7.1.13) iMpOrtant nOte: To reduce the risk of electric shock, do not remove the cover. Unit is to be serviced by qualified personnel only. For detailed plug locations, see Figure 7-13. plug and wiring Diagram (after 06/01/98) and Figure 7-14.
  • Page 62 reCOMMenDeD replaCeMent partS FIGURE 7-10. 5E8/5D8 & 5E7/5D7 CONTROLLER ASSEMBLY (AFTER 5.1.00, PRIOR TO 7.1.13) item no. part no. C Description units per assembly 076138 CONTROLLER ASSEMBLY (AFTER 5.1.00) REG 076139 CONTROLLER ASSEMBLY (AFTER 5.1.00) EW 076140 CONTROLLER ASSEMBLY (AFTER 5.1.00) REG 076129 CONTROLLER ASSEMBLY (AFTER 5.1.00) EW 075044...
  • Page 63 reCOMMenDeD replaCeMent partS FIGURE 7-11. 5E8 CONTROLLER ASSEMBLY (BEFORE 6.1.98) iMpOrtant nOte: To reduce the risk of electric shock, do not remove the cover. Unit is to be serviced by qualified personnel only. For detailed plug locations, see Figure 7-13. plug and wiring Diagram (after 06/01/98) and Figure 7-14.
  • Page 64 reCOMMenDeD replaCeMent partS FIGURE 7-11. 5E8 CONTROLLER ASSEMBLY (BEFORE 6.1.98) item no. part no. C Description units per assembly 075711 CONTROLLER ASSEMBLY (BEFORE 6.1.98) REG 075520 CONTROLLER ASSEMBLY (BEFORE 6.1.98) EW 075498 Hanger, Controller, rear 075702 Hanger, Controller, rear 068962 COntrOller (Mfg Before 9.98) 075054 COntrOller (Mfg after 9.98)
  • Page 65 reCOMMenDeD replaCeMent partS FIGURE 7-12. PLUG AND WIRING DIAGRAM (AFTER 7.1.13) iMpOrtant nOte: To reduce the risk of electric shock, do not remove the cover. Unit is to be serviced by qualified personnel only. For detailed label location, see Figure 7-15.
  • Page 66 ILLUSTRATED PARTS BREAKDOWN FIGURE 7-12. PLUG AND WIRING DIAGRAM (AFTER 7.1.13) Item Part No. Description Units Per Ass’y 063031 Button 431172-091 Cable Tie 068864 Strain Relief 080509 Power Cord Wrap Mounting Bracket, Stretcher 065438 Cable Clamp 031072 Flat Washer 000794 3/16 Pop Rivet 031000 10-24 X 1/2 Hex HD.
  • Page 67 reCOMMenDeD replaCeMent partS FIGURE 7-13. PLUGAND WIRING DIAGRAM (AFTER 6.1.98, BEFORE 7.1.13) iMpOrtant nOte: To reduce the risk of electric shock, do not remove the cover. Unit is to be serviced by qualified personnel only. For detailed label location, see Figure 7-15.
  • Page 68 reCOMMenDeD replaCeMent partS FIGURE 7-13. PLUG AND WIRING DIAGRAM (AFTER 6.1.98, BEFORE 7.1.13) item no. part no. C Description units per assembly PLUG AND WIRING DIAGRAM (AFTER 6.1.98) 063031 ButtOn 065403 tie, Cable 068874 relieF, Strain p75743 COrD, Hanger Coil 065438 ClaMp, Cable 031072...
  • Page 69 reCOMMenDeD replaCeMent partS FIGURE 7-14. PLUG AND WIRING DIAGRAM (BEFORE 6.1.98) iMpOrtant nOte: To reduce the risk of electric shock, do not remove the cover. Unit is to be serviced by qualified personnel only. For detailed plug locations, see Figure 7-13. plug and wiring Diagram (after 06/01/98) and Figure 7-14.
  • Page 70 reCOMMenDeD replaCeMent partS Figure 7 - 1 laBel lOCatiOnS electric Models Manual/Hydraulic Models Figure 7 - 1 laBel lOCatiOnS 7-45...
  • Page 71 reCOMMenDeD replaCeMent partS FIGURE 7-15. LABEL LOCATIONS item no. part no. C Description units per assembly LABEL LOCATIONS 075035 laBel, Control panel 075490 laBel, Max patient weight 075040 laBel, emer Drop Back rest 075149 laBel, articulating Headrest label 075849 laBel, Side Hydraulic right 075850 laBel, Side Hydraulic left 063022...
  • Page 72 reCOMMenDeD replaCeMent partS Figure 7 - 1 wriSt reSt aSSeMBly, eye, Dual lateral Figure 7 - 1 . wriSt reSt aSSeMBly, eye, Dual lateral 7-47...
  • Page 73 reCOMMenDeD replaCeMent partS FIGURE 7-16. WRIST REST ASSEMBLY, EYE, DUAL LATERAL item no. part no. C Description units per assembly SA0785 WRIST REST ASSEMBLY, EYE, DUAL LATERAL 075142 aSSeMBly, Sub-, Full wrist rest 075135 • welDMent, wrist rest Support 075138 •...
  • Page 74 reCOMMenDeD replaCeMent partS Figure 7 - 17. wriSt reSt aSSeMBly, eye, OVer BrOw Figure 7 - 1 . wriSt reSt aSSeMBly, eye, OVer BrOw 7-49...
  • Page 75 reCOMMenDeD replaCeMent partS FIGURE 7-17. WRIST REST ASSEMBLY, EYE, OVER BROW item no. part no. C Description units per assembly SA0786 WRIST REST ASSEMBLY, EYE, OVER BROW 075142 aSSeMBly, wrist rest Support 075135 • welDMent, wrist rest Support 075138 • Bar, wrist rest Mounting 075141 •...
  • Page 76 reCOMMenDeD replaCeMent partS FIGURE 7-18. I.V. ROD ASSEMBLY, EYE TOPS BUILT PRIOR TO 1.1.98; BETWEEN 6.1.98 AND 10.1.98 FIGURE 7-18. I.V. ROD ASSEMBLY, EYE TOPS BUILT PRIOR TO 1.1.98; BETWEEN 6.1.98 AND 10.1.98 7-51...
  • Page 77 reCOMMenDeD replaCeMent partS FIGURE 7-19. I.V. ROD ASSEMBLY, EYE TOPS BUILT PRIOR TO 1.1.98 AND 6.1.98; BETWEEN 6.1.98 AND 10.1.98 item no. part no. C Description units per assembly 066EYE EYE I.V. ROD ASSEMBLY, TOPS PRIOR TO 1.1.98, MOUNTS ON OUTSIDE OF TOP (TOP CHANNEL LENGTH: 63.00”) 066019 EYE I.V.
  • Page 78 reCOMMenDeD replaCeMent partS Figure 7 - i.V. rOD aSSeMBly, eye tOpS Built Between 10.1.98 anD 3.5.03 iMpOrtant nOte: I.V. rod is shown mounted on patient’s right, which is standard. I.V. rod can be mounted on the patient’s left. by bolting it to the opposite side angle. Figure 7 - i.V.
  • Page 79 reCOMMenDeD replaCeMent partS FIGURE 7-20. I.V. ROD ASSEMBLY, EYE TOPS BUILT BETWEEN 10.1.98 AND 3.5.03 item no. part no. C Description units per assembly 066EY0 EYE I.V. ROD ASSEMBLY, TOPS (AFTER 10.1.98) 062038 SCrew, Hex Head Cap, 1/4-20 x 5/8” long 031055 nut, lock,1/4-20 075569...
  • Page 80 reCOMMenDeD replaCeMent partS Figure 7 - . i.V. rOD aSSeMBly, eye tOpS Built aFter 3.5.03 Figure 7 - . i.V. rOD aSSeMBly, eye tOpS Built aFter 3.5.03 7-55...
  • Page 81 ILLUSTRATED PARTS BREAKDOWN FIGURE 7-21. I.V. ROD ASSEMBLY, EYE TOPS BUILT AFTER 3.5.03 Item Part No. Description Units Per Ass’y 075565 Casting, I.V. Rod Hinge 075577 Rivet, 1/4” X 1 9/16 075566 Plug, I.V. Rod Bottom 056397-874 Tube, Outside 075593 Label, Warning 066015 Glide, Outside Cap...
  • Page 82 reCOMMenDeD replaCeMent partS Figure 7 - FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( part 1 OF 3 ) Figure 7 - . FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( part 1 OF 3 ) 7-57...
  • Page 83 reCOMMenDeD replaCeMent partS Figure 7 - 22. FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( part 2 OF 3 ) Figure 7 - 22. FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( part 2 OF 3 ) 7-58...
  • Page 84 reCOMMenDeD replaCeMent partS Figure 7 - 22. FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( part 3 OF 3 ) Figure 7 - . FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( part 3 OF 3 ) 7-59...
  • Page 85 ILLUSTRATED PARTS BREAKDOWN FIGURE 7-22. FIFTH WHEEL SUB-ASSEMBLY, ELECTRIC BASE (AFTER 7.1.13) Item Part No. Description Units Per Ass’y 080468 Fifth Wheel Sub-Assembly, Electric Base FIG. 7-22 Part 1 of 3 062684 150830-756 5/16 - 18 Lock Nut 065807 Bolt, Shoulder 3/8 X 3/8 080086 M6-1 X 10 Hex Cap Screw GR8.8 Zinc 080460...
  • Page 86 reCOMMenDeD replaCeMent partS Figure 7 - . FiFtH wHeel SuB - aSSeMBly, HyDrauliC BaSe/eleCtriC BaSe ( part 1 OF 3 ) Figure 7 - FiFtH wHeel SuB - aSSeMBly, HyDrauliC BaSe/eleCtriC BaSe ( part 1 OF 3 ) 7-61...
  • Page 87 reCOMMenDeD replaCeMent partS Figure 7 - . FiFtH wHeel SuB - aSSeMBly, HyDrauliC BaSe/eleCtriC BaSe ( part 2 OF 3 ) Figure 7 - . FiFtH wHeel SuB - aSSeMBly, HyDrauliC BaSe/eleCtriC BaSe ( part 2 OF 3 ) 7-62...
  • Page 88 reCOMMenDeD replaCeMent partS Figure 7 - . FiFtH wHeel SuB - aSSeMBly, HyDrauliC BaSe/eleCtriC BaSe ( part 3 OF 3 ) Figure 7 - FiFtH wHeel SuB - aSSeMBly, HyDrauliC BaSe/eleCtriC BaSe ( part 3 OF 3 ) 7-63...
  • Page 89 reCOMMenDeD replaCeMent partS FIGURE 7-23. FIFTH WHEEL SUB-ASSEMBLY, HYDRAULIC BASE/ELECTRIC BASE item no. part no. C Description units per assembly 076103 FiFtH wHeel SuB-aSSeMBly, HyDrauliC BaSe 075799 FiFtH wHeel SuB-aSSeMBly, eleCtriC BaSe 076107 linK, Short 075783 linK, long 065807 BOlt, Shoulder, 3/8” x 3/8” 062684 150830 nut, lock, 5/16”-18...
  • Page 90 reCOMMenDeD replaCeMent partS Figure 7 - 24. FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( aFter 7.1.13 ) Figure 7 - 24. FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( aFter 7.1.13 ) 7-65...
  • Page 91 ILLUSTRATED PARTS BREAKDOWN FIGURE 7-24. FIFTH WHEEL SUB-ASSEMBLY, ELECTRIC BASE (AFTER 7.1.13) Item Part No. Description Units Per Ass’y 031076 1/4 Flat Washer 150830-756 5/16 Lock Out 062684 065807 3/8 X 3/8 Shoulder Bolt 031006 1/4 - 20 X 1 1/2 Hex HD Cap Screw 031055 1/4 - 20 Lock Nut 080468...
  • Page 92 reCOMMenDeD replaCeMent partS Figure 7 - 25. FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( aFter 9.1.99, BEFORE 7.1.13 ) Figure 7 - 18. FiFtH wHeel SuB - aSSeMBly, eleCtriC BaSe ( aFter 9.1.99 ) 7-67...
  • Page 93 reCOMMenDeD replaCeMent partS FIGURE 7-25. FIFTH WHEEL SUB-ASSEMBLY, ELECTRIC BASE (AFTER 9.1.99, BEFORE 7.1.13) item no. part no. C Description units per assembly 068516 FIFTH WHEEL ASSEMBLY, AFTER 9.1.99 aSSeMBly, Horizon Base 051308 nyliner, Flange, 3/4” X 1-1/8” 068360 aSSeMBly, Swivel Bracket 068429 plate, 5th wheel Hinge 068415...

  • Page 94: Appendix

    APPENDIX 8.1 GUIDANCE AND MANUFACTURER’S DECLARATION — ELECTROMAGNETIC EMISSIONS The Hausted A.P.C. Series Models and Surgi-Chairs are intended for use in the electromagnetic environ- ment specified below. The customer or the user of the Hausted A.P.C. Series Models and Surgi-Chairs should assure that it is used in such an environment.

  • Page 95: Guidance And Manufacturer's Declaration - Electromagnetic Immunity

    APPENDIX 8.2 GUIDANCE AND MANUFACTURER’S DECLARATION — ELECTROMAGNETIC IMMUNITY The Hausted A.P.C. Series Models and Surgi-Chairs are intended for use in the electromagnetic environ- ment specified below. The customer or the user of the Hausted A.P.C. Series Models and Surgi-Chairs should assure that it is used in such an environment.

  • Page 96: Recommended Separation Distances

    APPENDIX 8.3 GUIDANCE AND MANUFACTURER’S DECLARATION — ELECTROMAGNETIC IMMUNITY The Hausted A.P.C. Series Models and Surgi-Chairs are intended for use in the electromagnetic environ- ment specified below. The customer or the user of the Hausted A.P.C. Series Models and Surgi-Chairs should assure that it is used in such an environment.
  • Page 97 APPENDIX 8.4 RECOMMENDED SEPARATION DISTANCES BETWEEN PORTABLE AND MOBILE RF COMMUNICATIONS EQUIPMENT AND HAUSTED A.P.C. SERIES MODELS AND SURGI-CHAIRS The Hausted A.P.C. Series Models and Surgi-Chairs are intended for use in an electromagnetic envi- ronment in which radiated RF disturbances are controlled. The customer or the user of the Hausted A.P.C.

  • Page 98: Warranty

    SCOPE OF WARRANTY GF Health Products, Inc. (“GF”) warrants to the original purchaser only that it will replace or repair components, at GF’s sole discretion, that are defective in material or workmanship under normal use and service. All warranties are conditioned upon the proper use of the products strictly in accordance with good commercial practice and applicable GF instructions and manuals, including proper use and maintenance.

  • Page 99: Disposal And Key To Symbols

    DISPOSAL AND KEY TO SYMBOLS DISPOSAL Hausted equipment and accessories can be disposed of. We recommend disassembling and dividing the equipment and components into different waste groups such as: metal, cable, electronic, recoverable resource and plastic for recycling or combustion. Most plastic components are provided with a plastic types code and fiber content to aid sorting of plastic parts.
  • Page 100 www.hausted.com www.grahamfield.com...
