Front View - Samsung SCX-3405 User Manual

Machine overview
10

Front view

• This illustration may differ from your machine depending on your model.
There are various types of machine.
• Some features and optional goods may not be available depending on
model or country (see "Features by models" on page 7).
Type A
1
7
6
5
4 3
1 Scanner lid 7
8
9
2
11
10
Output tray
2 Control panel 8
3 9
Handle
4 Tray 10 Inner cover
5 Tray handle 11 Toner cartridge
6 Output support
a. Close the scanner lid before opening the scan unit.
b. Be careful not to pinch your fingers.
Scanner glass
a b
Scan unit
