4.3. Command Interface
The command interface is a new addition to version 4 of the converter's firmware. This interface has been
developed primarily to support programming access to the configuration settings by an application such as our own
configuration application, but can also offer a powerful human operated (e.g. via HyperTerminal) command driven
interface in it's own right. Additionally, the commands can be placed in a Text/script file and sent (e.g. by
HyperTerminal) in one go to the converter. The <scr> command is strongly recommended for use in this scenario.
The command interface protocol is quite straightforward. Each command (see table and descriptions below) must
be sent over the COM port, followed by a Carriage return. This can be done in HyperTerminal just by typing each
command and hitting the Enter key.
There are up to 3 ways each command can be used.
1. On its own. This acts as a "query" command.
e.g. cod<CR>
Returns the current device class
2. With an "=" and parameter(s). This acts as a "set" command
e.g. cset=9600,n,1<CR>
Sets the current settings to 9600 baud, No Parity and 1 Stop Bit
Not all commands support this function as they are query commands only
3. With a "?" which acts as a "help" command
e.g. svc?<CR>
Returns a description of the command syntax and allowable parameters
The command list summary is given below.
Command
Description
Name
aset
Get all settings
btset
Get current Bluetooth settings
cnx
Manually connect to a found device
cod
Class Of Device
cset
Communication Settings
delpair
Delete the current pair
delpart
Delete the current Partner
dflt
Default settings
disc
Discoverability
enc
Encryption
find
Manually perform an inquiry
help or ?
Help
hsk
Handshaking
ladd
Local device address
list
List the manually-found devices
lowpwr
Low Power Mode
lnam
Local device name
The full command list syntax and programming examples will be given in a future edition of this manual. In the
meantime, this information can be found using the help or ? command in HyperTerminal when your converter is
attached to an available COM port.
Manual for BL-521 5_3.doc
Command
Name
menu
padd
pair
parkset
part
pin
pnam
prox
remcfg
scr
sec
sniffset
svc
svr
upg
ver
verb
© Copyright Brainboxes Limited 2004
Description
Display Menu
Partner Address
Pair
Park Settings
Partner
PIN code
Partner Name
Set the proximity mode
Remote Configuration
Script Mode
Security
Sniff Settings
Connect Using profile other than SPP
Server or Client
Prepare for upgrading
F/W app version
Verbose
Page 24 of 41
