Specifications - Samsung SyncMaster 633NW User Manual

Specifications

General
General
Model Name
LCD Panel
Size
Display area
Pixel Pitch
Synchronization
Horizontal
Vertical
Display Color
16.7 M
Resolution
Optimum resolution
Maximum resolution 1360 x 768@60 Hz
Input Signal, Terminated
RGB Analog,
0.7 Vp-p ± 5 %
Separate H/V sync, Composite, SOG
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
90 MHz (Analog)
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin - to - 15pin D-sub cable, Detachable, 1500 +/- 20 mm
Dimensions (W x H x D) / Weight (Simple Stand)
386 x 264.5 x 67.2 mm (15.2 x 10.4 x 2.6 inch) (Without Stand)
386 x 315.8 x 186.6 mm (15.2 x 12.4 x 7.3 inch) (With Stand)/ 2.55 kg (5.62 lbs)
VESA Mounting Interface
75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)
SyncMaster 633NW
15.6 inch (39 cm)
344.232 mm(H) x 193.536 mm(V)
0.252 mm(H) x 0.252 mm(V)
30 ~ 61 kHz
56 ~ 75 Hz
1360 x 768@60 Hz
