Summary of Contents for Samsung SYNCMASTER 650MP

  • Page 1: Lcd Display

    SyncMaster 650MP, 650FP LCD Display User Manual...

  • Page 2: Safety Instructions

    Safety Instructions Notational Note These safety instructions must be followed to ensure your safety and prevent property dam- age. Make sure to read the instructions carefully and use the product in the correct manner. Warning / Caution Failure to follow directions noted by this symbol could result in bodily harm or damage to the equipment.

  • Page 3: Installation

    Ensure that the power plug is plugged into the power outlet firmly and correctly. • Do not forcefully bend or pull the power plug and do not place any heavy material on it. • Do not connect multiple appliances to the same power outlet. •...
  • Page 4 Keep heating appliances as far away from the power cord or the product as possible. • Do not install it in a badly ventilated location such as a bookcase or closet. • When putting the product down, make sure to put it down softly. •...
  • Page 5 When cleaning the product, make sure to disconnect the power cord. • When cleaning the product, disconnect the power cord and clean it with a soft, dry cloth. • Since the product housing is easily scratched, make sure to use the specified cloth only.
  • Page 6 Do not try to move the monitor by pulling only the wire or the signal cable. • Otherwise, it may fall and result in electric shock, damage to the product or fire due to damage to the cable. Do not lift or move the product back and forwards or right and left while only holding the power cord or signal cables.
  • Page 7 Take a rest for at least five (5) minutes after using the monitor for one (1) hour. This reduces eye fatigue. Do not install it in an unstable location such as an unstable rack or uneven surface or a location exposed to vibrations. •...
  • Page 8 • The customer can return used or rechargeable batteries to a nearby public recycling center or to a store selling the same type of the battery or rechargeable battery. Do not place the product in a location exposed to direct sunlight or near any heat such as a fire or heater.

  • Page 9: Checking The Contents Of The Package

    Introduction Package Contents Note Please make sure the following items are included with your LCD Display. If any items are missing, contact your dealer. Contact a local dealer to buy optional items. Checking the Contents of the Package Remove the lock from the package box, as shown in the figure above. Lift up the package box by holding the grooves on both sides of the package...
  • Page 10 Manuals Quick Setup Guide (Not available in all loca- Cables Power Cord Others Remote Control Batteries (AAA X 2) (BP59-00138A) (Not available in all loca- Ferrite Core for Power Cord Sold separately DVI Cable Warranty Card User's Guide tions) D-Sub Cable BNC to RCA Adaptor Jack tions) NetworkBox...
  • Page 11 Sold separately RGB to BNC Cable Ferrite Core • • Your LCD Display Front MENU button [MENU] Opens the on-screen menu and exits from the menu. Also use to exit the OSD menu or return to the previous menu. Navigate buttons (Up-Down buttons) Moves from one menu item to another vertically or adjusts selected menu values.
  • Page 12 Switches from PC mode to Video mode. Selects the input source that an external device is connected to. [PC] → [DVI] → [AV] → [Component] → [HDMI] → [MagicInfo] → [BNC] Note • MagicInfo can only be enabled when a network box is connected. •...
  • Page 13 POWER S/W ON [ │ ] / OFF [O] Switches the LCD Display On/Off. POWER The power cord plugs into the LCD Display and the wall outlet. RS232C OUT/IN (RS232C Serial PORT) MDC(Multiple Display Control) Program Port RGB IN (PC Connection Terminal (In- put)) •...
  • Page 14 DVI/RGB/HDMI AUDIO IN (PC/DVI/ HDMI Audio Connection Terminal (Input)) AV/COMPONENT AUDIO IN [R-AUDIO- Connect the port of the DVD, VCR (DVD / DTV Set-Top Box) to the [R-AUDIO-L] port of the LCD Display. DVI OUT • Connect a monitor to another monitor through a DVI cable.

  • Page 15: Remote Control

    Note See Connecting Cables for further information regarding cable connections. Remote Control Note The performance of the remote control may be affected by a TV or other electronic device operating near the LCD Display , causing a malfunction due to interference with the frequen- BNC OUT [R, G, B, H, V] (BNC Terminal (Output)) BNC (Analog PC) Connection: connecting...
  • Page 16 POWER 3. Number Buttons 4. DEL / GUIDE but- 5. + VOL - SOURCE D.MENU 8. TOOLS POWER Number Buttons / GUIDE button + VOL - SOURCE D.MENU TOOLS Up-Down Left-Right buttons INFO COLOR BUTTONS TTX/MIX MTS/DUAL ENTER/PRE-CH MUTE CH/P MENU RETURN EXIT...
  • Page 17 9. Up-Down Left-Right but- tons INFO 11. COLOR BUTTONS TTX/MIX 13. MTS/DUAL ENTER/PRE-CH MUTE CH/P 17. TV MENU - This function does not work for this LCD Display. Moves from one menu item to another horizontally, vertically or adjusts selected menu values. Current picture information is displayed on the upper left corner of the screen.

  • Page 18: Installation Vesa Bracket

    When installing VESA, make sure to comply with the international VESA standards. • Purchasing VESA Bracket and Installation Information : Please contact your nearest SAMSUNG Distributor to place an order. After your order is placed, installation profes- sionals will visit you and install the bracket. •...

  • Page 19: Wall Bracket Installation

    • SAMSUNG is not responsible for any product damage or any injury caused by installation at customer's discretion. Dimensions Notice For securing the bracket on a wall, use only machine screws of 6 mm diameter and 8 to 12 mm length.
  • Page 20 There are two hinges(left and right). Use the correct one. Captive Screw Wall Bracket Hinge (Left) Hinge (Right) Before drilling into the wall, check if the length between the two locking holes at the back of the product is correct. If the length is too short or long, loosen all or some of the 4screws on the wall bracket to adjust the length.

  • Page 21: To Mount The Product On The Wall Bracket

    To mount the product on the wall bracket The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same) Remove the 4 screws on the back of the product. Insert the screw B into the plastic hanger.

  • Page 22: Wall Bracket Angle Adjustment

    Remove safety pin (3) and insert the 4 product holders into the corresponding bracket holes (1). Then place the product(2) so that it is firmly fixed to the bracket. Make sure to re-insert and tighten the safety pin (3) to securely hold the product to the bracket. Wall Bracket Angle Adjustment Adjust the bracket angle to -2°...
  • Page 23 Introduction Make sure to use the top center, and not the left or the right side of the product to adjust the angle.

  • Page 24: Connecting A Computer

    Connections Connecting a Computer There are several ways to connect the computer to the monitor. Choose one from the following options. Using the D-sub (Analog) connector on the video card. • Connect the D-sub to the 15-pin, [RGB IN] port on the back of your LCD Display and the 15 pin D-sub Port on the computer.
  • Page 25 Using the HDMI (digital) output on the graphics card. • Connect the [HDMI IN] port on the LCD Display to the HDMI port on the PC using the HDMI cable. Note When the HDMI cable to the PC, ensure that you select HDMI from both the Source List and Edit Name before selecting PC or DVI device so that normal PC screen and sound can be outputted.

  • Page 26: Connecting To Other Devices

    • Turn on both your computer and the LCD Display. • Contact a local SAMSUNG Electronics Service Center to buy optional items. Connecting to Other devices • AV input devices such as DVD players, VCRs or camcorders as well as your computer can be connected to the LCD Display.

  • Page 27: Connecting To A Camcorder

    Connecting to a Camcorder Locate the AV output jacks on the camcorder. They are usually found on the side or back of the camcorder. Connect a set of audio cables between the AUDIO OUTPUT jacks on the camcorder and the [AV/COMPONENT AUDIO IN [R-AUDIO-L]] on the LCD Display . Connect a video cable between the VIDEO OUTPUT jack on the camcorder and the [AV IN [VIDEO]] on the LCD Display .

  • Page 28: Connecting Using A Dvi Cable

    Select BNC for the Camcorder connection using the SOURCE button on the front of the LCD Display or on the remote control. Connecting Using a DVI Cable Connect between the [DVI OUT] port on the LCD Display and the input port on another monitor using a DVI cable.

  • Page 29: Connecting Using A Dvi To Hdmi Cable

    Note In HDMI mode, only PCM format audio is supported. Connecting Using a DVI to HDMI Cable Connect the DVI output terminal of a digital output device to the [HDMI IN] terminal of the LCD Display using a DVI to HDMI cable. Connect the red and white jacks of an RCA to stereo (for PC) cable to the same colored audio output terminals of the digital output device, and connect the opposite jack to the [DVI / RGB /HDMI AUDIO IN] terminal of the LCD Display.

  • Page 30: Connecting A Dtv Set Top (Cable/Satellite) Box

    Connect a Component cable between the [BNC/COMPONENT IN [R/Y, G/P port on the LCD Display and the P Note • Select Component for the connection to a DVD player using the SOURCE button on the front of the LCD Display or on the remote control. •...

  • Page 31: Connecting To An Audio System

    Connections Connecting to an Audio System Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and [AUDIO OUT] on LCD Display.

  • Page 32: Using The Software

    Prepare a blank disk and download the driver program file at the Internet web site shown here. Internet web site : http://www.samsung.com/ Installing the Monitor Driver (Automatic) Insert CD into the CD-ROM drive. Click "Windows". Choose your monitor model in the model list, then click the "OK" button.

  • Page 33: Installing The Monitor Driver (Manual)

    Note This monitor driver is certified by Microsoft, and installing it will not damage your system. The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/ Installing the Monitor Driver (Manual) ® Microsoft Windows Vista™‚ Operating System Insert your Manual CD into your CD-ROM drive.
  • Page 34 This monitor driver is under certifying MS logo, and this installation will not damage your system. The certified driver will be posted on Samsung Monitor homepage. Click "Update Driver..." in the "Driver" tab. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer".
  • Page 35 Select the model that matches your monitor from the list of monitor models on the screen, and click "Next". 10. Click "Close" → "Close" → "OK" → "OK" on the following screens displayed in sequence. ® ® Microsoft Windows XP Operating System...
  • Page 36 Insert CD into the CD-ROM drive. Click "Start" → "Control Panel", then click the "Appearance and Themes" icon. Click "Display" icon and choose the "Settings" tab then click "Advanced...". Click the "Properties" button on the "Monitor" tab and select "Driver" tab. Click "Update Driver..."...
  • Page 37 Then click "OK" button. Note This monitor driver is certified by Microsoft,, and this installation will not damage your system. The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/ Click the "Close" button, then click the "OK" button continually.
  • Page 38 10. Monitor driver installation is completed. ® ® Microsoft Windows 2000 Operating System When you can see "Digital Signature Not Found" on your monitor, follow these steps. Choose "OK" button on the "Insert disk" window. Click the "Browse" button on the "File Needed" window. Choose A:(D:\Driver), then click the "Open"...
  • Page 39 Select the "Monitor" tab. Click the "Change" button in the "Monitor Type" area. Choose "Specify the location of the driver". Choose "Display a list of all the driver in a specific location...", then click "Next" button. Click the "Have Disk" button. Specify A:\(D:\driver), then click "OK"...

  • Page 40: Installation Problems

    10. You have finished setting up your monitor. Execute X-Window after setting other re- quested hardware. MDC (Multi-Display Control) Installation Insert the installation CD into the CD-ROM drive. Click the MDC installation file. Note If the popup window to install the software for the main screen is not displayed, proceed with the installation using the MDC executable file on the CD.
  • Page 41 Using the Software Using MDC...

  • Page 42: Main Screen

    Therefore, a serial cable should be connected between the serial port on a PC and the serial port on a display. Main Screen Click Start > Program > Samsung > MDC System to start the program. Select a set to see the volume of the selected set within the slider.

  • Page 43: Port Selection

    Main Icons Remocon Safety Lock Port Selection 1. Use the main icons to switch into each screen. 2. Allows you to enable or disable the remote control signal receiving function of the display unit. 3. Set the Safety Lock function. When setting the Lock function, you can only operate power and lock buttons on the remote control and set.

  • Page 44: Power Control

    1. The Multiple Display Control is originally set to COM1. 2. If any port other than COM1 is used, COM1 through COM4 can be selected in the Port Selection Menu. 3. If the exact port name that is connected to the LCD Display using a serial cable is not selected, communication will be unavailable.
  • Page 45 Info Grid shows some basic information necessary to Power Control. (Power Status) 2) Input 3) Image Size 4) On Timer 5) Off Timer 2. Use the Select All button or Check Box to choose a display to control.

  • Page 46: Input Source

    Power Control allows controlling some of the functions of the selected display. 1) Power On/Off - Turns the power of the selected display On/Off. 2) Volume - Controls the volume level of the selected display. It receives the volume value of the selected display from the sets and displays it in the slider. (When you cancel the selection or choose Select All, the value returns to the default value 10) (Mute On/Off) - Turns on/off the Mute function of the selected display.
  • Page 47 • PC Mode...
  • Page 48 Info Grid shows some basic information necessary to Input Source Control. - Changes the Input Source of the selected display to PC. - Changes the Input Source of the selected display to BNC. - Changes the Input Source of the selected display to DVI. - Changes the Input Source of the selected display to TV.

  • Page 49: Image Size

    The Input Source Control feature is available only for the displays whose power status is ON. Image Size PC, BNC, DVI 1. Click Image Size of the main icons and the Image Size control screen appears. Info Grid shows some basic information necessary to Image Size Control. ( Power Status) - Shows the power status of the current display.
  • Page 50 Image Size TV, AV, S-Video, Component, DVI(HDCP), HDMI, DTV 1. Click Image Size of the main icons and the Image Size control screen appears. Info Grid shows some basic information necessary to Image Size Control. 1) Click the Video Source tab to adjust Image Size for TV, AV, S-Video, Component, DVI(HDCP), HDMI, DTV. Click Select All or use Check Box to select a display to control.
  • Page 51 1. Click Time of the main icons and the Time Control screen appears. Info Grid shows some basic information necessary to Time Control. 1) Current Time - Set the current time for the selected display (PC Time). - To change the current time, first change the PC Time. 2) On Time Setup - Set the Hour, Minute, AM/PM of On Time Setup, Status, Source, Volume of the selected display.

  • Page 52: Pip Size

    PIP Size 1. Click PIP of the main icons and the PIP control screen appears. Click Select All or use Check Box to select a display to control. Info Grid shows some basic information necessary to PIP Size Control. 1) PIP Size - Shows the current PIP Size of the display in use.

  • Page 53: Pip Source

    PIP Source 1. Click PIP of the main icons and the PIP control screen appears. Info Grid shows some basic information necessary to PIP Source Control. 1) PIP Source - PIP Source can be controlled with turning on the LCD Display power. 2) PC - Changes the source of the PIP of the selected display to PC.
  • Page 54 Settings Picture 1. Click Settings of the main icons and the Settings Control screen appears. Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value of the selected function is displayed in the slide.When selected, each function fetches the value for the set and displays it on the slide bar.

  • Page 55: Picture Pc

    - Adjusts the Color Tone for the selected display. 8) Color Temp - Adjusts the Color Temp for the selected display. 9) Brightness Sensor - Adjusts the Brightness Sensor for the selected display. 10) Dynamic Contrast - Adjusts the Dynamic Contrast for the selected display. The Input source of MagicInfo works only on MagicInfo model.
  • Page 56 2) Contrast - Adjusts Contrast of the selected display. 3) Brightness - Adjusts Brightness for the selected display. 4) Red - Adjusts red Color of the selected display. - Available only for NT. 5) Green - Adjusts green Color of the selected display. - Available only for NT.
  • Page 57 Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value of the selected function is displayed in the slide. When selected, each function fetches the value for the set and displays it on the slide bar. When "Select All" is chosen, the default value is displayed. Changing a value in this screen will automatically change the mode to "CUSTOM."...

  • Page 58: Image Lock

    Image Lock 1. Click Settings of the main icons and the Settings Control screen appears. Info Grid shows some basic information necessary to Settings Control. 1) Image Lock - Available only for PC, BNC. 2) Coarse - Adjusts Coarse of the selected display. 3) Fine - Adjusts Fine of the selected display.
  • Page 59 An "Info Grid" showing several basic data items appears. 1) Maintenance - Allows the Maintenance Control function for all input sources. 2) Auto Lamp Control - Automatically adjusts the backlight of the selected display at a specified time. The Manual Lamp Control automatically turns off if you adjust using the Auto Lamp Control. 3) Manual Lamp Control - Allows you to adjust the backlight of the selected display regardless of the time.

  • Page 60: Video Wall

    1) Scroll - This function is used to remove the afterimages that occur when a still screen is displayed on the selected display for a long time. 2) Pixel Shift - This allows the screen to be moved finely at the specified time interval. 3) Safety Screen - The Safety Screen function is used to prevent afterimages from occurring when a still screen is displayed on the monitor for a long time.
  • Page 61 Select a display from Display Selection. The place will be set up by pressing a number in the selected mode. The MDC program supplied by Samsung supports up to 5x5 LCD Displayes. 3) On / Off - Turns on/off the Video Wall function of the selected display.

  • Page 62: Troubleshooting

    You may not operate this function in MagicInfo. The Input source of TV works only on TV model. The Maintenance Control function is available only for the displays where the power status is ON. Troubleshooting 1. The display you wish to control does not appear on the Power Control Info Grid - Check the connection of RS232C.
  • Page 63 2. Selected one display: Fetches and displays the settings value for the selected display. 3. Selected one display (ID1) and add another display (ID3): The program, which was displaying the settings value of ID 1, fetches and displays the value of ID3. 4.

  • Page 64: Adjusting The Lcd Display

    Adjusting the LCD Display Input Available Modes • PC / DVI / BNC • • Component • HDMI • MagicInfo Note • MagicInfo can only be enabled when a network box is connected. • The HDMI port and network box cannot be connected at the same time. Source List MENU →...
  • Page 65 Note Available Modes: PIP ON Note The PIP function is not available when Video Wall is On. When external AV devices such as VCRs or DVDs are connected to the LCD Display , PIP allows you to watch video from those devices in a small window super-imposed on the PC Video signal.
  • Page 66 • PC : DVI / AV / Component / HDMI • BNC : DVI / AV / HDMI • DVI / AV : PC / BNC • Component : PC • HDMI : PC / BNC Swap MENU → ENTER → Swaps the contents of the PIP and main image.
  • Page 67 Changes the Position of the PIP window. Transparency MENU → ENTER → → ENTER → Adjusts the Transparency of PIP windows. • High • Medium • • Opaque Note • PIP turns off when the LCD Display is switched to an external source. •...
  • Page 68 are common signals for AV and PC, make sure to set the Edit Name in accordance with the input signal. • The Picture menu changes depending on the input signal and Edit Name. Picture [PC / DVI / BNC / MagicInfo Mode] Available Modes •...
  • Page 69 For documents or works involving heavy text. Custom Although the values are carefully chosen by our engineers, the pre-configured values may not be comfortable to your eyes depending on your taste. If this is the case, adjust the brightness and contrast by using the OSD menu. Custom By using the on-screen menus, the contrast and brightness can be changed to your personal preference.
  • Page 70 → ENTER → The color tones can be changed. (Not available when Dynamic Contrast is set to On.) Cool Normal Warm Custom Note If you set the Color Tone to Cool, Normal, Warm, or Custom, the Color Temp. function is disabled.
  • Page 71 → , → ENTER Blue MENU → → ENTER → → ENTER → → , → ENTER Color Temp. MENU → → ENTER → → , → ENTER Color Temp. is a measure of the 'warmth' of the image colors. (Not available when Dynamic Contrast is set to On.) Note This function is only enabled if the Color Tone is set to Off.
  • Page 72 → , → ENTER Removes noise such as horizontal stripes. If the noise persists even after Fine tuning, repeat it after adjusting the frequency (clock speed). Position MENU → → ENTER → → ENTER → → → ENTER → Adjusts the screen location horizontally and vertically. Auto Adjustment MENU →...
  • Page 73 → ENTER → Selects either On or Off with the signal control. Signal Control MENU → → ENTER → → ENTER → → R-Gain MENU → → ENTER → → , → ENTER G-Gain MENU → → ENTER → → , →...
  • Page 74 MENU → → ENTER → → → , → ENTER Size MENU → → ENTER → → ENTER → The Size can be switched. 16:9 HDMI Black Level MENU → → ENTER → → ENTER → When watching with a DVD or set-top box connecting to the product via HDMI or DVI, image quality deterioration (black level, lower-quality contrast, lighter color tone, etc.) may occur depending on the connected external device.
  • Page 75 PIP Picture MENU → → ENTER → → ENTER → Adjusts the PIP Screen Settings. Note • Available Modes: PIP ON Contrast MENU → → ENTER → → ENTER→ → → , → ENTER Adjusts the Contrast of the PIP window on the screen. Brightness MENU →...
  • Page 76 Note This function is not available if PC signal is received while in DVI or HDMI mode. Tint MENU → → ENTER → → → → → → ENTER → → → , → ENTER Adds a natural tone to the PIP window. Note This function is not available if PC signal is received while in DVI or HDMI mode.

  • Page 77: Brightness Sensor

    Brightness Sensor MENU → → ENTER → ENTER → → ENTER → Brightness Sensor automatically detects distribution of the inputted visual signal and adjusts to create optimum brightness. Picture [ AV / HDMI / Component Mode] Available Modes • PC / DVI / BNC •...
  • Page 78 Dynamic, Standard, Movie, or Custom can be activated. (Not available when Dynamic Contrast is set to On.) Dynamic Standard Movie Custom Custom By using the on-screen menus, the contrast and brightness can be changed to your personal preference. MENU → →...
  • Page 79 → , → ENTER Adjusts the picture Color. Tint MENU → → ENTER → → → , → ENTER Adds a natural tone to the display. Color Tone MENU → → ENTER → → ENTER → The color tones can be changed. The individual Color components are also user adjustable. (Not available when Dynamic Contrast is set to On.) Cool2 Cool1...

  • Page 80: Digital Nr (Digital Noise Reduction)

    (Not available when Dynamic Contrast is set to On.) Note This function is only enabled if the Color Tone is set to Off. Size MENU → → ENTER → → ENTER → The Size can be switched. 16:9: Sets the picture to 16:9 wide mode. Zoom 1: Magnifies the size of the picture on the screen.
  • Page 81 Note Digital NR function is not available for all resolutions. HDMI Black Level MENU → → ENTER → → ENTER → When a DVD or set-top box is connected to your TV via HDMI or DVI, it may cause a deg- radation in the screen quality, such as an increase in the black level, a low contrast, or discoloration, etc., depending on the external device connected.
  • Page 82 PIP Picture MENU → → ENTER → → ENTER → Adjusts the PIP Screen Settings. Note • Available Modes: PIP ON Contrast MENU → → ENTER → → ENTER→ → , → ENTER Adjusts the Contrast of the PIP window on the screen. Brightness MENU →...
  • Page 83 → ENTER → Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to create an optimum contrast. (Disabled when PIP is set to On.) Lamp Control MENU → → ENTER → → → , → ENTER Adjusts the inverter lamp in order to reduce energy consumption. Note This function does not operate when Dynamic Contrast is set to On in PC, DVI, AV, HDMI, Component or MagicInfo modes.
  • Page 84 Auto Motion Plus 120Hz MENU → → ENTER → [Picture] → ENTER → [Auto Motion Plus 120Hz] → ENTER → This feature can be used to view fast moving scenes. Mode MENU → → ENTER → [Picture] → → ENTER → [Auto Motion Plus 120Hz] → ENTER → [Mode] →...

  • Page 85: Available Modes

    Judder : use to reduce the judder as much as you want. Note Only activated when Mode is set to Custom. Sound Available Modes • PC / DVI / BNC • • Component • HDMI • MagicInfo Note • MagicInfo can only be enabled when a network box is connected. •...
  • Page 86 Selects Custom if you want to adjust the settings according to your personal preferences. Custom The sound settings can be adjusted to suit your personal preferences. MENU → → → ENTER → Note • You can hear the sound even when sound value is set to 0. •...
  • Page 87 Reduces the difference in volume control between broadcasters. SRS TS XT MENU → → → ENTER → → ENTER → SRS TS XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers. TruSurround XT delivers a compelling, virtual surround sound experience through any two-speaker playback system, including internal television speakers.
  • Page 88 → ENTER → When you use the product with it connecting to a Home theater, turn the Internal speakers off so you can listen to sound from the Home theater's (external) speakers. Internal Sound is outputted both from the Internal speaker and the External speakers, but the volume control is only available from the Internal speaker.
  • Page 89 You can choose one of 13 languages. Note The language chosen affects only the language of the OSD. It has no effect on any software running on the computer. Time Selects from one of 4 time settings, Clock Set, Sleep Timer, On Timer, and Off Timer. MENU →...
  • Page 90 On Timer MENU → → → → ENTER → → ENTER → Turns the LCD Display on automatically at a preset time. Controls the mode and the volume level at the time the LCD Display turns on automatically. Off Timer MENU →...
  • Page 91 High Medium Opaque Safety Lock Change PIN MENU → → → → ENTER → → → [0∼9] → [0∼9] → [0∼9] → [0∼9] The password can be changed. Note The preset password for the LCD Display is "0000". Lock On MENU →...
  • Page 92 → ENTER → This feature adjusts the power consumption of the unit in order to save energy. Video Wall A Video Wall is a set of video screens connected together, so that each screen shows a part of the whole picture or where the same picture is repeated on each screen. When the Video Wall is on, you can adjust the Video Wall screen setting.
  • Page 93 The Format can be selected to see a divided screen. Full Provides a full screen without any margins. Natural Displays a natural image with the original aspect ratio intact. Horizontal MENU → → → → ENTER → → ENTER → →...
  • Page 94 The screen can be divided into several images. A number of screens can be selected with a different layout when dividing. • Select a mode in Screen Divider. • Select a display in Display Selection. • The selection will be set up by pressing a number in the selected mode. Safety Screen The Safety Screen function is used to prevent afterimages that may appear when a still picture is displayed on the screen over a long time.
  • Page 95 Sets how many pixels the screen moves horizontally. Five adjustment levels: 0, 1, 2, 3, and 4. Vertical MENU → → → → ENTER → → ENTER → Sets how many pixels the screen moves vertically. Five adjustment levels: 0, 1, 2, 3, and 4. Time MENU →...
  • Page 96 You can set the timer for Screen Burn Protection. If you start the operation to erase any residual image, the operation will be performed for the set period of time and then automatically finish. Mode MENU → → → → ENTER → →...
  • Page 97 Time MENU → → → → ENTER → → → ENTER → Within the set period of time specify a time for execution. • Mode-Scroll : 1~5 sec • Mode-Bar, Eraser : 10~50 sec Scroll MENU → → → → ENTER → →...
  • Page 98 Eraser MENU → → → → ENTER → → This function prevents after-images on the screen by moving a rectangular pattern. Side Gray MENU → → → → ENTER → → → ENTER → Select the brightness of the grey for the screen background. Light Dark Resolution Select...
  • Page 99 Note Available in PC mode only 1024 X 768 1280 X 768 1360 x 768 1366 X 768 Note Selecting the menu is only allowed when the graphics resolution is set to 1024 x 768 @ 60Hz, 1280 x 768 @ 60Hz, 1360 x 768 @ 60Hz or 1366 x 768 @ 60Hz. Power On Adjustment MENU →...
  • Page 100 Landscape Portrait Reset Reverts the product settings to factory defaults. The Reset function is only available when PC / DVI is being used. MENU → → → → ENTER → → ENTER → Image Reset MENU → → → → ENTER → →...

  • Page 101: Multi Control

    • Component • HDMI • MagicInfo Note • MagicInfo can only be enabled when a network box is connected. • The HDMI port and network box cannot be connected at the same time. Multi Control Assigns an individual ID to the SET. MENU →...
  • Page 102 Note • The remote control can be used to select MagicInfo. However, it is recommended to use a separate USB keyboard to utilize MagicInfo fully. • For MagicInfo in Device mode, moving external devices while booting may cause errors. Set up external devices only if the LCD Display turns on. •...
  • Page 103 Adjusting the LCD Display You can select an Application to be executed in your computer when Windows starts. 2. Select TCP/IP - step 2 In step 2 of MagicInfo Setup Wizard, you don’t have to go to Network Setting on the desktop to make your settings for TCP/IP.
  • Page 104 Adjusting the LCD Display When using multiple languages, you can choose and set a specific language among them. 4. Select Screen Type - step 4 You can select which rotation type will be applied to your device. 5. Setup Information...
  • Page 105 Adjusting the LCD Display Shows the settings that have been selected by the user. Note If the MagicInfo icon is not displayed on the notification area, double click the MagicInfo icon on the window desktop. The icon will appear.

  • Page 106: Troubleshooting

    Troubleshooting Self-Test Feature Check Note Check the following items yourself before calling for assistance. Contact a Service Center for problems that you cannot solve by yourself. Self-Test Feature Check Turn off both your computer and the LCD Display. Unplug the video cable from the back of the computer. Turn on the LCD Display.

  • Page 107: Symptoms And Recommended Actions

    2) Maintaining the Flat Panel Display Screen. Clean with a soft cloth (cotton flannel). Symptoms and Recommended Actions Note A LCD Display recreates visual signals received from the computer. Therefore, if there is a problem with the computer or the video card, this can cause the LCD Display to become blank, have poor coloring, become noisy, etc.

  • Page 108: Problems Related To The Screen

    Check if the signal cable between the computer and the LCD Display is securely con- nected. (Refer to Connecting a Computer) Problems related to the Screen Note Problems related to the LCD Display screen and their solutions are listed. The screen is blank and the power indicator is off. Ensure that the power cord is firmly connected and the LCD Display is on.

  • Page 109: Problems Related To Audio

    The screen color is inconsistent. Adjust color using Custom under OSD Color Adjustment menu. The color image is distorted by dark shadows. Adjust color using Custom under OSD Color Adjustment menu. The color white is poor. Adjust color using Custom under OSD Color Adjustment menu. The Power Indicator blinks.
  • Page 110 Check if the batteries are empty. Check if the power is on. Check if the power cord is securely connected. Check if a special fluorescent or neon lamp is on in the vicinity. Q & A How can I change the frequency? The frequency can be changed by reconfiguring the video card.
  • Page 111 Troubleshooting Note Before calling for assistance, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the In- formation section or contact your dealer.

  • Page 112: Specifications

    15pin-to-15pin D-sub cable, Detachable DVI-D to DVI-D connector, Detachable Dimensions (W x H x D) / Weight 1554.0 x 924.0 x 138.0 mm / 61.2 x 36.4 x 5.4 inch (Without Stand) SyncMaster 650MP, 650FP 30 ~ 81 kHz 50 ~ 85 Hz...
  • Page 113 Dimensions (W x H x D) / Weight 1554.0 x 1029.0 x 500.0 mm / 61.2 x 40.5 x 19.7 inch (With Stand) / 69.0 Kg / 152.1 VESA Mounting Interface 800 x 400 mm Environmental considerations Operating Storage Plug and Play Capability This LCD Display can be installed on any Plug &...

  • Page 114: Preset Timing Modes

    Preset Timing Modes If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.
  • Page 115 Specifications called the Vertical Frequency or Refresh Rate. Unit:...

  • Page 116: For A Better Display

    Information For a Better Display Adjust the computer resolution and screen injection rate (refresh rate) on the computer as described below to enjoy the best picture quality. You can have an uneven picture quality on screen if the best picture quality is not provided for TFT- LCD.
  • Page 117 Power Off, Screen Saver, or Power Save Mode • Turn the power off for 4 hours after 20 hours in use • Turn the power off for 2 hours after 12 hours in use • Set the Monitor to power off with the PC Display Properties Power Scheme. •...

  • Page 118: Select Method

    • Avoid using a combination of characters and background color with large dif- ference in luminance. Avoid using Grey colors, which can cause Image retention easily. Avoid: Colors with big difference in luminance (Black & White, Grey) Change the characters color periodically •...
  • Page 119 • Time Period : 1 ~ 5 seconds ( Recommend : 5 ) Apply the Screen Pixel function on Product • Apply the Screen Pixel function - Symptom: Dot with Black Color move up and down. - Select method • Instruction Guide : OSD Menu ->...
  • Page 120 • Time Interval : 1 ~ 10 hours ( Recommend : 1 ) • Time Period : 10 ~ 50 seconds ( Recommend : 50 )
  • Page 121 Appendix Contact SAMSUNG WORLDWIDE Note If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. U.S.A CANADA MEXICO ARGENTINA BRAZIL CHILE COLOMBIA COSTA RICA ECUADOR EL SALVADOR GUATEMALA HONDURAS JAMAICA NICARAGUA PANAMA PUERTO RICO REP.
  • Page 122 0 801 1SAMSUNG (172678) 022 - 607 - 93 - 33 PORTUGAL (7267864) SLOVAKIA 0800-SAMSUNG (726-7864) http://www.samsung.com/sk SPAIN 902 - 1 - SAMSUNG(902 172 678) SWEDEN 0771 726 7864 (SAMSUNG) http://www.samsung.com/se SWITZERLAND 0848 - SAMSUNG (7267864, CHF 0.08/min) 0845 SAMSUNG (7267864)
  • Page 123 010-6475 1880 3698 - 4698 http://www.samsung.com/hk http://www.samsung.com/ hk_en/ 3030 8282 http://www.samsung.com/in 1-800-3000-8282 1800 110011 0800-112-8888 http://www.samsung.com/id 0120-327-527 http://www.samsung.com/jp 1800-88-9999 http://www.samsung.com/my 0800 SAMSUNG(0800 726 http://www.samsung.com/nz 786) 1-800-10-SAMSUNG http://www.samsung.com/ph (726-7864) 1-800-3-SAMSUNG (726-7864) 1-800-8-SAMSUNG (726-7864) 02-5805777 1800-SAMSUNG(726-7864) http://www.samsung.com/sg 1800-29-3232, 02-689-3232 http://www.samsung.com/th 0800-329-999 http://www.samsung.com/tw 1 800 588 889 http://www.samsung.com/vn...

  • Page 124: Correct Disposal

    Vertical Frequency Horizontal Frequency Interlace and Non-Interlace Methods Plug & Play Resolution Correct Disposal Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Eu- rope only (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
  • Page 125 Reproduction in any manner whatsoever without the written permission of Samsung Elec- tronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this ma- terial.
