Summary of Contents for Samsung HB890
- Page 1 To learn more about the Samsung Hospitality Display please visit : www.samsung.com Samsung Electronics Co., Ltd. Head Office (Suwon Korea) 416, Maetan-3Dong, Yongtong-Gu Suwon City, Gyunggi-Do, Korea 443-742...
- Page 2 Advanced Technology of SAMSUNG Hospitality Display...
- Page 4 Highlights display design • Create a sophisticated viewing environment with the HB890 and 690 Series displays are designed especially for premium luxury design of streamlined LED displays 5-star hotel suites. The displays feature a full metal frame • Offer an upgraded guest experience with wireless...
- Page 5 SINC Server Hotel widgets Seperated by Smart Hub Figure 3. Samsung LYNK™ SINC is a well-organized solution for ordering Figure 4. SINC 2.1 includes a library of widgets so users can choose and and serving content to hotel room displays.
- Page 6 Improve the bottom line with energy-efficient equipment for cable operators. features Samsung HB890 and 690 Series offers many features to help busi- nesses save energy and reduce costs. The LED displays are cost-effective because they use less energy, emit less carbon dioxide (CO ) and require less maintenance than conventional hospitality displays.
- Page 7 Samsung HB890 and 690 Series HB890 Connectors 46”/55”/65” • HG46EB890XB • HG55EB890XB • HG65EB890XB 14 15 1. VARIABLE AUDIO OUT 6. HEADPHONE ID 11. DATA 2. VOL-CTRL 7. HDMI IN 3 12. RJ45(LAN) 3. USB 8. RJP 13. SCART 4. DIGITAL AUDIO OUT(OPTICAL) 9.
- Page 8 Samsung HB890 and 690 Series HB690 Connectors 28” 1. VARIABLE AUDIO OUT 2. VOL-CTRL 3. USB 4. HDMI IN 3 5. HDMI IN 2 (DVI) 6. HDMI IN (ARC) 7. ANT IN(SATELLITE) 8. ANT IN(AIR/CABLE) 9. RJP • HG28EB690BB 10. DIGITAL AUDIO OUT(OPTICAL) 11.
-
Page 9: Specifications
Samsung HB890 and 690 Series Specifications EU/CIS HB890 Basic Info Model Name HG46EB890XB HG55EB890XB HG65EB890XB Backlight Inch Display Resolution 1920 x 1080 HD/FHD Ultra Clear Panel Picture Engine 3D HyperReal Engine Dynamic Contrast Ratio Mega Contrast Static Contrast Ratio 5000:1... - Page 10 Samsung HB890 and 690 Series Specifications EU/CIS HB890 Basic Info Model Name HG46EB890XB HG55EB890XB HG65EB890XB Hospitality Plug&Play(Easy Set-up) Music Mode (Imput : PC/AV/Component) Music Mode BackLight on/off Audio Loop in (Headphone extension) RJ 12 / IR Pass Through Power on Status Setting...
- Page 11 Samsung HB890 and 690 Series Specifications EU/CIS HB890 Basic Info Model Name HG46EB890XB HG55EB890XB HG65EB890XB HDMI (Side/Rear) USB (Side/Rear) Component In (Y/Pb/Pr) (Side/Rear) Composite In (AV) (Side/Rear) 1 (Common Use for Component Y) RJ45(LAN) (Side/Rear) Headphone (Side/Rear) Digital Audio Out (Optical) (Side/Rear) RF In (Terrestrial/Cable input) (Side/Rear) Input &...
- Page 12 Samsung HB890 and 690 Series Specifications EU/CIS HB690 Basic Info Model Name HG28EB690BB HG32EB690QB HG40EB690QB HG46EB690QB HG55EB690QB Backlight Inch Display Resolution 1366 x 768 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 HD/FHD Picture Engine HyperReal Engine...
- Page 13 Samsung HB890 and 690 Series Specifications EU/CIS HB690 Basic Info Model Name HG28EB690BB HG32EB690QB HG40EB690QB HG46EB690QB HG55EB690QB Samsung LYNK™ REACH Samsung LYNK™ SINC Compatibility H-Browser Compatibility My channel Hospitality Feature Smoovie Samsung LYNK™ REACH Server Compatibility Sound bar compatibility Samsung LYNK™ DRM...
- Page 14 Samsung HB890 and 690 Series Specifications EU/CIS HB690 Basic Info Model Name HG28EB690BB HG32EB690QB HG40EB690QB HG46EB690QB HG55EB690QB Hospitality Plug&Play (Easy Set-up) Music Mode (Imput : PC/AV/Component) Music Mode BackLight on/off Audio Loop in (Headphone extension) RJ 12 / IR Pass Through...
-
Page 15: For More Information
All data were deemed correct at time of indepen- dent business units: Consumer Electronics (CE), creation. Samsung is not liable for errors or omissions. All brand, product, compris- ing Visual Display, Home Appliances, Printing service names and logos are trademarks and/or registered trademarks of their respective owners and are hereby recognized and acknowledged. - Page 16 • Reduce operating expenses with energy-saving features High-quality displays in guest rooms can contribute to an enjoyable hotel stay. With the elegant design of Samsung Address guest needs and staff requirements HB67x Series slim displays, hoteliers can elevate guests’ with consistent hospitality displays viewing experience.
- Page 17 Internet Protocol (IP) infrastructure is needed. REACH Server Hospitality display Samsung LYNK REACH >Remote control room >Guest room >Software program Logo REACH Server Figure 1. Property can easily customize and managing interface and contents with Samsung LYNK REACH and REACH Server DATA SHEET...
- Page 18 System (CAS) problems. Enhanced functions include a support video on demand (VoD) system. To help ensure Samsung HB67x Series offers many features to help busi- reliability, the technology also supports additions to cable nesses save energy and reduce costs. The LED displays are head-end equipment.
- Page 19 Samsung HB67x Series HB670 Connectors 28” / 32” 1. COMMON INTERFACE 2. HDMI IN 2 (DVI) 3. HDMI IN 1 4. USB 5. ANT IN(AIR/CABLE) 6. HDMI IN 3 (ARC) 7. HEADPHONE OUT 8. RJ12 • HG28EB670BW 9. HEADPHONE ID 10.
- Page 20 Samsung HB67x Series HB673 Connectors 32” 1. COMMON INTERFACE 2. HDMI IN 2 (DVI) 3. HDMI IN 1 4. USB 5. ANT IN(AIR/CABLE) 6. HDMI IN 3 (ARC) 7. HEADPHONE OUT 8. HEADPHONE ID 9. RJP • HG32EB673CW 10. SCART 11.
- Page 21 Samsung HB67x Series HB675 Connectors Connectors 28” 1. COMMON INTERFACE 2. HDMI IN 2 (DVI) 3. HDMI IN 1 4. USB 5. ANT IN (SATELLITE) 6. ANT IN (AIR/CABLE) 7. HDMI IN 3 (ARC) 8. HEADPHONE OUT 9. RJ12 10. HEADPHONE ID •...
- Page 22 Variable Speaker Output 4W (Mono, 8Ω) Smart Hub Apps Photos, Clip & Music Samsung SMART View Web Browser Voice Recognition Samsung TV Apps supported Samsung 3D 3D Converter Smart Phone Remote Support Feature AllShare(Powered by DLNA) AllShare Cast (Screen Mirroring) ConnectShare™...
- Page 23 Energy saving mode (BLU control) Multi code remote control Screwed Remote battery cover Alarm Key Mixed channel list (DVB-T/T2/C/S2, Analog) Samsung LYNK™ REACH My channel Smoovie Samsung LYNK™ REACH Server Compatibility Sound bar compatibility Samsung LYNK™ DRM S/W Clock DATA SHEET...
- Page 24 Samsung HB67x Series Specifications EU/CIS HB670 HB673 Basic Info Model Name HG28EB670BW HG32EB670BW HG39EB670FW HG46EB670FW HG32EB673CW Energy Efficiency Class Eco Sensor HDMI (Side/Rear) USB (Side/Rear) Component In (Y/Pb/Pr) (Side/Rear) Composite In (AV) (Side/Rear) 1 (Common Use for Component Y) Digital Audio Out (Optical)
- Page 25 Samsung HB67x Series Specifications EU/CIS HB675 Basic Info Model Name HG28EB675BB HG32EB675FB HG39EB675FB HG42EB675FB HG46EB675FB Backlight Inch Display Resolution 1366 x 768 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080 HD/FHD Picture Engine HyperReal Engine Dynamic Contrast Ratio...
- Page 26 Basic Info Model Name HG28EB675BB HG32EB675FB HG39EB675FB HG42EB675FB HG46EB675FB My channel Smoovie Samsung LYNK™ REACH Server Compatibility Sound bar compatibility Samsung LYNK™ DRM S/W Clock HDMI (Side/Rear) USB (Side/Rear) Component In (Y/Pb/Pr) Composite In (AV) (Side/Rear) 1 (Common Use for Component Y)
- Page 27 All data were deemed correct at time of indepen- dent business units: Consumer Electronics (CE), creation. Samsung is not liable for errors or omissions. All brand, product, compris- ing Visual Display, Home Appliances, Printing service names and logos are trademarks and/or registered trademarks of their respective owners and are hereby recognized and acknowledged.
- Page 28 Create an enhanced in-room entertainment environment High-quality displays in guest rooms can contribute to an enjoyable hotel stay. With the modern design of Samsung Address guest needs and staff requirements HB460 Series displays, hoteliers can elevate guests’ view- with consistent hospitality displays ing experience.
- Page 29 Internet Protocol (IP) infrastructure is needed. REACH Server Hospitality display Samsung LYNK REACH >Remote control room >Guest room >Software program Logo REACH Server Figure 1. Property can easily customize and managing interface and contents with Samsung LYNK REACH and REACH Server DATA SHEET...
- Page 30 Reinforce controllability over in-room displays with Security Mode* Samsung HB460 Series offers many features to help busi- nesses save energy and reduce costs. The LED displays are Samsung HB460 Series provides the unique and strong cost-effective because they use less energy, emit less carbon hardware controllability with Security Mode.
- Page 31 Samsung HB460 Series HB460 28” Connectors 1. COMMON INTERFACE 2. HDMI IN (DVI) 3. USB 4. ANT IN (AIR/CABLE) 5. HEADPHONE OUT 6. HEADPHONE ID 7. SERVICE • HG28EB460BW 8. COMPONENT / AV IN 32” / 39” Connectors 1. COMMON INTERFACE 2.
- Page 32 10W x 2 Variable Speaker Output Smart Hub Apps Photos, Clip & Music Samsung SMART View Web Browser Voice Recognition Samsung TV Apps supported Samsung 3D 3D Converter Smart Phone Remote Support AllShare(Powered by DLNA) AllShare Cast (Screen Mirroring) Feature ConnectShare™ (USB2.0)
- Page 33 Energy saving mode(BLU control) Multi code remote control Screwed Remote battery cover Alarm Key Mixed channel list (DVB-T/T2/C/S2, Analog) Samsung LYNK™ REACH Samsung LYNK™ SINC Compatibility H-Browser Compatibility My channel Smoovie Samsung LYNK™ REACH Server Compatibility Sound bar compatibility Samsung LYNK™ DRM...
- Page 34 Samsung HB460 Series Specifications EU/CIS HB460 Basic Info Model Name HG28EB460BW HG32EB460GW HG39EB460HW HDMI (Side/Rear) USB (Side/Rear) Component In (Y/Pb/Pr) (Side/Rear) Composite In (AV) (Side/Rear) 1 (Common Use for Component Y) RJ45(LAN) (Side/Rear) Headphone (Side/Rear) Digital Audio Out (Optical) (Side/Rear)
- Page 35 All data were deemed correct at time of indepen- dent business units: Consumer Electronics (CE), creation. Samsung is not liable for errors or omissions. All brand, product, compris- ing Visual Display, Home Appliances, Printing service names and logos are trademarks and/or registered trademarks of their respective owners and are hereby recognized and acknowledged.
