Beghelli BoxLED BL736LED Series Installation Instructions

FLOODLIGHT LED
BoxLED
®
Flood
BL736LED-FL
EACH MODEL NUMBER CONSISTS OF THE FOLLOWING:
SERIES / OPERATION / LUMENS / WATTAGE / DISTRIBUTION /
VOLTAGE / WET LOCATION / WEIGHT / DIMENSION
SERIES: BL736LED
OPERATION: HT (AC ONLY)/0-10V DIMMING
LUMENS: LO (14,000), HO (24,000)
WATTAGE: 150W/230W
DISTRIBUTION: NBD (30° X 40°), WBD(70°),
ASY (70° X 30°)
VOLTAGE: 120-277V; 347V
WET LOCATION: IP66
WEIGHT: 17LBS.
DIMENSION: LENGTH: 426.7MM (16.8")
WIDTH: 414MM (16.3")
HEIGHT: 160MM (6.3")
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
1. Do not let power cords touch hot surfaces.
2. Do not mount near gas or electric heaters.
3. Equipment should be mounted in locations and at heights where unauthorized personnel will not readily subject it to tampering.
4. The use of accessory equipment not recommended by Beluce Canada, may cause an unsafe condition, and will void the warranty.
5. Do not use this equipment for other than its intended purpose.
6. Servicing of this equipment should be performed by qualified service personnel.
SAVE THESE INSTRUCTIONS!
First make sure power is turned off before starting the installation!
1. Attach and secure mounting brackets to surface using appropriate fasteners.
2. Measure, locate fixture's position, and mark locations for the brackets.
3. Secure brackets (hardware supplied by others) as shown on next page.
Fixture will snap in place.
926000503
Beluce Canada Inc., 3900 14th Avenue, Markham, ON L3R 4R3 Tel: (905) 948-9500 Fax: (905) 948-8673
INSTALLATION INSTRUCTIONS
No user serviceable parts. Refer service to a qualified service
technician. Read instructions prior to installing and/or operating
this device. Installation should be performed by a licensed
electrician/installer in accordance with local codes.
1
