When using electrical equipment, basic safety precautions should always be followed including the following:
CAUTION! ALWAYS MAKE SURE THE POWER IS TURNED OFF before starting the installation.
1.
Measure, locate fixture's position, and mark locations for the brackets.
2.
Secure brackets to ceiling as shown below. (HARDWARE BY OTHERS)
3.
Wiring fixture to power supply, shall be performed by a certified electrician, and wired in a manner that
complies with all local and national electrical codes, as well as the manufacturer's wiring diagram.
4.
Proper replacement of a part removed for user manintenance.
Beghelli U.S.A., 3250 Corporate Way, Miramar, Florida, Tel: (800) 726-4316 Tel: (954) 442-6600 Fax: (954) 442-6677
INSTRUCTIONS
IMPORTANT SAFEGUARDS
WIRING
Page 1 of 4
TEMPESTA
PLUS (TA PLUS-LED)
TM
SE UNV
9/16/2019
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Beghelli TEMPESTA PLUS SE
Summary of Contents for Beghelli TEMPESTA PLUS SE
-
Page 1: Important Safeguards
Proper replacement of a part removed for user manintenance. WIRING Beghelli U.S.A., 3250 Corporate Way, Miramar, Florida, Tel: (800) 726-4316 Tel: (954) 442-6600 Fax: (954) 442-6677 Page 1 of 4 9/16/2019... - Page 2 Install back plate on the wall at designated location (hard- twist to release lock (repeat ware by others). for 3 other clips). Beghelli U.S.A., 3250 Corporate Way, Miramar, Florida, Tel: (800) 726-4316 Tel: (954) 442-6600 Fax: (954) 442-6677 Page 2 of 4 9/16/2019...
- Page 3 MOUNTING POSITIONS WALL MOUNT LED POSITION CEILING MOUNT LED POSITION Beghelli U.S.A., 3250 Corporate Way, Miramar, Florida, Tel: (800) 726-4316 Tel: (954) 442-6600 Fax: (954) 442-6677 Page 3 of 4 9/16/2019...
- Page 4 (refer to LED INDICATOR LEGENDS). Beghelli U.S.A., 3250 Corporate Way, Miramar, Florida, Tel: (800) 726-4316 Tel: (954) 442-6600 Fax: (954) 442-6677 Page 4 of 4...
