GENERAL INFORMATION ....................3 System Features ........................ 3 Remote Services Features....................3 GSMVLP-ADT Module Kit ....................4 Installing the GSMVLP-ADT Module ................4 Opening the QuickConnect 3000 Control ................ 4 Mounting the GSMVLP-ADT ................... 4 Programming the GSMVLP-ADT Module ..............5 Using the AlarmNet Direct website .................
The GSMVLP-ADT is an optional communication module intended for use with ADT 3000 control panels, and provides wireless communication with the ADT network for delivery of alarm and other messages to the monitoring central station. The GSMVLP-ADT cellular communication module transmits signals via the GSM cellular network, using GPRS, and forwards them to your Central Station.
Page 4
1. Disconnect power from the control, including the battery, BEFORE installing the GSMVLP-ADT module. 2. CAUTION: ESD SENSITIVE DEVICE. To discharge any static buildup, briefly touch a chassis ground point before installing this module. Avoid performing this installation while standing on a carpeted floor.
Page 5
Figure 3 – Installing the GSMVLP-ADT Module Install the control in accordance with the ADT QuickConnect 3000 Installation Instructions. Install the GSMVLP-ADT into the control’s back case and secure it with the three provided screws. Refer to Figure 3. For best radio performance, the wires, ECP/power cable and shielded audio cable must be routed as shown in Figure 4.
CS2 Port (0-65535) Access Point Name (APN 2) (roch, aurora, kc) Primary Subsystem Number (two-digit number) Primary Group Number (three-digit number) Primary Subscriber ID (four-digit number) 10. After programming is complete, you must transfer the data to the GSMVLP-ADT. – 6 –...
Page 7
After the GSMVLP-ADT has been installed in the ADT QuickConnect 3000, connect the 7720P Programming Tool as shown in Figure 5. The GSMVLP-ADT powers the 7720P Programming Tool via the programming jack. Each key of the 7720P has two possible functions: a normal function and a Shift function.
Refer to Table 2 for GSMVL-ADT programming and follow the prompts. Press the [ENTER] key to begin programming. Access to Prog NOTE: The ADT monitoring center can remotely block access to local device Mode Denied programming. If this has been done, the following prompt appears: Table 2 –...
Page 9
If not enabled, go to Prompt 16 "CS1 IP" prompt. This address must be programmed if using [01-30] RIS Event Addr RIS Event Reporting. For the Lynx Plus and (12) ADT Safewatch QuickConnect 3000 panel, the address must be 04. – 9 –...
Page 10
PROMPTS ENTRY OPTIONS DESCRIPTION 12-digit RIS Event IP1 Enter the 4-part address of the primary IP Address: 255.255.255.255_ RIS event server. xxx xxx xxx xxx Enter the internet port of the primary RIS [0-65535] Event Port1 event server. (443)_ 12-digit RIS Event IP2 Enter the 4-part address of the secondary IP Address:...
Page 11
(N)_ If not enabled, skip to Prompt 28 [01-30] This address must be programmed if using Keypad Address Remote Access. For the Lynx Plus and ADT (28)_ Safewatch QuickConnect 3000 panel, the address must be 01. • 30 Day The GSMVLP-ADT will send one status Supervision •...
ECP Status Codes The GSMVLP-ADT sends status messages to the control panel to indicate general failures. The control will display “FAULT 103” if any of the events listed below should occur. In addition, the Contact ID codes (listed in Appendix A) for these conditions are sent to the central station by the module.
Description What to do Display GSMVLP-ADT radio not yet Wait for RSSI LEDs to be lit. Cannot Upload initialized. Press [Y]. Try Again? Y/N_ Network problem, or you Initiate the Force Server Update Failed to Update answered "N" to "Cannot Upload command by pressing the [0] key;...
Module Identification Displays MAC Address xxxxxxxxxxxx “xxxxxxxxxxxx” indicates the GSMVLP-ADT's unique MAC CRC yyyy identification number. "yyyy" indicates the MAC CRC number. These numbers are found on the label on the module, as well as the label on the box.
GSMVLP-ADT Status Display Screen 4 Second Site RSSI Secondary GSMVLP-ADT Site RSSI level in dbm. -xxxdbm Press the [space] key to go to the GSMVLP-ADT Status Display Screen 1. Press the [backspace] key to go to the previous field. ECP Mode Displays the mode of operation and system fault status.
Page 16
Pressing [Y] will force the device to upload its entire Update? configuration file to the server. Pressing [N] cancels the operation. NOTE: If the GSMVLP-ADT module is not initialized when you enter this command, the following screen will be displayed: Cannot Upload Try Later! _ Wait for the RSSI LEDs to light, indicating the GSMVLP-ADT module has completed its initialization, and try again.
SUMMARY OF LED OPERATION GSMVLP-ADT Status Display Operation The GSMVLP-ADT Status Display has four LEDs used to indicate message and device status (refer to Figure 5). When installed in the control, the LEDs appear in the following order from top to bottom.
GSMVL-004-V0 Figure 9 – LED Sequence for a Configured GSMVLP-ADT Message Transmission CENTRAL STATION MESSAGES The following messages are sent to the Central Station by the GSMVLP-ADT module for the conditions listed below. Table 4 – GSMVLP-ADT Central Station Messages...
GLOSSARY AES – Advanced Encryption Standard ECP – Enhanced Console Protocol, which is a proprietary communications bus used in Honeywell control panels for wiring additional keypads and peripheral devices; consists of a four-wire data bus (power+/-, data in/out). GPRS – (General Packet Radio Service) GSM –...
