Plug & Play Short
Plug & Play Plus
Wave Wire
MOTORE TUBOLARE CON REGOLAZIONE AUTOMATICA
I
O MANUALE DEL FINECORSA ELETTRONICO
TUBULAR MOTOR WITH AUTOMATIC OR MANUAL
GB
ADJUSTMENT OF THE ELECTRONIC LIMIT SWITCH
ROHRMOTOR MIT AUTOMATISCHER ODER MANUELLER
D
EINSTELLUNG DER ELEKTRONISCHEN ENDLAGEN
MOTEUR TUBULAIRE AVEC RÉGLAGE AUTOMATIQUE OU
F
MANUEL DES FINS DE COURSE ÉLECTRONIQUES
MOTOR TUBULAR CON REGULACIÓN AUTOMÁTICA O
E
MANUAL DEL FIN DE CARRERA ELECTRONICO
ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN
INSTRUCTIONS - INSTRUCCIONES
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CHERUBINI Plug & Play Short
Summary of Contents for CHERUBINI Plug & Play Short
- Page 1 Plug & Play Short Plug & Play Plus Wave Wire MOTORE TUBOLARE CON REGOLAZIONE AUTOMATICA O MANUALE DEL FINECORSA ELETTRONICO TUBULAR MOTOR WITH AUTOMATIC OR MANUAL ADJUSTMENT OF THE ELECTRONIC LIMIT SWITCH ROHRMOTOR MIT AUTOMATISCHER ODER MANUELLER EINSTELLUNG DER ELEKTRONISCHEN ENDLAGEN MOTEUR TUBULAIRE AVEC RÉGLAGE AUTOMATIQUE OU MANUEL DES FINS DE COURSE ÉLECTRONIQUES MOTOR TUBULAR CON REGULACIÓN AUTOMÁTICA O...
-
Page 3: Table Of Contents
TRANSLATION OF THE ORIGINAL INSTRUCTIONS Table of contents: Electrical connections ..................... p. 14 Electrical connections Plug & Play Plus - Wave Wire ..........p. 15 Electrical connections Plug & Play Short ..............p. 15 How to prepare the motor ..................p. 16 Instruction fixing with clamp .............. -
Page 4: Electrical Connections
ELECTRICAL CONNECTIONS - To prevent any danger or malfunction, the size of electrical control components connected to the motor must be compatible with the electrical features of the motor. - Means for disconnection must be incorporated in the fixed wiring in accordance with the national installation standards. -
Page 5: Electrical Connections Plug & Play Plus - Wave Wire
ELECTRICAL CONNECTIONS PLUG & PLAY PLUS - WAVE WIRE 1- brown 2- black 3- blue 4- yellow-green ELECTRICAL CONNECTIONS PLUG & PLAY SHORT 1- brown 2- black 3- blue 4- yellow-green... -
Page 6: How To Prepare The Motor
HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the stop ring nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks. -
Page 7: Instruction Fixing With Clamp
INSTRUCTION FIXING WITH CLAMP The clamp allows to fix the motor directly on the side-cover bolt (Ø 12 mm). The clamp may be used only for motors until maximal torque of 15 Nm. The bolt has to be in aluminum with minimal Ø 11,5 and maximal Ø 11,9 mm. The clamp is supplied pre-assembled with the tightening of the screw on right side, in case should be necessary to tighten the screw on the left side go on as follows:... -
Page 8: Restoring The Original Configuration
RESTORING THE ORIGINAL CONFIGURATION restore original motor 1- brown 2- black configuration perform the procedure 3- blue as described below: 4- yellow-green - Connect both the brown and black motor wires under the same switch, e.g. UP. DOWN - Press the UP button for at least 2 seconds. -
Page 9: Plug & Play Plus - Wave Wire
PLUG & PLAY Plus - WAVE WIRE INSTRUCTION FOR USE IN MANUAL MODE PLUG & PLAY Plus WAVE WIRE In this mode the following devices are optional: The motor Wave Wire is specific for use with a) security locks or stiff fixing springs, cassette awning: the upper limit switch (closing b) fixed or removable stoppers for end slats. -
Page 10: Adjustment Of The Limit Switches With Plug & Play Plus
PLUG & PLAY Plus - WAVE WIRE ADJUSTMENT OF THE LIMIT SWITCHES WITH PLUG & PLAY Plus SETTING THE UPPER LIMIT SWITCH POSITION If the rolling shutter is completely open, you have firstly to drive it down by around 20 cm. Bring the rolling shutter to the opening position using the UP button. -
Page 11: Deletion Of Individual Limit Switch Positions
SETTING THE LOWER LIMIT SWITCH POSITION Bring the awning to the opening position using the DOWN button. Follow the command sequence given in order to save the opening position (DOWN-DOWN-DOWN). DOWN DOWN DOWN DOWN DELETION OF INDIVIDUAL LIMIT SWITCH POSITIONS Deletion of the UPPER limit switch Bring the rolling shutter/awning to the upper limit switch and... -
Page 12: Motor Actions At Limit Switch Stops And Obstacles
After the limit switches have been set, the motors act differently when they reach the mechanical stop or if there is an obstacle. EU DECLARATION OF CONFORMITY CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/35/EU... - Page 13 Note - Bem - Notes - Notas:...
- Page 14 Note - Bem - Notes - Notas:...
- Page 16 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 | Fax +39 030 6872.040 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel.
