CHERUBINI Lumen S-RX Instructions Manual

Solar tubular motor for roller shutters with electronic limit switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LUMEN S-RX
MOTORE TUBOLARE SOLARE PER AVVOLGIBILI
IT
CON FINECORSA ELETTRONICO
SOLAR TUBULAR MOTOR FOR ROLLER SHUTTERS
EN
WITH ELECTRONIC LIMIT SWITCH
SOLARBETRIEBENER ROHRMOTOR FÜR ROLLLÄDEN
DE
MIT ELEKTRONISCHEM ENDANSCHLAG
MOTEUR TUBULAIRE SOLAIRE POUR VOLETS ROULANTS
FR
AVEC FIN DE COURSE ÉLECTRONIQUE
MOTOR SOLAR TUBULAR PARA PERSIANAS ENROLLABLES
ES
CON FIN DE CARRERA ELECTRÓNICO
ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN
INSTRUCTIONS - INSTRUCCIONES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lumen S-RX and is the answer not in the manual?

Questions and answers

Related Manuals for CHERUBINI Lumen S-RX

Summary of Contents for CHERUBINI Lumen S-RX

  • Page 1 LUMEN S-RX MOTORE TUBOLARE SOLARE PER AVVOLGIBILI CON FINECORSA ELETTRONICO SOLAR TUBULAR MOTOR FOR ROLLER SHUTTERS WITH ELECTRONIC LIMIT SWITCH SOLARBETRIEBENER ROHRMOTOR FÜR ROLLLÄDEN MIT ELEKTRONISCHEM ENDANSCHLAG MOTEUR TUBULAIRE SOLAIRE POUR VOLETS ROULANTS AVEC FIN DE COURSE ÉLECTRONIQUE MOTOR SOLAR TUBULAR PARA PERSIANAS ENROLLABLES CON FIN DE CARRERA ELECTRÓNICO...

  • Page 3: Table Of Contents

    TRANSLATION OF THE ORIGINAL INSTRUCTIONS Table of contents: How to prepare the motor ......................p. 29 Photovoltaic panel installation ....................p. 30 Finding the optimal position in the presence of obstacles ..........p. 31 Battery charge status check .....................p. 32 Battery protection function .....................p. 32 Battery pack installation ......................p.

  • Page 4: How To Prepare The Motor

    HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the stop ring nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks.

  • Page 5: Photovoltaic Panel Installation

    PHOTOVOLTAIC PANEL INSTALLATION The photovoltaic panel (A) must be positioned in such a way as to optimise the incidence of the sun’s rays. Correct positioning is essential to ensure high efficiency of the panel and autonomy of the solar motor. The panel is designed to be compatible with all roller shutter boxes and to ensure a constant flow of charge to the battery.

  • Page 6: Finding The Optimal Position In The Presence Of Obstacles

    H < L / 2 In some geographical areas, solar radiation may be significantly reduced at certain times of the year. In such circumstances, the battery can be recharged using a special Cherubini charger sold as an accessory or a compatible model (optional).

  • Page 7: Battery Charge Status Check

    Specifications of the battery charger to be purchased separately as an alternative to the one supplied by Cherubini (24 Vdc, 25 W, 2.1 mm jack). Outside Inside 11 ± 0,5 mm WARNING! If the battery charge is insufficient, the motor slows down considerably and switches to ECO mode, which allows certain operations to be carried out.

  • Page 8: Battery Pack Installation

    BATTERY PACK INSTALLATION • Ensure that the battery, the fastening and the cables don’t touch the surface of the roller blind or the screen. • The power cable must be installed with an upward slope and a drip line. • Clean all drill holes to ensure that the rivets fit properly. •...

  • Page 9: Battery Safety Warnings

    BATTERY SAFETY WARNINGS Cautions: • Use the battery only to power the LUMEN S-RX tubular motor. • Keep the battery away from heat sources and water. • Do not charge or use batteries that have been dropped or damaged. • Do not connect the positive or negative terminals of the battery with metal objects.

  • Page 10: Replacing A Photovoltaic Panel

    REPLACING A PHOTOVOLTAIC PANEL Photovoltaic panels should only be replaced by a professional installer and only with an identical model. The photovoltaic panel must never be disposed of with household waste. • Disconnect the motor cable from the battery • Disconnect the photovoltaic panel from the motor cable •...

  • Page 11: Electrical Connections

    ELECTRICAL CONNECTIONS Photovoltaic panel Cod. A4508_0U25 OPTIONAL ON DEMAND Extension cable Cod. A4508_0U17 - A4508_0U18 24 Vdc power adapter Cod. A4508_0U16 green white black 14.4 Vdc 3.5 Ah Li-ion battery - Cod. A4508_0U24 A4508_0U18 Kit cablaggio Lumen L. 1.500 mm (Pack 10 pz.) A4508_0U17 Kit cablaggio Lumen L.

  • Page 12: Compatible Remote Controls

    COMPATIBLE REMOTE CONTROLS GIRO GIRO Wall stop DOWN down STOP GIRO Lux GIRO P-Lux DISPLAY GIRO Plus DISPLAY Activating the Change channel DISPLAY Change Sun sensor channel Wind sensor Wind sensor is “ON” is “ON” Sun sensor is “ON” Sun sensor is “ON” Change Activating/ Deactivating the Sun sensor Deactivating the Sun sensor...

  • Page 13: Key To Symbols

    KEY TO SYMBOLS GIRO down Press button A Skipper stop Press buttons A and B down at the same time short motor rotation in one direction long motor rotation in other direction double short rotation...

  • Page 14: Command Sequences Example

    COMMAND SEQUENCES EXAMPLE Most of the command sequences have three distinct steps, at the end of which the motor indicates if the step has been concluded positively or not, by turning in different ways. This section is provided to demonstrate the motor indications. The buttons must be pressed as shown in the sequence, without taking more than 4 seconds between one step and the next.
  • Page 15 FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER PLUS - SKIPPER LUX - SKIPPER P-LUX REMOTE CONTROL POP PLUS - POP LUX - POP P-LUX To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).

  • Page 16: Function Open/Close Programming Remote Control

    FUNCTION OPEN/CLOSE PROGRAMMING REMOTE CONTROL SKIPPER - SERIES GIRO - REMOTE CONTROL POP To prevent accidental changes to the programming of the motor during the daily use of the remote control, the possibility of programming is disabled automatically 8 hours after sending the last sequence (A+B or B+C).

  • Page 17: Setting The First Remote Control

    ADJUSTMENT OF THE LIMIT SWITCHES LUMEN S-RX solar motors have an electronic limit switch system with an encoder. This system ensures great reliability and precision in keeping the positions. Limit switch regulation is performed simply with the remote control. During setting, the motor moves only as long as the up or down button is pressed, stopping when the button is released.

  • Page 18: Example 1: Setting First The Opening Position

    EXAMPLE 1: Setting first the opening position SETTING THE OPENING POSITION If the rolling shutter is completely open, you have first to drive it down by around 20 cm. Hold the button A or C pressed and drive the rolling shutter to the opening position. With physical stops: press button A or C until the motor stops automatically.

  • Page 19: Example 2: Setting First The Closing Position

    EXAMPLE 2: Setting first the closing position SETTING THE CLOSING POSITION If the rolling shutter is completely closed, you have first to drive it up by around 20 Hold the button A or C pressed and drive the rolling shutter to the closing position. With lockdown hangers: press buttons A or C until the motor stops automatically.

  • Page 20: Mode 2: Limit Switch Setting (Semi-Automatic)

    MODE 2: LIMIT SWITCH SETTING (semi-automatic) To do the settings in this mode the rolling shutter has to be equipped with lockdown hangers in the closing position, but the rolling shutter does not need to have physical stops in the opening position. This mode of setting is helpful in cases where the factory will set the opening position and the closing position will be set automatically during the normal use.

  • Page 21: Deleting The Middle Position

    SETTING A MIDDLE POSITION This function allows the rolling shutter to be set at a favourite middle position. When this middle position is memorized, you just press the stop button for 2 seconds and automatically the motor will move the shutter to this position. To memorize the middle position, move the rolling shutter to the desired position and then hold the STOP button down (for about 2 sec) until the motor gives confirmation.

  • Page 22: Obstacle Sensitivity Setting

    The LUMEN S-RX motor has the option of changing the obstacle detection sensitivity on three levels. For increased sensitivity select the MAX level, for reduced sensitivity select the MIN level. The LUMEN S-RX motor has MID level selected as the factory setting. 2 sec...

  • Page 23: Deleting The Limit Switch Positions

    DELETING THE LIMIT SWITCH POSITIONS DELETING THE OPENING LIMIT SWITCH To delete only the opening limit switch perform the following steps and proceed with “SETTING THE OPENING POSITION”. Tn: Already programmed remote control Tn (2 sec) DELETING THE CLOSING LIMIT SWITCH To delete only the closing limit switch perform the following steps and proceed with “SETTING THE CLOSING POSITION”.

  • Page 24: Setting Of Additional Remote Controls

    SETTING OF ADDITIONAL REMOTE CONTROLS Up to 15 remote controls can be set. Tn: Already programmed remote control Tx: Additional remote control Tx (2 sec) REMOTE CONTROL MEMORY CLEARING It is possible to delete singly all the memorized remote controls. When the last one is deleted the motor initial condition is restored.

  • Page 25: Full Memory Clearing

    FULL MEMORY CLEARING This full memory clearing does not delete the setting of the limit switch. The full memory clearing can be performed in two ways: 1) WITH THE REMOTE CONTROL Tn: Already programmed remote control Tn (4 sec) 2) WITH BATTERY CONNECTION/DISCONNECTION SEQUENCE Do this operation only in case of emergency, if all remote controls are no longer operating.

  • Page 26: Special Functions

    SPECIAL FUNCTIONS SHORT-TERM SETTING OF A REMOTE CONTROL This function makes it possible to store a remote control temporarily, for example, with the purpose of setting the limit switches during assembly in the factory. A later final saving of the remote control will be possible using the appropriate command sequence (see: “SETTING THE FIRST REMOTE CONTROL”).

  • Page 27: Setting The A530058 Pocket Remote Control

    SETTING THE A530058 POCKET REMOTE CONTROL NB: The new pocket remote control can be set only after programming of a previous remote control as the traditional Cherubini remote controls (Skipper, Giro or POP - 3 buttons Up-Down-Stop remote control). HOW TO PROCEED TO SET THE BUTTON ON THE POCKET REMOTE CONTROL...

  • Page 28: Dichiarazione Di Conformità Ue

    Il testo completo della dichiarazione di conformità UE è disponibile facendone richiesta sul sito: www.cherubini.it. EU DECLARATION OF CONFORMITY CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/53/EU, Directive 2011/65/EU. The full text of the EU declaration of conformity is available upon request at the following website: www.cherubini.it.
  • Page 30 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel. +34 (0) 966 967 504 info@cherubini.es | www.cherubini.es...
