Package content
1x IB-2912MCL-C31, 1x Wall power supply, 1x USB Type-C® to Type-C®
cable, 2x Silicone thermal pads, 2x Aluminium heat sinks, 4x Rubber band,
1x Manual
Front view
1 2 3 4 5
Side view
10
1. LED for operation of the device (blue)
2. LED for operation of the source SSD (blue)
3. LED for operation of the target SSD (blue)
4. LED for clone progress: blinking for clone progress 50-100% (green)
5. LED for clone progress: blinking for clone progress 0-50 % (green)
6. RESET button
7. Button for clone mode confirmation
8. ON / OFF switch of the device
9. USB 3.1 (Gen 2) Type-C® interface to host computer
10. Aluminium cover with integrated 45 mm fan
1 1. Bay for source SSD
12. Mounting clip
13. Power supply interface
14. Bay for target SSD
Manual IB-2912MCL-C31
6 7 8 9
11
12
14
13
