ATO GK3000 Quick Setup Manual

Note: For detailed parameter explanation, please refer to the full manual.
Group P0：
P0.00=0 (V/F control mode, PA group does not need to be set), =1 (Senseless vector control, you need to set the
motor parameter group PA)
P0.01=_ channel selection of frequency given.
0：Analog potentiometer on control panel(single display valid)
1：▲、▼key on control panel (single display valid) Panel digital potentiometer + ▲、▼key on control
panel(double display valid)
2：Digital setting 1, control panel given
3：Digital setting 2, UP/DOWN terminal given
4：Digital setting 3, serial port given
5：VI analog given (VI-GND)
6：CI analog given (CI-GND)
7：Pulse terminal given (PULSE)
8：Combination given (refer to P3.00)
P0.02=_ _Running frequency set，P0.20 lower limit freq.~P0.19upper limit freq.
P0.03=_Running command mode selection
0：Control panel mode
1：Terminal control mode
2：Serial port control mode
P0.04=00 Running direction setting
P0.06=_ _ Max output freq.
P0.07=_ _ Basic running freq.
P0.08= _ _ Max output voltage, rated voltage.
P0.19=_ _ Upper limit freq. , Lower limit freq. ～ Max output freq. P0.06
P0.20=_ _ Lower limit freq.
Group P9：
P9.13
This parameter does not need to be set when the VFD is a single channel display.
When the VFD is dual channel display.
P9.13=0000，Ordinary three-phase asynchronous motor
P9.13=1000，Single-phase asynchronous motor (removing capacitor)
P9.13=2000，Single-phase asynchronous motor (without removing the capacitor)
Group PA (When P0.00=1)：
PA.01=_ _（Motor rated voltage）
PA.02=_ _（Motor rated current）
PA.03=_ _（Motor rated frequency）
PA.04=_ _（Motor rated rotating speed）
PA.05=_ _（Motor poles number 2, 4, 6） ，
