hepco & becker Easyrack 6627590 01 01 Quick Start Manual

For royal enfield himalayan

Advertisement

Quick Links

Easyrack
Artikel Nr.: / Item-no.:
7590
662
01 01
Royal Enfield Himalayan
ab Baujahr 2018 / from date of manufacture 2018
INHALT
CONTENTS
1x
700010247
1x
700010248
1x
700010245
Bei Bestellung eines Aluracks zusätzlich:
1x
799.901HB Alu-Rack
1x
799.902HB TC-Bügel für Alu-Rack
1x
799.903HB Abdeckplatte für Rack
Bei Bestellung eines Easyracks zusätzlich:
1x
700008650 Easyrack
1x
700008647 Abdeckblende links
1x
700008648 Abdeckblende rechts
1x
700010249
4x
Senkschraube M6x35
2x
Zylinderschraube ISK M6x45
2x
Zylinderschraube ISK M8x25
2x
Zylinderschrauben ISK M8x30
4x
Zylinderschraube ISK M6x12
4x
Zylinderschraube ISK M6x20
6x
U-Scheiben ø6,4
4x
U-Scheiben ø8,4
4x
Karosseriescheibe Ø6,4x18
8x
selbstsichernde Muttern M6
2x
selbstsichernde Muttern M8
2x
Aludistanz Ø18xØ9x20mm
4x
Viereck-Scheibe 20x20x ø6,4
1x
Moosgummi 20cm selbstklebend
Easyrack
Alurack
Artikel Nr.: / Item-no.:
655
schwarz/black
Adapterplatte
Stützplatte
Halter
Schraubensatz:
7590
01 01
schwarz/black
1x
700010247
1x
700010248
1x
700010245
When ordering a Alurack:
1x
799.901HB alu-rack
1x
799.902HB bow for Alu-rack
1x
799.903HB plastic cover for rack
When ordering a Easyrack:
1x
700008650 Easyrack
1x
700008647 plastic cover left
1x
700008648 plastic cover right
1x
700010249
4x
2x
2x
2x
4x
4x
6x
4x
4x
8x
2x
2x
4x
1x
Alurack
Adapter plate
Support plate
Holder
Screw kit:
countersunk screw M6x35
allen screw M6x45
allen screw M8x25
allen screw M8x30
allen screw M6x12
allen screw M6x20
washer ø6,4
washer ø8,4
body washer Ø6,4x18
self lock nut M6
self lock nut M8
alu spacer Ø18xØ9x20mm
special washer 20x20x ø6,4
foam rubber 20cm self-adhesive
1
