Summary of Contents for LaMotte WaterLink Spin Touch FF
- Page 1 Instruction Manual Touch WaterLink Code 3587...
-
Page 2: Before First Use
® Connect application for Windows . This application is available for free at http:// ® softwarecenter.lamotte.com/. Via the WaterLink Connect desktop application, results ® from the Spin Touch can be transferred to a water analysis program such as WaterLink ™... - Page 3 ® is capable of connecting to a Bluetooth enabled device, such as a phone or tablet. The Spin Touch is also compatible with a LaMotte Bluetooth Printer [Code 5-0066]. Other Bluetooth printers are not supported. Transferring results over Bluetooth to a mobile device requires that a mobile app is installed on the device and an active account for the associated software program.
- Page 4 5. Wet disks should be dried thoroughly with a lint free wipe. The disk should be handled by the edges. 6. Disks should be fi lled and used within 10 minutes. They cannot be fi lled ahead of time. For fi lling and troubleshooting tips go to: www.lamotte.com/spin_support/...
-
Page 5: General Operating Procedures
GENERAL OPERATING PROCEDURES METER When a fi lled disk is placed in the chamber and the lid is closed, the meter spins at high speed to distribute the sample to the test wells. Next the meter slows to maximize the pumping action of the stainless steel mixing beads as the reagents mix with the sample water. - Page 6 TESTING Water type Fresh Tap to Start Test Disk Series FF103 30-Jan-19 12:14 AM 1. Press and hold until the meter turns on. 2. Tap . Select a Water type. Tap to confi rm. 3. Tap . Select a disk series (found on disk packaging). Tap to confi...
-
Page 7: Test Results
SAVE AND PRINT TEST RESULTS Test results can be saved, transferred to the WaterLink Connect mobile app via Bluetooth, and sent to the Mobile Bluetooth Printer (Code 5-0066). Test Results Test Time 05:30:06 30-Jan-2019 ALK 133 AMMO 0.5 G HARD 77 NITRITE 1.1 pH 5.7 NITRATE 23... -
Page 8: Print Results
Logged results are viewed in Test History. Controls for viewing and managing single or multiple test records are located on the Test History screen. Tap the checkbox next to a test record to select it, then tap one of the buttons along the bottom to perform an action with the selected records. - Page 9 DISK STORAGE Disks are sensitive to moisture. Avoid opening more packs than are needed. Disks have a limited shelf life and should not be exposed to the humidity in the air more than necessary. Store disks at 70-80 °F/21-27 °C. Do not transport the meter with a disk in the chamber.
- Page 10 until the battery is fully charged. When the battery is completely charged, the charging icon will change to the full battery icon. SETTINGS to enter the SETTINGS menu. Tap to return to the test screen at any time. Brightness The brightness level of the display can be adjusted from 00 to 10. Tap to adjust the brightness.
-
Page 11: Fresh Water
RANGES Fresh Water Test Factor Range Display Abbreviation Alkalinity 0-250 ppm Ammonia 0-4.0 ppm AMMO Hardness 0-500 ppm G HARD Nitrate 0-300 ppm NITRATE Nitrite 0-2.0 ppm NITRITE 4.5-10.0 Phosphate 0.0 - 2.0 ppm PHOS Salt Water Test Factor Range Display Abbreviation Alkalinity 0-300 ppm... - Page 12 DISK DESCRIPTIONS Fish Farming Fresh Water Disk Total Low Range Alkalinity Hardness FF104 (Code 4351) Phosphate Nitrite Nitrite Phosphate Nitrate High Range Nitrate Hardness Ammonia Alkalinity Ammonia Range Empty Blank Fish Farming Salt Water Disk Alkalinity Magnesium FF203 (Code 4352) Calcium Nitrite Alkalinity...
-
Page 13: Accessories And Replacement Parts
ACCESSORIES AND REPLACEMENT PARTS Description Code ® ® WaterLink Spin Touch FF Meter Water Sample Bottle (60 mL) 0688 Plastic Beaker, 50 mL 0944 Syringe with tips (3) 1189-3 Syringe tips (3) 1189-TIP Cleaning Tissues 0669 Meter Check Disk 1705 Universal Disk Cover 1719 USB Cable... - Page 14 Operation Humidity Range 0- 90 % RH, non-condensing Communication USB-C, Bluetooth low energy technology (BLE) Calibration Factory set, fi eld calibration via internet connection Firmware Internet updateable (New Test, New Test Calibrations, etc.) Software Android & iOS Apps, WaterLink ® Solutions, WaterLink ®...
-
Page 15: Troubleshooting Guide
Disk type is not an option Software or meter fi rmware is Update WaterLink Connect at in Disk Series out of date. softwarecenter.lamotte.com High pH results Water sample temperature above For water samples over 100 °F 100 °F (38 °C) interferes with pH (38 °C) subtract 0.3 from pH result... - Page 16 Disc not spinning Lid open, meter not powered on, Close lid, power on meter, charge low battery, disk or disk cover the battery or plug meter into a pressed down too tightly on hub stable power source, remove the disk/disk cover and place back in the meter more gently Fast electrical transients may Restart the test to resume normal...
-
Page 17: Alignment Procedure
“Angle Calibration Unsuccessful. Contact Tech Support.” will be displayed. 8. Tap to return to the Testing Menu and resume testing. email: softwaresupport@lamotte.com phone: 800-344-3100 option 3 | Mon-Fri 9am-5pm EST HELPFUL HINTS ¬ Do not touch top or bottom of disk. Handle disk by the edge. -
Page 18: Maintenance
Should it be necessary to return the meter for repair or servicing, pack the meter carefully in a suitable container with adequate packing material. A return authorization number must be obtained from LaMotte Company by calling 800- 344-3100, ext. 3 (US only) or 410-778-3100, ext. 3, faxing 410-778-6394, or emailing softwaresupport@lamotte. -
Page 19: General Information
Safety Data Sheets (SDS) can be found at www.lamotte.com. Additional emergency information for all LaMotte reagents is available 24 hours a day from the National Poison Control Center at 1-800-222-1222 or by contacting the 24 hour emergency line for ChemTel at 1-800-255-3924 (USA, Canada, Puerto Rico). -
Page 20: Warranty
¬ Consult the dealer or an experienced radio/TV technician for help. WARRANTY LaMotte Company warrants this instrument to be free of defects in parts and workmanship for 2 years from the date of shipment. If it should become necessary to return the instrument for service during or beyond the warranty period, contact our Technical Service Department at 1-800-344-3100 or 1-410-778-3100, ext.
