Any personal injury or property loss caused by improper installation, improper debug, unnecessary
repair or not following the instructions of this manual should not be the responsibility of Gree Electric
Appliances, Inc. of Zhuhai.

2 Product Introduction

2.1 Names of Key Components

No.
Name

2.2 Rated Working Condition

—
Rated Cooling
Rated Heating

3 Preparations for Installation

Product graphics are only for reference. Please refer to actual products. Unspecified measure unit is
mm(inch).

3.1 Standard Fittings

Please use the supplied standard fittings listed below as instructed.
No. Name
1 Wired Controller
2 Drain Hose Assembly
3 Union nut
4 Corrugated pipe
5 M10×8 Nut with Washer
①
Air Outlet
Indoor Side Condition
Dry Bulb Temp Wet Bulb Temp
°C(°F)
26.7(80.0)
21.1(70.0)
Appearance
Multi Variable Air Conditioners Ducted Type Indoor Unit
Fig.2.1.1
②
Air-return Opening
Dry Bulb Temp
°C (°F)
19.4(67.0)
15.6(60.0) 8.3(47.0)
Q'ty
1
1
1
1
4
2
③
Drain Pipe
Outdoor Side Condition
Wet Bulb Temp
°C (°F) °C (°F)
35(95.0) 23.9(75.0)
6.1(43.0)
Usage
To control the indoor unit
To connect with the hard PVC drain
pipe
To connect the exit tube
To be used for connecting the
refrigerant pipe
To be used together with the hanger
bolt for installing the unit.
