RAIN BUCKET
ET2000 (400 SERIES) RAIN BUCKET SETUP
8
4
3
2
1
10
1
STOP – The STOP key will stop any currently
running Scheduled watering Cycle, Manual
Cycle, Test Cycle, Manual Special Sequence.
2
MANUAL – The MANUAL key will perform
Manual Water, Test, Master Valve Override and
Manual Special Sequence.
3
NO WATER – The NO WATER key will turn the
controller Off and set No Water Days.
4
? – The ? key is used to access the controller
Help screens.
5
ENGLISH / ESPANOL – The ENGLISH /
ESPANOL key allows you to toggle the displayed
text between English and Spanish.
6
BACK – The BACK key will go back to the
previous screen.
®
7
MAIN MENU – The MAIN MENU key is used to
access the different program features of the
controller.
8
MENU KEYS – MENU keys select the different
features of commands in the different screens
and are adjacent to the left and right side of the
controller's display screen. The text in the screen
will point towards the MENU key that needs to
be pressed.
9
LEFT / RIGHT ARROW KEYS – The LEFT /
RIGHT ARROW keys move the highlighted
cursor around the different screens when setting
up or editing the controller's features and
options.
10
PLUS / MINUS KEYS – The PLUS / MINUS
keys increase or decrease values or answer Yes
or No questions in the different screens.
water work
m aking
RAIN BUCKET SETUP
8
5
6
7
9
since 1986
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Calsense ET2000 400 Series
Summary of Contents for Calsense ET2000 400 Series
- Page 1 RAIN BUCKET SETUP ® RAIN BUCKET ET2000 (400 SERIES) RAIN BUCKET SETUP STOP – The STOP key will stop any currently MAIN MENU – The MAIN MENU key is used to running Scheduled watering Cycle, Manual access the different program features of the Cycle, Test Cycle, Manual Special Sequence.
- Page 2 3 0.10 inches of rain will have to fall before key (Figure 1). any rain data starts to accumulate in the rain table. Maximum Hourly Rain: This setting determines the CALSENSE WATER MANAGEMENT SYSTEM maximum amount of rain that will be put in the rain Programs & Stations Lights table after a period of one (1) hour of rain.
- Page 3 NO, rain will have no effect on irrigation run times for that program. If there is no rain bucket installed and WEATHER SETUP you are not sharing rain data through the Calsense ET Gage Command Center program, these settings will have no effect on irrigation.
- Page 4 NO, rain will have no effect on irrigation run times for (Figure 12). that program. If there is no rain bucket installed and you are not sharing rain data through the Calsense Command Center program, these settings will have no effect on irrigation.
- Page 5 Rain Bucket Budget Wind Gage Moisture Press the REPORTS Menu Rain Switch key (Figure 15). Figure 12 CALSENSE WATER MANAGEMENT SYSTEM Programs & Stations Lights Press the RAIN SWITCH Menu Weather Reports key if you want to activate a Rain Flow Radio Remote Switch.
- Page 6 Rain Bucket wired to the precipitation rate of each station and the amount of controller, or shared, using the Calsense Command usable rain. Usable rain in the Rain Table is Center software, from a controller wired to a rain determined by settings programmed at the Rain bucket.
