#45831 - MANUAL
Read these instructions completely before using this product and retain this owner´s
manual for future reference.
SPECIFICATIONS
Input:
Battery:
No load speed:
Speed settings:
Collet size:
Charge Time:
Speeds:
Weight:
STANDARD EQUIPMENT
Cordless 3.6V Rotary Tool
16 x Sanding Bands & 30 Sanding Discs
20 Cut-Off Wheels, 2 x HSS Cutters,
5 x Drill Bits & 10 x Diamond
Engravers
2 x Steel Brushes, 2 x Nylon Brushes, Rubber
Polishing Point, Felt Tip with Shank, 5 x Felt
Wheels, Felt Tip & Cloth Wheel
10 x Grinding Stones, Whet Stone,
2 x Drum Mandrels, 2 x Screw
Mandrels & Cone Mandrel
USB Cable, 5 x Collets, Spanner, LED Collar & Carry
Case
3.6V
1.5Ah Li-Ion
5.000-18.000 rpm
6
Ø1,6, 2,4, 3,2 mm
3-5 Hours
1-6
0,2 kg
KNOW YOUR PRODUCT
CORDLESS 3.6 ROTARY TOOL
1. Charging Input
2. Battery Status Indicator Light
3. On/Off Button
4. Spindle Lock Button
5. Shaft Collar
6. Collet Nut
7. Variable Speed Controls
SETUP & PREPARATION
1. BATTERY & CHARGER
WARNING!
THE POWER SUPPLY FOR THIS
CHARGER IS RECOMMENDED FOR USE WITH A
RESIDUAL CURRENT DEVICE (RATED AT 30mA OR
LESS).
Battery Charge Indicator
The rotary tool is equipped with a battery status indicator to show the battery charge state. Press
the on/off button and see which LED lights up to gauge the status.
Full Charge
Mid Charge
Low Charge; requires charging soon.
Battery requires immediate charging.

Advertisement

Table of Contents
loading

Summary of Contents for Profi-Partner 45831

  • Page 1 #45831 - MANUAL KNOW YOUR PRODUCT Read these instructions completely before using this product and retain this owner´s CORDLESS 3.6 ROTARY TOOL manual for future reference. 1. Charging Input 2. Battery Status Indicator Light SPECIFICATIONS 3. On/Off Button Input: 3.6V 4.

  • Page 2: Installing Accessories

    Note: The charger cable needs to be removed from the tool to check the Slide the LED collar onto the shaft and turn it clockwise charge state. to tighten it into place. Note: Once connected for charging, the battery status indicator lights will illuminate red and remain so whilst charging.
  • Page 3 Note: Sanding Discs Avoid excessive tightening of the collet nut when no accessory is inserted, as this may cause Materials: timbers, plastics, soft metals, ceramics, stone and the collet to get stuck in the collet nut. If this happens, push the shank of an accessory into the glass.
  • Page 4 HSS Cutters Nylon Brushes Materials: leather, timbers, plastics, soft metals (aluminium, Materials hard plastic, aluminium, silverware, jewellery copper, brass etc.) and clay. High speed cutters can be used for and other precious metals.The nylon brushes are ideal for carving, cutting out grooves, slots and inlays or hollowing out light deburring, general cleaning and polishing jobs.
  • Page 5 6. GRINDING CONTROLS On/Off Button Grinding Stones Materials soft and hard metals (including stainless Press the on/off button to turn the tool on. The steel), ceramic, stone, glass.The aluminium oxide battery charge indicator LEDs will illuminate. grinding stonesare great for cleaning up welded joints,deburring castings, removing rust,cutting rivets, To turn the tool off, press the on/off button sharpening tool blades or just general purpose grinding on...

  • Page 6: Troubleshooting

    Storage 8. SPEED SELECTION Keep in a dry, frost free location, out of reach of children. Note: Eurotops Versand GmbH will not be responsible for any damage or injuries Recommended Speed Settings caused by the repair of the tool by an unauthorised person or by mishandling of the figures listed tool.

  • Page 7: General Power Tool Safety Warnings

    e. Do not overreach. Keep proper footing and balance at all times. This enables better control GENERAL POWER TOOL SAFETY WARNINGS of the power tool in unexpected situations. f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts.
  • Page 8 • After changing the bits or making any adjustments, make sure the collet nut, chuck or any ROTARY TOOL SAFETY WARNINGS other adjustment device are securely tightened. Loose adjustment devices can unexpectedly shift, causing loss of control, loose rotating components will be violently thrown. WARNING! Do not use accessories which are not specifically designed and •...
  • Page 9 • Support panels or any oversized workpiece to minimize the risk of wheel pinching and Hersteller Model Typ ref. NDCRK003602 Shanghai Nova Corporation kickback. Large workpieces tend to sag under their own weight. Supports must be placed under Room 402, Jiangtian Building No.3456 the workpiece near the line of cut and near the edge of the workpiece on both sides of the wheel.
