- Page 1 OWNER'S MANUAL JSJ-2-1/4C Service Jack JET EQUIPMENT & TOOLS, INC. P.O. BOX 1349 253-351-6000 A WMH Company Auburn, WA 98071-1349 Fax 800-274-6840 www.jettools.com e-mail jet@jettools.com M-414558 12/96...
-
Page 2: Replacement Parts
JET’s expense, but if it is determined there is no defect, or that the defect resulted from causes not within the scope of JET’s warranty, then the user must bear the cost of storing and returning the product. This warranty gives you specific legal rights, and you have other rights which vary from state to state. -
Page 3: Specifications
5. Do not get under vehicle while jack is being used as the only support. 6. If jack needs service, contact your local JET distributor for the location of the closest JET Service Station. - Page 4 Assembly Note: For parts identification, refer to parts list. 1. Insert upper handle (36) into lower handle (35) and fasten with hex cap bolt (37). 2. Remove handle bolt (33) and spacer (34). 3. Insert handle assembly into handle socket (38). Make sure handle assembly engages gear shaft (27) by turning handle back and forth and observing movement of handle socket gear (30).
-
Page 5: Troubleshooting
Operating Instructions Important: Sometimes during shipment and handling, air gets into the hydraulic system, causing poor lifting performance. Before initial operation, purge any air from the system by fully opening release (turn handle counter-clockwise). Then, while holding the saddle down, pump handle rapidly several times. - Page 6 Main Body Assembly...
- Page 7 35..00100.........Handle (lower) * ..............1 36..00001.........Handle (upper) * ..............1 37..00817.........Screw * ..................1 38..00200.........Handle Socket................1 * indicates normal stocked part. Other parts may be purchased on a special order basis only. Contact JET Equipment & Tools (1-800-274-6848) for details.
- Page 8 Power Unit Assembly...
- Page 9 28..000316.......Plug Screw ................1 29..000331.......Ball ...................1 30..000317.......Plunger..................1 31..000318.......Spring ..................1 .... JSJ214C-RK......Repair Kit (not shown) * ............1 * indicates normal stocked part. Other parts may be purchased on a special order basis only. Contact JET Equipment & Tools (1-800-274-6848) for details.
