Special Tips; Operation Notice; Separate The Tire Edge - Bosch TCE 260 Operation Manual

6.3

Special tips

1. Special process to be need for some special tires,
which different from the normal demount/ mount
process.
2. Some special rims as figure below, the groove at
the middle of the rim is very shallow. Or there is no
groove. These rims can not meet the safety regulati-
on regarding the traffic and transportation. In some
countries, these types of rim/wheel are not allowed
in the market.
Danger
Pay special attention when demount/ mount tire, the
rim or tire may be damaged.
3. In the process of inflating the tire, the danger of tire
burst may happen.
4. The cross-section shaft of some rims is the smooth
structure as figure below. The C at rim is very deep.
You will find B is higher than A. When you break the
bead of this type of tire, you must press the bead
which must be lower than B position. When mount
the tire, the bead opposite to the tool head must
over B point. At this moment, the bead can be led
into the groove at the middle of the rim.
5. Some wheels have the tire pressure inspect system
as figure below. Do not damage the tire pressure
inspect system when mount/demount tires.
Robert Bosch GmbH
Operation | TCE 260 | 13
6.4

Operation notice

Warning
The following information must be read, which is hel-
pful to operator to simplify operation processes and to
reduce unnecessary troubles.
R
Tips:
To protect the rim, demounting head plastic conver
should changed per two mouth. If damaged, these plas-
tic parts should be changed at once.
Warning
Bead breaking process is very danger, the operator
should operate accordance with the instruction descri-
bed in the manual.
6.5

Separate the tire edge

Before any operation, please detach the weight
attached on the wheel before deflate the tire.
Not using the grease will seriously damage the
tire. Please use the special grease.
1. Check whether the tire has been deflated complete-
ly. If not, you should deflate at first.
en
|
1 987 AT7 374 2015-09-02
