C I R R U S
A I R P L A N E M A I N T E N A N C E M A N U A L
1. DESCRIPTION AND OPERATION
The aft passenger windows are manufactured of acrylic and adhesive bonded to the fuselage. Replace-
ment is accomplished by removing the interior trim around the window, removing the sealant around the
window, and then removing the window from the fuselage. In general, the reverse process is used to install
a replacement window. This method is literally seamless, and the fuselage will show no marks or evidence
of maintenance.
EFFECTIVITY:
All
CABIN
M O D E L S S R 2 2 A N D S R 2 2 T
56-20
Page 1
15 Jun 2010
