ASROCK IMB-385 Jumpers And Headers Setting Manual

*15G06M006000AK*
P/ N: 15G06M006000AK V1.0
IMB-385
The terms HDMI™ and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
1 : 8-pin ATX Power Input Connector
8 5
4 1
2 : 3-Pin CPU FAN Connector (+12V)
GND
+12V
CPU_FAN_SPEED
3 : 4-Pin CPU FAN Connector (+12V)
FAN_SPEED_CONTROL
CPU_FAN_SPEED
+12V
GND
4 : DDR3 DIMM Slots
(DDR3_A1, DDR3_B1)
5 : 24-pin ATX Power Input Connector
12 24
1 13
6 : PWR LOSS Header
Short : Power Loss
Open : no Power Loss
RS-232 Port 4 Pin Headers
7 : COM5
8 : COM6
9 : COM4
10 : COM3
Jumpers and headers setting guide
24.4cm (9.6 in)
35
34
USB 3.0
33
T: USB0
B: USB1
32
USB 2.0
31
T: USB2
B: USB3
30
USB 2.0
29
Top:
T: USB4
RJ-45
B: USB5
28
27
IMB-385
PCIE2
CI1
1
HD_AUDIO1
CI2
1
26 25 24
11 : Digital Input / Output
Pin Header
PIN Signal Name PIN Signal Name
1 SIO_24
3 SIO_25
5 SIO_26
7 SIO_27
9 JGPIO_PWR1 10
12 : Digital Input / Output Power
Selection
1-2 : +12V
2-3 : +5V
13 : Digital Input / Output Default Value
Setting
1-2 : +5V
2-3 : GND
14 : AT/ATX Mode Selection
1-2 : AT mode
2-3 : ATX mode
15 : TPM Header
S_PWRDWN#
+5VSB_ATX
SMB_DATA_MAIN
SMB_CLK_MAIN
1 2 3
CPU_FAN1
CPU_FAN2
BUZZ1
CHA_FAN2
CHA_FAN1
CMOS
CLRCMOS1
64Mb
Battery
1
BIOS
PCIE1
PCI1
Intel
H81
PCI2
LPT1
USB8_9 USB10_11
1
1 1
23 22 21
2 SIO_20
4 SIO_21
6 SIO_22
8 SIO_23
GND
48MHz +5V
GND GND
SERIRQ# +3VSB
LAD0
GND
LAD1 +3V
LAD3
LAD2
PCIRST#
FRAME
GND PCICLK
4
5
PWR_LOSS1 6
1
7
1
1
8
COM5 COM6
9
1
1
10
COM4 COM3
JGPIO1
11
1
12
1 1
13
14
1
TPM1
15
SATA_5
SATA_1
1
PLED PWRBTN
16
1
HDLED RESET
PANEL1
SATA_2 SATA_6
19 18
20 17
16 : System Panel Header
PLED+
PLED-
PWRBTN#
GND
1
DUMMY
RESET#
GND
HDLED-
HDLED+
SATA2 Connectors
SATA_5
17 : SATA_5
18 : SATA_6
SATA_6
SATA3 Connectors
SATA_1
19 : SATA_2
20 : SATA_1
SATA_2
21 : Printer Port Header
AFD#
ERROR#
PINIT#
GND
SLIN#
1
SPD7
SPD6
ACK#
SPD5
BUSY
SPD4
SPD3
SPD2
SPD1
SPD0
STB#
USB2.0 Headers
22 : USB10_11
23 : USB8_9
PE
SLCT
