Schematic diagrams and bill of material
Qty Ref. Part / value
1 U1 ST7540
STM32F103
1 U2
CBT7TR
1 U3 ST3232CTR
USBUF02W
1 U4
6
1 Y1 16MHz
1 Y2 32.768KHz
1 Y3 8MHz
52/56
Table 1. Bill of material (continued)
Voltage /
Tol. %
current
3
ppm/Y
ear
5
ppm/Y
ear
3
ppm/Y
ear
DocID024383 Rev 1
Technology
Watts
information
FSK power line
transceiver
32-bit MCU
3 to 5.5 V, low
power, up to 400
kbps RS-232
drivers and
receivers
EMI filter and
line termination
for USB
upstream ports
UM1619
PA Manufact.
SMD VAC
SMD
ST
HTSSOP28
SMD
ST
LQFP48
SMD
ST
TSSOP16
SMD
ST
SOTT323-6
HC-49 SMD Euroquartz
Citizen
SMD
QD
HC-49 SMD Euroquartz
