Installing to Wall

2
WOOD STUD WALL
Use wall mount (A) as a template, make sure it is level, and mark two mounting holes along the
FHQWHU OLQH RI WKH ZRRG VWXG 'ULOO WZR   PP GLD KROHV   PP GHHS /HYHO ZDOO PRXQW
(A) and attach to wall with two wood screws (H LQWR VWXG FHQWHU 8VH RI DQ HGJH WR HGJH VWXG ¿QGHU
LV KLJKO\ UHFRPPHQGHG 7LJKWHQ VFUHZV ¿UPO\ EXW GR QRW RYHUWLJKWHQ ,QVHUW WZR IDVWHQHU FDSV T) into
wall plate mounting holes.
WARNING
Do not over tighten screws, or damage may occur.
T
A
WALL
PLATE
H
5 of 45
WARNING
Wood screws must
H
center in stud
A
ISSUED: 11-02-09 SHEET #: 095-9302-1
STUD
TOP CUTAWAY VIEW
WOOD
STUD
