Dexing Fiber Labs NDS3542D User Manual

Multi-input modulator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NDS3542D Multi-input Modulator
User's Manual
Web-NMS Version: 1.08 Build 100 Nov 4 2015
Software: 1.30
Hardware:1.04
Chengdu Dexin Digital Technology Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fiber Labs NDS3542D and is the answer not in the manual?

Questions and answers

Related Manuals for Dexing Fiber Labs NDS3542D

Summary of Contents for Dexing Fiber Labs NDS3542D

  • Page 1 NDS3542D Multi-input Modulator User’s Manual Web-NMS Version: 1.08 Build 100 Nov 4 2015 Software: 1.30 Hardware:1.04 Chengdu Dexin Digital Technology Co., Ltd.

  • Page 2: Table Of Contents

    DIRECTORY Chapter 1 Product Outline................1   1.1 Outline........................1  1.2 Features ......................... 1  1.3 Principle Chart......................2  1.4 Technical Specifications ..................2  1.5 Appearance and description..................3  Chapter 2 Installation Guide................5   2.1 Acquisition Check....................5  2.2 Installation Preparation .................... 5  2.3 Wire’s Connection ....................

  • Page 3: Chapter 1 Product Outline

    NDS3542D Multi-input Modulator User’s Manual Chapter 1 Product Outline 1.1 Outline NDS3542D multi-input modulator is DEXIN’s all-in-one device which integrates demodulation, trans-mux and modulation in one case to convert signals into RF output. It is a 1-U case which supports 4 tuner inputs to receive signal from satellite, cable or terrestrial.

  • Page 4: Principle Chart

    NDS3542D Multi-input Modulator User’s Manual 1.3 Principle Chart 1.4 Technical Specifications 4 S/S2 Tuner and 2 ASI input Input Input Frequency 950-2150MHz Symbol rate 1~45Mbauds DVB-S Signal Strength -65~-25dBm Tuner FEC Demodulation 1/2, 2/3, 3/4, 5/6, 7/8 QPSK Section Input Frequency 950-2150MHz Symbol rate QPSK/8PSK: 1~45Mbauds...

  • Page 5: Appearance And Description

    NDS3542D Multi-input Modulator User’s Manual Local interface LCD + control buttons Remote Web NMS management System 2 ASI out(BNC type) Stream Out IP (4*MPTS over UDP) out (RJ45, 1000M) Upgrading Web and USB Dimension 482mm×300mm×44.5mm(W*D*H) Weight 3.7kg Temperature 0~45℃(Operation) ; -20~80℃(Storage) General Power AC 100V±1050/60Hz;...
  • Page 6 NDS3542D Multi-input Modulator User’s Manual Module 1: with 2 CAMs /Smart card slots and 2 RF signal input and loop-through Module 2: with 2 CAMs /Smart card slots and 2 RF signal input and loop-through 2 separate ASI input Interface 2 separate groups of ASI output RF out Interface Power switch/Fuse/Socket...

  • Page 7: Chapter 2 Installation Guide

    NDS3542D Multi-input Modulator User’s Manual Chapter 2 Installation Guide 2.1 Acquisition Check When user opens the package of the device, it is necessary to check items according to packing list. Normally it should include the following items:  NDS3542D Multi-input Modulator 1pcs ...
  • Page 8 NDS3542D Multi-input Modulator User’s Manual 2.2.2 Environment Requirement Item Requirement When user installs machine frame array in one machine hall, the distance between 2 rows of machine frames Machine Hall Space should be 1.2~1.5m and the distance against wall should be no less than 0.8m.

  • Page 9: Wire's Connection

    NDS3542D Multi-input Modulator User’s Manual  Users should make sure the 2 ends of grounding wire well electric conducted and be antirust.  It is prohibited to use any other device as part of grounding electric circuit  The area of the conduction between grounding wire and device’s frame should be no less than 25mm 2.2.4 Frame Grounding All the machine frames should be connected with protective copper strip.

  • Page 10: Signal Cable Connection

    NDS3542D Multi-input Modulator User’s Manual 2.4 Signal Cable Connection The signal connections include the connection of input signal cable and the connection of output signal cable. The details are as follows: NDS3542D Modulator Cable Illustration:  NMS Cable illustration (CAT5): ...

  • Page 11: Chapter 3 Operation

    NDS3542D Multi-input Modulator User’s Manual Chapter 3 Operation The front panel of NDS3542D is the user-operating interface and the equipment can be easily operated and managed by user according to the procedures displayed on the LCD: Keyboard Function Description: MENU: Cancel current entered value, resume previous setting; Return to previous menu. ENTER: Activate the parameters which need modifications, or confirm the change after modification.

  • Page 12: Lcd Menu Tree

    NDS3542D Multi-input Modulator User’s Manual 3.1 LCD Menu Tree...
  • Page 13 NDS3542D Multi-input Modulator User’s Manual Card A: Main Menu CI Card: Max Birate CI Card Card A Input TS Mode Card Error Check Parse Program Descramble Program Rom Version Card Status Descramble Error CI Card: (Same content with Card A above) Card D BISS A : Main Menu：...
  • Page 14 NDS3542D Multi-input Modulator User’s Manual...

  • Page 15: General Setting

    NDS3542D Multi-input Modulator User’s Manual 3.2 General Setting Switch on the device and after a few seconds’ initialization, it presents start-up pictures as below: Dexin NDS3542D Modulator Start up… Start OK… A Bitrate xx.xxMbps Indicate the Real-time output bitrate of the 2 carriers, which shows in turn. Press ‘LOCK’...
  • Page 16 NDS3542D Multi-input Modulator User’s Manual times upon power on Uptime 2 Days-10:30:20 3.2.2 Input Sets NDS3542D supports 4 tuner inputs and 2 ASI input. Users can connect the signals to the input interfaces and enter ‘Input Sets’ to configure the tuner and ASI input parameters. It displays as below: Input Sets 1: Tuner DVB S2 1...
  • Page 17 NDS3542D Multi-input Modulator User’s Manual Mux Program: Users can parse the Tuner input program list and select programs to mux out via the 4 carriers in this menu. For reading the input bitrate TS Locked Mux Program of corresponding channel Bitrate: 4.040 Mbps TS Lock Parse Program...
  • Page 18 NDS3542D Multi-input Modulator User’s Manual CI Card Card A Card B Card C Card D Press ENTER key to enter Card A (or Card B/C/D), the setting principle is the same. Card A Max Bitrate Input TS Mode Card Error Check Parse Program Descramble Program Rom Version...
  • Page 19 NDS3542D Multi-input Modulator User’s Manual Users can decide whether to enable or disable the card error check function in this menu. Card Error Check (1/2) Enable ►  Parse Program Users can read the quantity of programs parsed from the de-scrambled channel. Searching Program Get 8 Programs ...
  • Page 20 NDS3542D Multi-input Modulator User’s Manual Press ENTER key to enter BISS A (or BISS B/C/D), the setting principle is the same: BISS A Input TS Mode Word Mode Burned Key Descrambler Key TS Lock Parse Program Descramble Program  Input TS Mode One BISS can be applied to descramble one corresponding Tuner input signal sources.
  • Page 21 NDS3542D Multi-input Modulator User’s Manual  Parse Program Users can read the quantity of programs parsed from the de-scrambled channel. Searching Program Get 7 Programs  Descramble Program Users can select program(s) from the searched out programs to descramble. ►1 CETV 1 √...
  • Page 22 NDS3542D Multi-input Modulator User’s Manual Output Mode (1/8) To output muxed programs Tuner 1 To output programs from Tuner 2 Tuner x without mux Tuner 3 Tuner 4 output programs ASI 1 from ASI x without mux ASI 2 output programs from USB without mux ASI 1/2 out select: Enter this menu to choose the ASI output channel.
  • Page 23 NDS3542D Multi-input Modulator User’s Manual 3.2.6 Modulate Setting When entering “Modulate Setting” submenu, user can configure the modulating parameters for the 4 carrier output separately. Modulate Chanel A Chanel B Chanel C Chanel D Standard Constellation Symbol rate RF Frequency RF Level RF On Bitrate...
  • Page 24 NDS3542D Multi-input Modulator User’s Manual   Symbol rate 5310 Ksps  RF Frequency The RF output frequency range is from 30 to 950MHz with 1K stepping. After entering the RF frequency setting submenu, users the can press LEFT, RIGHT, UP, and DOWN buttons to adjust the frequency and confirm by press ENTER button.
  • Page 25 NDS3542D Multi-input Modulator User’s Manual NDS3542D supports TS to output in IP (4*MPTS) format through the DATA port. Users can set IP output parameters in this menu. IP Stream: Service IP Subnet Mask Gateway MPTS 1 MPTS 2 MPTS 3 MPTS 4 3.2.7 USB Device User can check USB status and choose to update CPU or FPGA at this menu.
  • Page 26 NDS3542D Multi-input Modulator User’s Manual Play Search File Play list Play Mode Search File: Users can read the quantity of programs in the USB. Play list: To view program list in the USB device. Play Mode: User can select a play mode for the *.ts files as needed before playing the *.ts file and specify a video under ‘Single file’...
  • Page 27 NDS3542D Multi-input Modulator User’s Manual Users can set network parameters in this menu. Enter ‘Network’ submenus to separately set corresponding parameters. Network NMS IP Subnet Mask Gateway MAC Address Web NMS Port Reset Password NMS IP The IP address for connecting 192.168.000.136 the device to PC Subnet Mask...
  • Page 28 NDS3542D Multi-input Modulator User’s Manual System Save Config Load Saved CFG Factory Reset LCD Time-out Key Password Lock Keyboard Product ID Version Save Configuration? Choose yes to save settings.   and press ENTER to confirm Choose yes to restore the Load Saved CFG? device into the last saved  ...

  • Page 29: Chapter 4 Web-Based Nms Management

    NDS3542D Multi-input Modulator User’s Manual Chapter 4 Web-based NMS Management In addition to using front buttons to control the device, users can also control and set the configuration with the web Brower in the PC. 4.1 login The default IP address of this device is 192.168.0.136. (We can modify the IP through the front panel.) Connect the PC (Personal Computer) and the device with net cable, and use ping command to confirm they are on the same network segment.
  • Page 30 NDS3542D Multi-input Modulator User’s Manual When we confirm the login, it displays the WELCOME interface as Figure-2 where users can have an overview of the device’s system information and working status. System information Input information of the 4 Tuner, 2 ASI and USB input channels Output information: Indicators—Green...
  • Page 31 NDS3542D Multi-input Modulator User’s Manual Parameters → TS Config: Click “TS Config”, it displays the interface where users can configure the output TS parameters in this interface. (Figure-4) Output carrier select The letters A， B， C and D represent the 4 carriers To choose output programs for the 4 carrier output Mux：To output muxed...
  • Page 32 NDS3542D Multi-input Modulator User’s Manual where users can choose the programs from 8 Tuner and 6 ASI input ports to Mux out. (Figure-6) Output Area Input Area Operation Area Figure-6 Configure ‘Input Area’ and ‘Output Area’ with buttons in ‘Operation Area’. Instructions are as below: : To enable/disable the PID remapping To refresh the input program information...
  • Page 33 NDS3542D Multi-input Modulator User’s Manual Figure-7 Input new data and click ‘Save’ button at last to confirm the modification. Parameters → CI Card: NDS3542D supports 4 CI cards to descramble programs from Tuner input. Users can click and enter ‘CI Card’ to configure the 4 cards respectively. (Figure-8) Card Selection Area Figure-8 ...
  • Page 34 NDS3542D Multi-input Modulator User’s Manual One CI card can be applied to descramble programs from the 2 Tuner input signal sources. ‘Skip CI card’ means to skip the card which is used for FTA stream.  Card Error Check Users can decide whether to enable the card error check function by checking the box. After configuring CI card parameters, click button to apply the input data and then click...
  • Page 35 NDS3542D Multi-input Modulator User’s Manual Number before slash indicates the programs which have been descrambled. Number behind slash indicates the whole programs from the selected channel. Users can also read the program information by clicking ‘+’ symbol. Parameters → BISS: From the menu on left side of the webpage, clicking “BISS”, it displays the interface where users can configure 4 BISS and descramble the input channels.
  • Page 36 NDS3542D Multi-input Modulator User’s Manual Input corresponding items and data to active the BISS descrambling as principles be Modulating Side (BISS SCR) Receiving Side (BISS DESCR) Digit (0x----) Mode 1+SW Data Mode 1+Descrambler Key Mode E+ESW Data + Device Mode E + Descrambler Key + Burned Key Mode E+ESW Data + Input ID Mode E + Descrambler Key + SK After configuring the above BISS parameters, click...
  • Page 37 NDS3542D Multi-input Modulator User’s Manual Parameters → PID Pass: From the menu on left side of the webpage, clicking “PID Pass”, it displays the interface where to add the PIDs which need pass through. (Figure-12) In some occasions, there are some PIDs which won’t belong to any program, such as EPG, NIT tables and so on which user just wants to pass them through the multiplexing module without changing anything.
  • Page 38 NDS3542D Multi-input Modulator User’s Manual Figure-15 System → USB From the menu on left side of the webpage, clicking “USB Media”, it displays the interface where users can operate USB device. (Figure-16) NOTE: It is necessary to connect USB device and signal source and activate modulating to operate TS recording.
  • Page 39 NDS3542D Multi-input Modulator User’s Manual Detailed Explanation: Play Mode: User can select a play mode for the *.ts files as needed before playing the *.ts file and specify a video under ‘Single file’ / ‘Single loop’ mode and press “Enter” button to start play.
  • Page 40 NDS3542D Multi-input Modulator User’s Manual System → LCD/Keyboard: From the menu on left side of the webpage, clicking “LCD/Keyboard”, it will display the screen as Figure-18 where to control the device’s front panel. Figure-18  Keyboard and LCD Lock: If it is marked with “√”，the LCD and keyboard will be locked to avoid unexpected modification or view of the device information and configurations.
  • Page 41 NDS3542D Multi-input Modulator User’s Manual Figure-20 System → Backup/Load: From the menu on left side of the webpage, clicking “Backup/Load”, it will display the screen as Figure-21 where to backup or load your configurations. Figure-21 System → Firmware: From the menu on left side of the webpage, clicking “Firmware”, it will display the screen as Figure-22 where to update firmware for the device.
  • Page 42 NDS3542D Multi-input Modulator User’s Manual Figure-22...

  • Page 43: Chapter 5 Troubleshooting

    NDS3542D Multi-input Modulator User’s Manual Chapter 5 Troubleshooting DEXIN’s ISO9001 quality assurance system has been approved by CQC organization. For guarantee the products’ quality, reliability and stability. All DEXIN products have been passed the testing and inspection before ship out factory. The testing and inspection scheme already covers all the Optical, Electronic and Mechanical criteria which have been published by DEXIN.

  • Page 44: Chapter 6 Packing List

    NDS3542D Multi-input Modulator User’s Manual Chapter 6 Packing List NDS3542D Multi-input Modulator  1pcs  User’s Manual 1pcs  RF/Loopout Cables 4pcs  ASI Cable 1pcs  Power Cord 1pcs...
