Step 2: LNBF Mounting and Location

For illustration purpose, we will use the following setting for A city. The following table is
provided for major cities in the homepage of Wavefrontier (www.multilnbdish.com). If you have
not received one from Wavefrontier or cannot find one for your location on the website, contact
Wavefrontier by send email to support@multilnbdish.com. We will forward information to you.
Make sure you indicate your zip code and satellites you are aiming for.
Model: T55
City: A City, CA
Country: USA
Azimuth Elevation
156 45
Here we will illustrate LNBF Holder setting for
American Wavefrontier Corp
100 Pacifica Suite 260
Irvine, CA 92618
Skew 91W
95 L20.0
119W whose setting is
Look closely on the top of LNBF holder supporter. It has grid
showing L20, L10, R10, R20.
Parts: A9
Insert LNBF Holder into the Supporter. Rotate/Align the
bottom of Holder so it can align to R10 Grid.
Parts: A10
Tighten the aligned holder by using B6. Place another B6 with
your hand. Do not tight this one. This (2
tightened at the very end of this whole process.
Parts: B6
101W 110W
L10.0 R0.0
R10.0
Tools:
Tools:
nd
one) will be
Tools: Phillips
119W
R10.0
