AdvisorOne Z-Wave
EN CNF ES PR
1. Z-Wave Module
English: Installation Sheet
Description
The Advisor™One self-contained lifestyle management and security system detects situations and provides control and information
to home and small business owners (P/N AVO-1037).
This document provides instructions on installing and programming the Z-Wave module (P/N AVO-ZW) for use with the AdvisorOne
panel.
The AdvisorOne Z-Wave module enables control of Z-Wave devices that have been configured to the AdvisorOne system.
Controlling lights, thermostats, door locks and other appliances is possible from the AdvisorOne panel and from the auxiliary
Advisor TouchScreens. Some Z-Wave devices may also be controlled via Advisor Mobile or from Bluetooth
system has been configured with the AdvisorOne Bluetooth module.
Preparation and Installation
Preparing to Install the Z-Wave Module
WARNING: Use caution when installing or removing the power supply to an outlet with a metal cover.
1.
Depending on the situation, it may be necessary to contact the central monitoring station before starting the installation.
2.
If a power supply is present, remove the screw from the securement tab and unplug the power supply.
3.
Remove the screw securing the panel chassis. Open the panel by pressing down on the tabs and carefully swing the panel
chassis open.
CAUTION: Use static electricity precautions when handling electronic components.
P/N 466-4410 • REV E • 29APR15
®
Module Installation Sheet
2. Tabs and Battery Connector
3. Without Covers
®
devices when the
1 / 5
Advertisement
Table of Contents
Related Manuals for Interlogix AdvisorOne AVO-ZW
Summary of Contents for Interlogix AdvisorOne AVO-ZW
- Page 1 ® AdvisorOne Z-Wave Module Installation Sheet EN CNF ES PR 1. Z-Wave Module 2. Tabs and Battery Connector 3. Without Covers English: Installation Sheet Description The Advisor™One self-contained lifestyle management and security system detects situations and provides control and information to home and small business owners (P/N AVO-1037).
- Page 2 Disconnect the battery from the battery connector (C in Figure 2) by pressing down on the wire end of the battery clip. To access the location of the Z-Wave module, remove the Communication Modules Cover by pulling outward on the tabs (D in Figure 2) and then lifting upward when tabs release.
- Page 3 • Verify the Z-Wave devices appear in the Z-Wave device list and a green dot appears. Re-install devices if necessary. If these steps fail, try replacing the module devices or contact Interlogix Technical Support. • If a device does not seem to work with an application, verify that it works at a low level and is a known category device, press CONFIGURATION/TESTING/Z-WAVE.
- Page 4 85% relative humidity, noncondensing Module compatibility Contact an Interlogix representative and/or Interlogix.com for the latest list of compatible devices. Regulatory Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 5 Limitation of Liability To the maximum extent permitted by applicable law, in no event will Interlogix be liable for any lost profits or business opportunities, loss of use, business interruption, loss of data, or any other indirect, special, incidental, or consequential damages under any theory of liability, whether based in contract, tort, negligence, product liability, or otherwise.
