MODEL 72300 1/2 TON CAPACITY SINGLE STAGE TRANSMISSION JACK
SETUP • OPERATING • MAINTENANCE INSTRUCTIONS
Note: Revision letters (A, B, C, D etc.) after model numbers have been omitted as they do not affect the setup,
operating and maintenance instructions of a particular jack unless otherwise noted.
IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING
BEFORE USING THIS DEVICE, READ THIS MANUAL
COMPLETELY
AND
THOROUGHLY,
OPERATING
PROCEDURES,
MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD
CAUSE ACCIDENTS RESULTING IN SERIOUS OR FATAL
PERSONAL INJURY AND/OR PROPERTY DAMAGE.
The use of portable automotive lifting devices is subject to certain
hazards that cannot be prevented by mechanical means, but
only by the exercise of intelligence, care, and common sense. It
is therefore essential to have owners and personnel involved in
the use and operation of equipment who are careful, competent,
trained, and qualified in the safe operation of the equipment and
its proper use. Examples of hazards are dropping, tipping, or
slipping of motor vehicles or their components caused primarily by
improperly securing loads, overloading, off-centered loads, use on
Adequately support the vehicle before starting repairs.
Consult the in-ground or above-ground lift manufacturer for
the recommended support procedure and under hoist support
stand locating points.
Support the engine with a stand before unbolting the
transmission from the engine.
Inspect the jack before each use. Do not use the jack if it is
damaged, altered, modified, in poor condition, leaking hydraulic
fluid or unstable due to loose or missing hardware. Take
corrective action before using the jack.
Do not use jack beyond its rated capacity. Do not lift or support
the vehicle with this jack.
1.
Refer to the exploded view parts drawing for identification,
location and position of parts.
2.
The chains and corresponding chain hardware are provided
in order to secure the transmission to the saddle assembly and
containing angles. One end of each chain should be anchored to
a containing angle. The restraint system (chain, chain hardware,
and containing angles) may be adjusted according to the specific
transmission configuration.
3.
Sometimes air gets trapped in the jack during shipment. An
air bound hydraulic system feels spongy when pumped and
sometimes the jack will not pump full incremental strokes.
PROFESSIONAL LIFTING EQUIPMENT
UNDERSTAND
SAFETY
WARNINGS AND
WARNING
®
other than hard level surfaces, and using equipment for a purpose
ITS
for which it was not designed.
It is the responsibility of the owner to make sure all personnel read
this manual prior to using this device. It is also the responsibility of
the device owner to keep this manual intact and in a convenient
location for all to see and read. If the manual is lost or not legible,
contact Norco Industries, Inc. for a free replacement. If the operator
is not fluent in English, the product and safety instructions shall be
read to and discussed with the operator in the operator's native
language by the purchaser/ owner or his designee, making sure
that the operator comprehends its contents.
This product is covered by a Limited Lifetime Warranty. For details
see the back cover of Norco's product catalog.
Use only on a hard level surface.
Be sure setup is stable and secure. Use this jack only with
adapters and load restraints provided by Norco. Use of this
jack is limited to the removal installation and transportation
(in the lowered position) of transmissions and transfer cases.
Center load on saddle. Consult the vehicle manufacturer for the
transmission's center of balance. Off-center loads can cause
jack failure and/or loss of load.
No alterations shall be made to this jack and use only with
factory approved adapters.

SETUP

PURGING AIR FROM THE HYDRAULIC SYSTEM
a.
Open the release valve by turning the release valve knob in
a counterclockwise direction two full turns.
b.
Pump the handle ten full strokes.
c.
Close the release valve by turning the release valve knob in
a clockwise direction until tight.
d.
Pump the jack until the ram is extended to maximum height.
e.
If the condition remains, repeat steps "a" through "d" until all
air is purged from the system.
