Device repair anD return

Prior to returning devices, contact the nearest local
Detector Electronics office so that a Return Material
Identification (RMI) number can be assigned. A written
statement describing the malfunction must accompany
the returned device or component to assist and expedite
finding the root cause of the failure.
Pack the unit properly. Always use sufficient packing
material. Where applicable, use an antistatic bag as
protection from electrostatic discharge.
Inadequate packaging that ultimately causes
damage to the returned device during shipment
will result in a service charge to repair the damage
incurred during shipment.
Return all equipment transportation prepaid to the factory
in Minneapolis.

orDerinG inFormation

When ordering, please specify:
x7050 xWatch explosion proof camera
Refer to the xWatch Model Matrix below for details.

ACCEssorIEs

swivel Mount Bracket is required for mounting the
camera:
– Q9001B1175 Aluminum
(p/n 002099-003)
– Q9001H8001 Stainless Steel Mounting Bracket
(p/n 004404-002)
xWAtCh MoDEl MAtrIx
MoDEl
x7050
2.1
NOTE
Mounting Bracket
DEsCrIPtIon
xWatch Explosion Proof Camera
tyPE MAtErIAl
A Aluminum
Stainless Steel (316)
B
tyPE
1E
1F
Q1201A laser holder/laser is used for sighting the
flame detector and xWatch camera. The Laser Holder
easily attaches to the front of the detector or camera.
The Laser projects a red laser beam to show the exact
center of the field of view. Additional laser positions are
provided to show the outside edges of the field of view.

rEPlACEMEnt PArts

Part number
009448-003
009448-004
107427-004
001680-001
005003-001

AssIstAnCE

For assistance in ordering a system to meet the needs of
a specific application, contact:
Detector Electronics Corporation
6901 West 110th Street
Minneapolis, Minnesota 55438 USA
Operator: (952) 941-5665 or (800) 765-FIRE
Customer Service: (952) 946-6491
Fax: (952) 829-8750
Web site: www.det-tronics.com
E-mail: det-tronics@det-tronics.com
thrEAD tyPE
1/2' NPT
M20
tyPE VIDEo outPut
50 NTSC
51 PAL
tyPE APProVAl AgEnCy
W FM/CSA/ATEX/CE
10
Description
Model DE2020N –
Replacement Camera Module, NTSC
Model DE2020P –
Replacement Camera Module, PAL
Rubber O-rings
Window cleaner squeeze bottle
(package of six bottles)
Silicone-free grease
tyPE ClAssIFICAtIon
2 Division/Zone Ex d
