- Page 1 • • 10623 Roselle Street, San Diego, CA 92121 (858) 550-9559 FAX (858) 550-7322 • contactus@accesio.com www.accesio.com MODELS PCI-IDO-48A, PCI-IDO-32A, and PCI-IDO-16A Isolated FET Outputs PCI Card With External Trigger Updates USER MANUAL FILE: MPCI-IDO-48A.A2c...
- Page 2 ACCES, nor the rights of others. IBM PC, PC/XT, and PC/AT are registered trademarks of the International Business Machines Corporation. Copyright by ACCES I/O Products Inc, 10623 Roselle Street, San Diego, CA 92121. All rights reserved. WARNING!! ALWAYS CONNECT AND DISCONNECT YOUR FIELD CABLING WITH THE COMPUTER POWER OFF.
- Page 3 Other than the above, no other warranty, expressed or implied, shall apply to any and all such equipment furnished or sold by ACCES. Manual PCI-IDO-48A Series...
-
Page 4: Table Of Contents
Chapter 6: Connector Pin Assignments ................15 Table 6-1: Port 0 Connector Pin Assignments (P2) ..................15 Table 6-2: Port 1 Connector Pin Assignments (P3) ..................16 Table 6-3: Port 2 Connector Pin Assignments (P4) ..................17 Chapter 7: Specifications ....................18 Manual PCI-IDO-48A Series... -
Page 5: Chapter 1: Introduction
Chapter 1: Introduction The PCI-IDO-48A is a PCI board providing opto-isolated discrete outputs with load voltages up to 60VDC. Solid-state, P-Channel FET switches are used as the output elements providing greater reliability and much faster turn-on and turn-off time than is possible with electromechanical relays. - Page 6 Outputs are broken out using 50-wire ribbon cables that mate with the IDC connectors on the card. A strain relief bar where the cables exit the card assures that the cables will not interfere with adjacent cards. Standard cables are six feet long but alternate lengths are available. Figure 1-1: Block Diagram Manual PCI-IDO-48A Series...
-
Page 7: Ordering Guide
Figure 1-2: Isolated FET Output Schematic Ordering Guide PCI-IDO-48A 48-Channel FET Output Board PCI-IDO-32A 32-Channel FET Output Board PCI-IDO-16A 16-Channel FET Output Board Model Options Extended temperature operation (-40° to +85°C) -RoHS RoHS compliant version Special Order Please contact ACCES with your precise requirement. -
Page 8: Optional Accessories
STB-50 screw terminal board on a DIN rail 50-Pin Three-Header Universal Screw Terminal Board Installed in T-BOX Black STB-72CH Powder-Coated Metal Enclosure Kit allows DIN rail mounting of STB-72CH MP104-DIN in the T-BOX. Manual PCI-IDO-48A Series... -
Page 9: Chapter 2: Installation
START | RUN and type , click OK or press . Follow the on-screen prompts to install the software for this board. LINUX Please refer to linux.html on the CD-ROM for information on installing under linux. Manual PCI-IDO-48A Series... - Page 10 In DOS, the PCI\SOURCE directory shows the BIOS calls used to determine the address and IRQ assigned to installed PCI devices. In Windows, the Windows sample programs demonstrate querying the registry entries (created by PCIFind and NTIOPCI.SYS during boot-up) to determine this same information. Manual PCI-IDO-48A Series...
-
Page 11: Chapter 3: Option Selection
Chapter 3: Option Selection There are no user configurable options on this product. Figure 3-1: Option Selection Map Manual PCI-IDO-48A Series... -
Page 12: Chapter 4: Address Selection
For clarity, PCIFind shows only the most commonly required information. For those who require it, be aware of the following: BAR[0]: memory mapped PEX8311 BAR[1]: I/O mapped PEX8311 BAR[2]: I/O mapped card registers (←all most software needs) Manual PCI-IDO-48A Series... -
Page 13: Chapter 5: Programming
Writing to this address updates the data on Port1 bits 0-7. The data is updated instantly to the outputs in Immediate Mode and updated on a rising edge of the External Trigger in External Trigger Mode. Refer to Base Address + 3 for Immediate and External Trigger Modes. Manual PCI-IDO-48A Series... - Page 14 Reading from this address will return the number of times (0-15) a rising edge of the External Trigger has occurred without writing to the outputs (Buffer Under-run Error). The count value is reset to zero when read. Manual PCI-IDO-48A Series...
-
Page 15: Chapter 6: Connector Pin Assignments
Bit 13 Supply (+) Bit 14 Return (-) Bit 14 Out Bit 14 Supply (+) Bit 15 Return (-) Bit 15 Out Bit 15 Supply (+) Ext. Trigger Input Table 6-1: Port 0 Connector Pin Assignments (P2) Manual PCI-IDO-48A Series... - Page 16 Bit 29 Out Bit 29 Supply (+) Bit 30 Return (-) Bit 30 Out Bit 30 Supply (+) Bit 31 Return (-) Bit 31 Out Bit 31 Supply (+) Ground Table 6-2: Port 1 Connector Pin Assignments (P3) Manual PCI-IDO-48A Series...
- Page 17 Bit 45 Out Bit 45 Supply (+) Bit 46 Return (-) Bit 46 Out Bit 46 Supply (+) Bit 47 Return (-) Bit 47 Out Bit 47 Supply (+) Ground Table 6-3: Port 2 Connector Pin Assignments (P4) Manual PCI-IDO-48A Series...
-
Page 18: Chapter 7: Specifications
Tolerance of higher isolation voltage can be obtained on request by applying a conformal coating to the board. Environmental Operating Temperature: 0°C to +70°C Storage Temperature: -40°C to +150°C Humidity: 5% to 90% RH, non-condensing 6.875" (174.6mm) long, 4.2” ( 106.7mm) high Board Dimensions: Manual PCI-IDO-48A Series... - Page 19 Please detail any errors you find and include your mailing address so that we can send you any manual updates. 10623 Roselle Street, San Diego CA 92121 Tel. (858)550-9559 FAX (858)550-7322 www.accesio.com Manual PCI-IDO-48A Series...
