Summary of Contents for iWantit iPHUDK11
- Page 1 (iPhone not included)
-
Page 3: Table Of Contents
contents unpacking .....................4 product overview .................5 docking station .....................5 remote control ......................6 remove the insulating strip from the remote control .......8 replace the remote control battery .............8 dock adapter ..................10 charging and sync ................11 operations ...................12 hints and tips ..................13 specifications ..................15 safety warnings ..................16... -
Page 4: Unpacking
Thank you for purchasing your new iWantit universal dock for iPhone. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. You will also find some hints and tips to help you resolve any issues. -
Page 5: Product Overview
product overview docking station iPhone Slot Remote Control Sensor Mini HDMI Socket Mini USB Socket... -
Page 6: Remote Control
remote control 1. OK (Confirm / Enter) Button 2. VOL+ (Volume Up) Button MENU Press to turn docking station volume up (iPhone VOL+ volume is not controlled). (Previous / Rewind) Button VOL- Press to skip to the previous song or video. Press and hold to rewind song. - Page 7 6. MENU (Menu) Button Press to go back to the MENU Previous Menu. (Play / Pause) Button VOL+ Press to play; press again to pause. (Next / Fast-forward) VOL- Button Press to skip to the next song or video. Press and hold to fast-forward song.
-
Page 8: Remove The Insulating Strip From The Remote Control
remove the insulating strip from the remote control Remove the insulating mylar strip from the battery if the battery is being used for the first time. It is located at the bottom back side of the remote control. replace the remote control battery Replace the remote control battery when it stops (normally every two years). - Page 9 Handling the Battery • Improper or incorrect use of batteries may cause corrosion or battery leakage, which could cause fire, personal injury or damage to property. • Install the battery correctly by following the polarity (+ and -) indications in the battery compartment. •...
-
Page 10: Dock Adapter
dock adapter Insert the dock adapter that fits your iPhone model, then plug in your iPhone. The adapter number is marked at the back of each dock adapter. The below adapters are provided with the product. For other iPhone models, please contact the store where you purchased your iPhone. -
Page 11: Charging And Sync
charging and sync To charge your iPhone with power adapter: 1. Connect the dock station to USB power adapter and plug Apple device into the dock for charging. 2. Connect the dock station to computer for charging and sync via the mini USB cable. -
Page 12: Operations
operations 1. Plug the yellow video connector into the composite video input port on your TV or receiver. Plug the write and red audio connections into the left and right analog audio input ports respectively, on your TV or receiver. Plug the mini HDMI connectors of component AV cable into the Dock Station. -
Page 13: Hints And Tips
hints and tips 1. I cannot start a slideshow with my remote control. • You cannot start a slideshow remotely. You must use the iPhone’s controls to start a slideshow. After you start the slideshow, you can control it with your remote control. For more information about your iPhone photo capabilities, refer to your iPhone documentation. - Page 14 4. Why doesn’t the docking station charge my iPhone’s battery? • Check if your iPhone is correctly docked in the docking station. • Check if your power adapter is firmly plugged in the docking station and the mains socket. 5. Why doesn’t my remote control function? •...
-
Page 15: Specifications
Model iPHUDK11 Input DC 5V 1A Output DC 5V 500mA Remote control battery 3V, CR2025 or equivalent Features and specifications are subject to change without prior notice. -
Page 16: Safety Warnings
safety warnings • Read all the instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party make sure to include this manual. • Check that the voltage marked on the rating label matches your mains voltage. - Page 17 Moisture • To reduce the risk of fire, electric shock or product damage, do not expose this unit to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, should be placed on the unit. • If you spill any liquid into the unit, it can cause serious damage.
- Page 18 Standby • The unit will continue to draw electricity from the mains supply while in standby. In the interests of safety and to avoid unnecessary energy consumption, never leave the unit in standby while unattended for long periods of time, e.g.
- Page 20 Please note that the use of this accessory with iPhone may affect wireless performance. iPhone is trademark of Apple Inc., registered in the U.S. and other countries. All trademarks are the property of their respective owners and all rights are acknowledged. DSG Retail Ltd. • Maylands Avenue Hemel Hempstead Herts • HP2 7TG • England (P.N.: iPHUDK11-002)
