Page 1 Stemme AG – Flugplatzstrasse F2 Nr. 7 – D-15344 Strausberg FLIGHT MANUAL TSA-M, VARIANT S6 DOCUMENT NUMBER: P400-006000 E DATE OF ISSUE: OCTOBER 07, 2008 _ _ _ _ _ _ _ _ Model: Serial number: EASA.A.143 _ _ _ _ _ _ _ _...
Page 2 Stemme AG – Flugplatzstrasse F2 Nr. 7 – D-15344 Strausberg The English version of the Flight Manual is a direct translation from the EASA approved German version, approval number EASA.A.143. If there are any discrepancies in the translation the German version is deemed binding.
Page 3 FLIGHT MANUAL TSA-M, VARIANT S6 Documentation of Revisions _______________________ All revisions to this Flight Manual must be documented in the following table. Exceptions to this are:  current values needed for the determination of the aircraft’s center-of- gravity (CG) (chapter 6.3) ...
Page 4 FLIGHT MANUAL TSA-M, VARIANT S6 Rev. Date of Pertaining Note and Date of Date of Section No. of Pages Signature Revision Approval incorporation iii, v, vii, viii, P061- EASA Approval 0, 6, 9 04.07.2011 6-16, 9-3 2010-047 10037239 iii, iv, v, vi, vii, viii,...
Page 5 FLIGHT MANUAL TSA-M, VARIANT S6 List of Effective Pages and Chapters ________________ This list is only valid for the aircraft serial number mentioned on the title page. Pages identified with “*” are intentionally left blanks. Page EASA Rev.-No. Date of Issue...
Page 6 FLIGHT MANUAL TSA-M, VARIANT S6 Page EASA Rev.-No. Date of Issue Page EASA Rev.-No. Date of Issue appro- appro- or Revision or Revision 3-11 28.01.2011 3-12 28.01.2011 3-13 3-14 3-15 28.01.2011 06.07.2020 3-16 28.01.2011 3-17 4-10 26.09.2011 3-18 4-11 3-19...
Page 7 FLIGHT MANUAL TSA-M, VARIANT S6 Page EASA Rev.-No. Date of Issue Page EASA Rev.-No. Date of Issue appro- appro- or Revision or Revision Chap. 5 Chap. 7 06.07.2020 06.07.2020 28.01.2011 28.01.2011 26.09.2011 28.01.2011 26.09.2011 20.05.2011 26.09.2011 14.06.2011 5-10 7-10 28.01.2011 5-11 01.10.2012...
Page 8 FLIGHT MANUAL TSA-M, VARIANT S6 Page EASA Rev.-No. Date of Issue appro- or Revision 7-35 28.01.2011 7-36 06.07.2020 7-37 06.07.2020 7-38 06.07.2020 7-39 06.07.2020 7-40 06.07.2020 7-41 06.07.2020 7-42 06.07.2020 7-43 06.07.2020 7-44 06.07.2020 Chap. 8 28.01.2011 26.09.2011 8-10 8-11 8-12 Chap.
Page 9: Table Of Contents
FLIGHT MANUAL TSA-M, VARIANT S6 Table of Contents ________________________________ Chapter 1 – General Chapter 2 – Operating Limitations Chapter 3 – Emergency Procedures Chapter 4 – Normal Operating Procedures Chapter 5 – Flight Performance Chapter 6 – Mass and Balance Chapter 7 –...
Page 10 FLIGHT MANUAL TSA-M, VARIANT S6 INTENIONALLY LEFT BLANK Doc.-No.: P400-006000 E Page: x Revision: 10 Date of Issue: 07. October 2008 Date of Rev.: 06.07.2020...
Page 11: Chapter 1 - General
Flight Manual STEMME S6 Chapter 1 – General Introduction ..................1-2 Basis for Certification ..............1-3 Warnings, Cautions and Notes ............1-4 Dimensions and Specifications ............1-5 Three-View Drawing ................. 1-7 Terminology and Abbreviations ............. 1-8 1.6.1 Speeds..................1-8 1.6.2 Meteorological Terminology ............
Page 12: Introduction
This Flight Manual has been created to provide pilots and flight instructors with all information necessary for safe, practical and optimized operations of the motorglider Stemme S6, equipment option “S6-T” (Fix Landing Gear). The Flight Manual contains all information for the pilot required by CS-22.
Page 13: Basis For Certification
Flight Manual STEMME S6 Basis for Certification ____________________________ The motorglider variant STEMME S6 is based on the type STEMME TSA-M, which has been type certified (type certificate nr. EASA.A.143) by EASA on November 22, 2008, in Cologne, Germany. The variant STEMME S6 has been certified in correspondence to the „Certification Specifications for Sailplanes and Powered Sailplanes CS-22“...
Page 14: Warnings, Cautions And Notes
Flight Manual STEMME S6 Warnings, Cautions and Notes ____________________ Remarks in the manual of particular importance to flight safety and handling have been especially marked by the use of one of the following terms: Warning: implies that non-observation of corresponding procedure leads to immediate or significant degradation of flight safety.
Page 15: Dimensions And Specifications
Flight Manual STEMME S6 Dimensions and Specifications _____________________ Specifications Fuselage Design Front section: carbon-fiber composites Mid-section: steel-tube framework with glass-fiber composite fairing Rear section with integrated vertical fin: carbon-fiber composites Length 27.95 ft / 8.52 m Height 8.04 ft / 2.45 m Width 3.97 ft / 1.21 m...
Page 16 Flight Manual STEMME S6 4-Cylinder 4-Stroke Otto-engine in Engine Design opposed-cylinder design, Turbocharger with electronic Manifold-Air-Pressure (MAP) control, integrated reduction gear Rotax 914 F2 Model Max. Take-off Power 113.3 HP / 84.5 kW at 5800 RPM (Takeoff RPM limited to 5600 RPM) 98.4 HP / 73.4 kW at 5500 RPM...
Page 17: Three-View Drawing
Flight Manual STEMME S6 Three-View Drawing ______________________________ Illustration 1-1: Threeview-Drawing of STEMME S6 Version „S6-T“ Doc.-No.:P400-006.000 E Page: 1-7 Revision: --- Date of Issue: 07. October 2008 Date of Rev.: --.--.----...
Page 18: Terminology And Abbreviations
Flight Manual STEMME S6 Terminology and Abbreviations ___________________ 1.6.1 Speeds Indicated Air-Speed True Air-Speed Calibrated Air-Speed, corrected for installation and instrument errors Maneuvering Speed, no full or sudden deflection of the flight controls is allowed above this speed Design Cruising Speed, only in calm air...
Page 19: Mass And Balance
Flight Manual STEMME S6 1.6.3 Mass and Balance Reference Plane, an imaginary vertical plane which forms the origin for all center-of-gravity calculations Mean Aerodynamic Chord MTOM Maximum Take-Off Mass (cf. MTOW) Empty Mass Mass of the Airplane including non-useable fuel, all operating- fluids and max.
Page 20: Miscellaneous
Flight Manual STEMME S6 1.6.5 Miscellaneous FCOM Flight Crew Operation Manual Alternating Current Direct Current Runway STBY Stand-by Communication Glass-fiber composites Carbon-fiber composites Visual Flight Rules NVFR Night-time Visual Flight Rules EASA European Aviation Safety Agency Service Bulletin German Aviation Authority („Luftfahrt-Bundesamt“)
Page 21: Units And Conversion Factors
Flight Manual STEMME S6 Units and Conversion Factors ______________________ Dimension Conversion Imperial Unit Metric Unit Distance [in] 25.4 [mm] [ft] 0.3048 [NM] 1.852 [km] Speed [kts] 1.852 [km/h] [fpm] 0.00508 [m/s] [mph] 1.609 [km/h] Mass 1 [lbs] 0.454 [kg] Volume [US gal] 3.7854...
Page 22: References
Flight Manual STEMME S6 References _____________________________________ The following list of references mentions documents and manuals which have been used to gain information from aircraft components from other manufacturers. However, the information presented in this Flight Crew Operation Manual is obligatory.
Page 23: Chapter 2 - Operating Limitations
FLIGHT MANUAL TSA-M, VARIANT S6 Chapter 2 – Operating Limitations Introduction ..................2-2 Air-Speeds ..................2-3 Air-Speed-Indicator Markings ............2-4 Limitations for Propulsion System and Operating Fluids .... 2-5 2.4.1 Engine Limitations ..............2-5 2.4.2 Operating Fluids ................. 2-6 Engine Instrument Markings ............2-7 Markings on other Instruments ............
Page 24: Introduction
FLIGHT MANUAL TSA-M, VARIANT S6 Introduction ____________________________________ This chapter describes the operating limitations, instrument markings and placards. These need to be followed for a safe operation of the motorglider, its engine and its standard equipment. Doc.-No.:P400-006.000 E Page: 2-2 Revision: --- Date of Issue: 07.
Page 25: Air-Speeds
FLIGHT MANUAL TSA-M, VARIANT S6 Air-Speeds ______________________________________ The air-speed limitations and their importance to flight operations are listed below: Speed (IAS) Remark Never-Exceed Speed 145 kts / This speed may NEVER (maximum speed) in 270km/h be exceeded. This air- calm weather conditions...
Page 26: Air-Speed-Indicator Markings
FLIGHT MANUAL TSA-M, VARIANT S6 Air-Speed-Indicator Markings _____________________ The following table defines the air-speed-indicator markings and their meaning. Marking IAS (Value/Range) Meaning White Arc 45 to 102 kts / Operating range for positive flap settings. 85 to 190 km/h (The lower limit is 1.1 V at MTOM in landing-configuration (LDG 2).
Page 27: Limitations For Propulsion System And Operating Fluids
FLIGHT MANUAL TSA-M, VARIANT S6 Limitations for Propulsion System and Operating Fluids ____________________________ 2.4.1 Engine Limitations Engine Engine Manufacturer BRP-Rotax GmbH & Co. KG Gunskirchen, Austria Engine Model ROTAX 914 F2 Maximum RPM during T/O (max. 5600 RPM for 5 minutes): (5800 RPM allowed for max.
Page 28: Operating Fluids
FLIGHT MANUAL TSA-M, VARIANT S6 Propeller Diameter: 5.58 ft / 1700 mm 2.4.2 Operating Fluids Fuel Type of Fuel MOGAS (unleaded higher-octane gasoline), or AVGAS 100LL Lubricants Oil Temperature minimum 122°F / 50°C maximum 266°F / 130°C Oil Pressure minimum 44.3 inHg / 1.5 bar...
Page 29: Engine Instrument Markings
FLIGHT MANUAL TSA-M, VARIANT S6 Engine Instrument Markings _______________________ Indicating Range Red Line Green Arc Yellow Arc Red Line (Lower (Normal (Upper (Upper Limit) Instrument Limit) Operating Warning Range) Range) Tachometer [RPM] 1400-5500 5500 - 5600 * 5600 * Oil Temperature [°F]...
Page 30: Markings On Other Instruments
FLIGHT MANUAL TSA-M, VARIANT S6 Markings on other Instruments ____________________ Indicating Range Red Line Green Arc Yellow Arc Red Line (Lower (Normal (Upper (Upper Limit) Instrument Limit) Operating Warning Range) Range) Voltmeter 11.5 Amperemeter Doc.-No.:P400-006.000 E Page: 2-8 Revision: --- Date of Issue: 07.
Page 31: Masses
FLIGHT MANUAL TSA-M, VARIANT S6 Masses _________________________________________ Maximum Take-Off Mass: 1874 lbs / 850 kg • • Maximum Landing Mass: 1874 lbs / 850 kg Maximum Payload in • Rear Baggage Compartment: 44 lbs / 20 kg Warning: Exceeding the mass limits can cause the A/C to be...
Page 32: Center-Of-Gravity (Cg)
FLIGHT MANUAL TSA-M, VARIANT S6 Center-of-Gravity (CG) ___________________________ More details for determining the CG in the empty configuration are described in chapter 6 of this operation manual. They can also be found in the maintenance manual of the STEMME S6.
Page 33: Permitted Maneuvers
FLIGHT MANUAL TSA-M, VARIANT S6 Permitted Maneuvers _____________________________ The STEMME S6 motorglider is certified according to CS-22 in the „Utility“- category. This certification includes the following maneuvers: 1. All regular, non-aerobatic maneuvers 2. Maneuvers with a maximum bank-angle of 60°...
Page 34: 2.10 Maneuver Load-Factors
FLIGHT MANUAL TSA-M, VARIANT S6 2.10 Maneuver Load-Factors __________________________ When flying the permitted maneuvers, the following maximum load factors are only allowed: at v at v Positive Negative -2.65 -1.5 Warning: Increasing the maneuver load-factors past the allowed limits causes the aircraft-structure to be overloaded!
Page 35: 2.11 Operating Altitude
FLIGHT MANUAL TSA-M, VARIANT S6 2.11 Operating Altitude _______________________________ The maximum demonstrated operating-altitude with the engine running is at 16000 ft / 4875 m MSL. At higher altitudes an unproblematic restart of the engine cannot be guaranteed. Doc.-No.:P400-006.000 E Page: 2-13 Revision: --- Date of Issue: 07.
Page 36: 2.12 Flight Crew
FLIGHT MANUAL TSA-M, VARIANT S6 2.12 Flight Crew _____________________________________ Maximum Number of Crew Members: Minimum Number of Crew Members: 1 Pilot – If the A/C has all necessary equipment (additional air-speed-indicator and wheel- brake on the right-hand side) it may be flown from the left seat or the right seat.
Page 37: 2.13 Permitted Modes Of Operation
FLIGHT MANUAL TSA-M, VARIANT S6 2.13 Permitted Modes of Operation _____________________ Permitted modes of operation are: VFR-flights in day-time only No Aerobatics, no maneuvers with negative load factors Caution: Flights into known icing conditions or into thunderstorm conditions are not permitted! Note: Aerotow and winch launching are not permitted.
Page 38: 2.14 Minimum Equipment
FLIGHT MANUAL TSA-M, VARIANT S6 2.14 Minimum Equipment _____________________________ The following table lists the aircraft’s minimum equipment which is required by CS-22 and by operational considerations. This minimum equipment must be functioning properly. Minimum Equipment: Flight and Navigational Instruments •...
Page 39: 2.15 Fuel
FLIGHT MANUAL TSA-M, VARIANT S6 2.15 Fuel ___________________________________________ Fuel to be used: MOGAS • (unleaded gasoline according to EN 228, min. RON 95) or AVGAS 100LL Standard tank, with auxiliary tank (integral tanks in left and right • wing) Tank Capacity (right): 17.2 US gal / 65 l...
Page 40: 2.16 Lubricant And Coolant
FLIGHT MANUAL TSA-M, VARIANT S6 2.16 Lubricant and Coolant ___________________________ 2.16.1 Lubricant To lubricate the engine and the attached gears, use only regular automotive-oils with additives for gears. Do NOT use alloyed or un-alloyed aircraft-engine oil! Caution: If AVGAS is used, do NOT use fully synthetic oil! Note: Only use oils according to the API-specifications.
Page 41: Coolant
FLIGHT MANUAL TSA-M, VARIANT S6 Illustration 2-1: Table of Lubricants Oil Capacity: maximum Oil Capacity: 0.8 US gal / 3 l • minimum Oil Capacity: 0.5 US gal / 2 l • max. permitted Oil Consumption: 0.02 US gal /h / 0.06 l/h •...
Page 42 FLIGHT MANUAL TSA-M, VARIANT S6 Caution: Low-grade coolant or contaminated coolant can cause deposits in the cooling system. This might lead to bad cooling performance! Caution: Because of the possible deposits and the fire danger do NOT use pure anti-freeze concentrate. Pure anti-freeze solidifies at –18°C!
Page 43: 2.17 Additional Limitations
FLIGHT MANUAL TSA-M, VARIANT S6 2.17 Additional Limitations ____________________________ 2.17.1 Maximum demonstrated Crosswind-Component The maximum demonstrated crosswind-component is: • 16 kts / 30 km/h Warning: Take-offs and landings in conditions with higher crosswind- components may cause uncontrollable flight conditions. 2.17.2...
Page 44: 2.18 Placards For Operating Limitations
FLIGHT MANUAL TSA-M, VARIANT S6 2.18 Placards for Operating Limitations _________________ The following section describes placards for operating limitations and their position in the cockpit. Note: Additional placards and their positions are mentioned in the maintenance manual. Illustration 2-2: Position of Placards on the Instrument Panel and Canopy Frame Doc.-No.:P400-006.000 E...
Page 45 FLIGHT MANUAL TSA-M, VARIANT S6 Manufacturer: STEMME AG Type: TSA-M Model: S6T Serial no.: Year of Constr.: Certificated for: Never exceed Speed: 270 km/h Manoeuvering Speed: 190 km/h Maximum Speeds - Rough Air: 190 km/h - Flaps extended pos. Flaps: TO / LDG 1:...
Page 46 FLIGHT MANUAL TSA-M, VARIANT S6 Baggage (IAS) max. 20 kg [ft MSL] [kts] 2. Mounted on the inside of the hatch to the rear fuselage section 6500 10000 13000 16500 3. Mounted on the instrument panel 19500 (near the air-speed-indicator,...
Page 47: Chapter 3 - Emergency Procedures
Flight Manual STEMME S6 Chapter 3 – Emergency Procedures Introduction ..................3-2 Defined Airspeeds for Emergency Procedures ......3-3 Canopy Jettison ................3-4 Bail-Out ..................... 3-5 Stall Recovery .................. 3-6 3.5.1 Powered-Configuration ............... 3-6 3.5.2 Glider-Configuration ..............3-7 Spin Recovery .................. 3-8 Recovery from Spiral-Dive ..............
Page 48: Introduction
Flight Manual STEMME S6 Introduction ____________________________________ This chapter provides checklists and recommended procedures to manage emergencies that may occur. When all mandatory procedures for pre-flight- checks and maintenance are observed, a malfunction of the engine or important equipment is very unlikely.
Page 49 Flight Manual STEMME S6 Defined Airspeeds for Emergency Procedures ________ Airspeed (IAS) Emergency [kts / km/h] Engine Failure during take-off 60 kts / 110 km/h Flaps set to TO / LDG 1 • Air-speed for the best glide-angle 60 kts / 110 km/h Flaps set to NEUTRAL •...
Page 50: Canopy Jettison
Flight Manual STEMME S6 Canopy Jettison ________________________________ Jettison the canopy as follows: Red emergency-handle PULL strongly (center of instrument-console) The canopy is pushed upwards by a gas-spring. If necessary, push by hand. Warning: The rear-canopy-lock must remain engaged when the...
Page 51: Bail-Out
Flight Manual STEMME S6 Bail-Out ________________________________________ After the canopy is jettisoned: Central-lock of the safety-belts OPEN Drop below the wing to avoid Bail-out over the side collision with the tail-unit. Note: The fixed side-parts of the cockpit are made of a strong structure without sharp edges.
Page 52: Stall Recovery
Flight Manual STEMME S6 Stall Recovery __________________________________ 3.5.1 Powered-Configuration Stall speed depends on flap-setting and actual weight and may occur in unaccelerated level-flight below 52 kts / 96 km/h (worst for flaps set to CRUISE at maximum weight). Stalls will occur in turns at higher speeds depending on g- force.
Page 53: Glider-Configuration
Flight Manual STEMME S6 3.5.2 Glider-Configuration Stall speed depends on flap-setting and actual weight and may occur in unaccelerated level-flight below 52 kts / 96 km/h (worst for flaps set to CRUISE at maximum weight). Stalls will occur in turns at higher speeds depending on g- force.
Page 54: Spin Recovery
Flight Manual STEMME S6 Spin Recovery __________________________________ If the motorglider spins unintentionally, the following procedures are recommended (for both glider-configuration and powered-configuration): Rudder DEFLECT in the direction opposite to the spin Ailerons NEUTRAL Elevator RELEASE back-pressure or PUSH slightly forward...
Page 55: Recovery From Spiral-Dive
Flight Manual STEMME S6 Recovery from Spiral-Dive _________________________ Caution: With middle and forward CG-positions, the spinning A/C has the tendency to start a spiral-dive after some spinning-turns. During a spiral-dive, the air-speed and g-forces will increase in a short time.
Page 56: Engine-Failure
Flight Manual STEMME S6 Engine-Failure __________________________________ 3.8.1 Engine-Malfunction on Ground Throttle IDLE Brakes as required Warning: Do NOT fly the A/C if a malfunction is not completely repaired! Caution: If the oil-pressure is in the red range, turn OFF the engine immediately.
Page 57: Engine-Failure During Take-Off
Flight Manual STEMME S6 3.8.2 Engine-Failure during Take-Off In the case of an engine-failure, or when not enough power is available, perform the following procedure: If RWY is long enough, land straight ahead. If RWY is NOT LONG enough, the pilot has to decide how to proceed, depending on altitude, position and terrain.
Page 58: Engine-Failure During Flight
Flight Manual STEMME S6 3.8.3 Engine-Failure during Flight An engine-failure is possible in all flight-phases and must be considered in flight- planning. Existing experience with the engine shows, that certain engine-failure- situations are more likely than others. The relevant emergency procedures are described in the following section.
Page 59 Flight Manual STEMME S6 Ignition BOTH Starter START (if necessary) If the restart of the engine fails: Prepare for an off-field-landing or a landing on next suitable airfield. Caution: Within 10 seconds after engine-restart, the oil-pressure must be in the green range. If not, a major engine-problem may exist.
Page 60: Drive-Section-Failure
Flight Manual STEMME S6 3.8.4 Drive-Section-Failure In the case of a failure of the drive-section the power-transmission from the engine to the propeller is destroyed. The cause could be a failure of the gear, the drive-shaft, their adapters or couplings. This is indicated by the smell of fire or noise from the power-transmission-system.
Page 61: Fire
Flight Manual STEMME S6 Fire ____________________________________________ 3.9.1 Fire in the Engine-Compartment If the red Fire-Warning light comes on and an alarm signal buzzes or if there is smell of fire or smoke in flight, the following procedure is recommended: In flight:...
Page 62: Electrical Fire
Flight Manual STEMME S6 3.9.2 Electrical Fire Electrical fire in flight: Master-switch Cabin-ventilation OPEN (side-window and/or nozzle) Throttle REDUCE for level-flight approx. v = 62 kts / 115 km/h Off-field-landing PREPARE for next suitable terrain. Warning: When the master-switch is OFF, the COM and all electrical equipment is turned OFF (including elevator-trim and propeller-feathering).
Page 63: 3.10 Emergency-Procedures During Take-Off
Flight Manual STEMME S6 3.10 Emergency-Procedures during Take-Off ______________ 3.10.1 Aborted Take-Off If the take-off-run needs to be aborted (due to a technical malfunction or for flight-safety-reasons), the following procedures are recommended: Throttle IDLE Air-brakes EXTEND Elevator PULL carefully to reduce load...
Page 64: 3.11 Emergency-Landing-Procedures
Flight Manual STEMME S6 3.11 Emergency-Landing-Procedures ___________________ 3.11.1 Off-Field-Landing For an off-field-landing, select the landing-area carefully. Pay great attention to the character of the surface-material in respect of the wheel-load. Landing on soft ground with not enough load-carrying-capacity is connected with a great risk.
Page 65 AIRSPEED. Do not use full air- brakes and be aware of the risk of flipping over. Caution: With its long landing-gear, the S6 has a tendency to flip-over when landing on soft ground. It is recommended to touchdown with MINIMUM AIRSPEED and to pull the elevator full up until standstill.
Page 66 Flight Manual STEMME S6 3.11.2.3 Landing with Damaged Wheel-Brakes Try to land on a grass surface to shorten the ground-roll-distance with roll-resistance. 3.11.2.4 Emergency Landing on water An emergency landing on water has high risks and should be used only as the last option.
Page 67 Flight Manual STEMME S6 Warning: Aircraft with nose-wheels tend to flip-over when landing on water. With the cockpit under water it is almost impossible to open the canopy without pressure-equalization by opening the cabin-ventilation and emergency-window. 3.11.2.5 Landing with Ground-Loop If a collision is not avoidable during the final part of the landing, initiate a ground- loop with enough distance from the obstacle.
Page 68: 3.12 Other Emergencies
Flight Manual STEMME S6 3.12 Other Emergencies ______________________________ 3.12.1 System Malfunctions Warning When a system behaves not normally - make checks as in section 3.12.1.1 through 3.12.1.19. Before the next flight find and eliminate the cause of the system malfunction according to the Maintenance Manual.
Page 69 Flight Manual STEMME S6 When little fuel is available If necessary reduce power- setting and air-speed. Fly without bank-angle or sideslip. If the engine has stopped Do normal airstart-procedure (see section 4.7.3.4) If the fuel-pressure is normal again when using of the auxiliary-fuel-pump (but drops when the auxiliary-fuel-pump were set to OFF) most likely there is a malfunction of the main-fuel-pump or a malfunction of the internal generator.
Page 70 Flight Manual STEMME S6 3.12.1.2 Green Light for Operation of Auxiliary-Fuel-Pump If the green light for the auxiliary-fuel-pump is ON, this is not an emergency. It shows that the auxiliary-fuel-pump is running. If the auxiliary-fuel-pump is set to ON, but with no green light, this can be a malfunction of the auxiliary-fuel-pump or a malfunction of the indication-light.
Page 71 Flight Manual STEMME S6 Fuel Transfer Pump ON until the yellow Low-Fuel- Caution-Light goes OFF and (low fuel in the right main tank) adequate fuel has been transferred into the main-tank. If there is adequate fuel in the right main tank AND the yellow Low-Fuel-...
Page 72 Flight Manual STEMME S6 3.12.1.4 Red MAP-Warning-Light is ON or FLASHING Red MAP-warning-light is continuously ON: The manifold-air-pressure is higher than maximum allowed limit: The manifold-air-pressure is not automatically controlled. In this case, THROTTLE BACK. Control the manifold-air-pressure with throttle (MAP-warning-light must go OFF).
Page 73 Flight Manual STEMME S6 3.12.1.5 Yellow TCU-Caution-Light of Manifold-Air-Pressure-Control is FLASHING A malfunction of the following systems is possible: sensors sensor-lines Turbo-Control-Unit Leakage of airbox CONTROL the RPM and manifold-air-pressure with THROTTLE (red MAP-warning-light must be OFF). Recommended operating limits: ≤ 75% MCP (MAP : ≤...
Page 74 Flight Manual STEMME S6 3.12.1.6 Red External-Alternator-Warning-Light is ON If the red external-alternator-warning-light is ON, this shows that the alternator (with engine-master-switch ON) is not generating electrical power. This is normal if the engine is not running. If the external-alternator-warning-light is ON when the engine is running, this could be a malfunction.
Page 75 Flight Manual STEMME S6 3.12.1.8 Total Electrical Failure A total electrical failure can have several reasons. In any case, the COM and all electrical equipment are not available, including: elevator-trim, propeller pitch control engine-instrumentation, incl. Turbocharger-Control-Unit (TCU) (except manifold-air-pressure-gauge). Also the electrical auxiliary-fuel-pump and the TCU will fail.
Page 76 Flight Manual STEMME S6 3.12.1.9 Loss of Electrical Energy for the Turbo-Control-Unit (TCU) When the TCU has no energy, because of master-switch OFF engine-master-switch OFF or the corresponding circuit-breakers have popped-out. the following procedure is recommended: Turn OFF the waste-gate-actuator with TCU-isolation-switch in the ACTIVATED position (the switch is UP).
Page 77 Flight Manual STEMME S6 3.12.1.10 Sudden Drop of Manifold-Air-Pressure MAP and RPM If the MAP and RPM suddenly drop, together with high noise or a bang, it is most likely that the turbocharger is damaged: SHUT-DOWN the engine as soon as possible. Change to glider- configuration and look for a safe landing-area.
Page 78 Flight Manual STEMME S6 3.12.1.11 Sudden Rise of Manifold-Air-Pressure MAP and RPM If the MAP and RPM suddenly rise and the yellow TCU-caution-light is FLASHING, a malfunction of the turbocharger-control-unit is most likely: Control RPM and MAP with throttle (red MAP-warning-light must be OFF) Recommended operating limits: ≤...
Page 79 Flight Manual STEMME S6 3.12.1.12 Repeating Increase and Decrease of Manifold-Air-Pressure MAP and RPM A periodic increase and decrease of MAP and RPM is most likely caused by oscillations of the manifold-air-pressure-control (while the yellow TCU-caution- light is not flashing). The following procedure is recommended:...
Page 80 Flight Manual STEMME S6 3.12.1.13 Exceeding the Maximum Cylinder-Head-Temperature CHT If the maximum CHT is exceeded, the following procedure is recommended: Cowl-flaps fully OPEN Throttle REDUCE as necessary for safe flight If the CHT does not decrease below maximum, change to glider-...
Page 81 Flight Manual STEMME S6 3.12.1.15 Oil-Pressure below Minimum during Flight If the oil-pressure is below minimum during flight, the following procedure is recommended: If a safe landing can be done in glider-configuration, change to glider- configuration (see section 4.7.3.2) Otherwise REDUCE throttle to the minimum required for a safe flight.
Page 82 Flight Manual STEMME S6 3.12.1.18 Loss of Propeller-Pitch-Control During flight, the pilot must check the RPM continuously. If the RPM changes unintentionally (during flight over a strong electro-magnetic-transmitter or by a malfunction of the pitch-control), the following procedure is recommended: Unintentional pitch-changes, RPM-variation in the „AUTO“-position or...
Page 83 Flight Manual STEMME S6 If the propeller-pitch can NOT be controlled by setting the Constant-Speed- Control to AUTO or to MANU - or when set to MANU the propeller-pitch or the RPM changes without command, the Constant-Speed-Control failed totally. The...
Page 84 Flight Manual STEMME S6 3.12.1.19 Other Malfunctions of the Propeller-Pitch-Control Green take-off position indicator light on the propeller control unit does not come ON: The propeller is not in start-position or the green control-light failed. During „before take-off“-check: Eliminate the cause ! Before LANDING - CHECK at 115 km/h / 62 kts airspeed if the Start- RPM is reached when executing a carefully THROTTLE UP.
Page 85: Vibrations Caused By The Propeller Or The Propulsion System
Flight Manual STEMME S6 3.12.2 Vibrations caused by the propeller or the propulsion system Reasons for abnormal vibrations may be a local propeller-damage or a malfunction of the engine or the drive system. It is recommended to REDUCE the engine-RPM immediately. If the vibrations are not clearly reduced, the...
Page 86: Lightning-Strike Or Possible Lightning-Strike
Flight Manual STEMME S6 3.12.4 Lightning-Strike or possible Lightning-Strike REDUCE air-speed to LESS than maneuvering-speed = 102 kts / 190 km/h. Reduce further as required. CHECK if all flight-controls react as intended Afterwards, immediately LAND on next suitable airfield. Caution: After a lightning-strike, all electrical-systems will most likely...
Page 87: Chapter 4 - Normal Operating Procedures
FLIGHT MANUAL TSA-M, VARIANT S6 Chapter 4 – Normal Operating Procedures Introduction ..................4-2 Air-Speeds for Normal Operation ........... 4-3 Rigging and Derigging ..............4-4 4.3.1 Fuselage ..................4-4 4.3.2 Wing ................... 4-4 4.3.3 Horizontal-Tail-Unit ..............4-6 4.3.4 Fuselage-Fairings ............... 4-7 Fueling of the Aircraft ..............
Page 88: Introduction
FLIGHT MANUAL TSA-M, VARIANT S6 Introduction ____________________________________ This chapter provides the normal operating procedures for the STEMME S6 motorglider in the „S6-T“-variant with the following equipment: - fixed landing-gear - ROTAX 914F engine - 17.2 US gal / 65 l main-tank + optional 17.2 US gal / 65 l auxiliary-tank The following subitems provide checklists for the normal operations.
Page 89: Air-Speeds For Normal Operation
FLIGHT MANUAL TSA-M, VARIANT S6 Air-Speeds for Normal Operation ___________________ All air-speeds for normal flight operation are given as IAS. Take-Off Lift-off-speed 43 kts / 80 km/h (Flaps set to „TO / LDG 1“) Air-speed for initial climb over 50 ft / 15 m obstacle 60 kts / 110 km/h (Flaps set to „TO / LDG 1“)
Page 90: Rigging And Derigging
FLIGHT MANUAL TSA-M, VARIANT S6 Rigging and Derigging ___________________________ Before rigging, clean and grease any connecting-points of the fuselage, wings, empennage and controls. Derigging is done in the reverse sequence of rigging. Warning: Before rigging or de-rigging of the A/C always CHECK:...
Page 91 FLIGHT MANUAL TSA-M, VARIANT S6 Place it on the fuselage. Do NOT jam fuel-lines or connecting-cables. Incline the wing a little bit with the rear down. First place the rear joints then the forward joints onto the frame. Start with the rear wing bolts. Insert the 2 bolts fully into the connectors between the fuselage and inner-wing.
Page 92: Horizontal-Tail-Unit
FLIGHT MANUAL TSA-M, VARIANT S6 14. Extend the air-brake at the outer-wings by moving the deflection-lever by hand. Secure the air-brake with the other hand. 15. Push the outer-wing into the inner-wing leaving a gap of approx. 4 in / 10 16.
Page 93: Fuselage-Fairings
FLIGHT MANUAL TSA-M, VARIANT S6 The forward vertical-edge of the horizontal-tail-unit-flange must be flush with the leading-edge of the vertical-stabilizer. Only then the connection is properly secured. Check correct installation of the horizontal-tail-unit by pushing the leading- edge upwards. 4.3.4 Fuselage-Fairings Install the upper-fairing.
Page 94: Fueling Of The Aircraft
FLIGHT MANUAL TSA-M, VARIANT S6 Fueling of the Aircraft ____________________________ Fuel is filled into the wing-tanks through the filler-caps in the outer area of the inner-wing-section (right side = main-tank, left side = optional auxiliary-tank). Open the filler-caps by pushing and turning the slotted-screw in a counterclockwise-direction with a screwdriver.
Page 95: Daily Inspection
FLIGHT MANUAL TSA-M, VARIANT S6 Daily Inspection ________________________________ The pilot-in-command has to perform an accurate visual inspection of the motorglider before commencing of flight-operations. Warning: Flight-readiness must be checked accurately after the A/C has been rigged or prior to the first flight of the day. Not...
Page 96 FLIGHT MANUAL TSA-M, VARIANT S6 Warning: Before turning the propeller by hand, turn OFF both ignition- circuits AND the master-switch! Activate the wheel-brakes. The cockpit should be occupied by an experienced person. Caution: When refilling coolant in the overflow-reservoir and tightening...
Page 97 FLIGHT MANUAL TSA-M, VARIANT S6 Caution: The A/C must have been parked with the wings leveled for a sufficient time (several hours) before draining. CHECK if drainage-valves close again correctly after operation. If they do not close correctly, there might be dirt in the fuel. While draining fuel there is an increased risk of fire.
Page 98 FLIGHT MANUAL TSA-M, VARIANT S6 Propeller-blades VISUAL INSPECTION for damage. Check condition of blades and spinner. Movement of blade-tips up to 0.1 in / 3 mm tolerable (jiggle tips slightly). Movement of pitch-angle up to 2° tolerable. No unacceptable cracks and no loose edge-guards.
Page 99 FLIGHT MANUAL TSA-M, VARIANT S6 VI. Wing Control-surfaces CHECK for clearance and too much play VISUALY CHECK for damage. Tank-filler caps, drainer and vents VISUALY CHECK for leakage (see section I and chapt. 4.4) Winglets & connection Check for correct mounting...
Page 100: Pre-Flight-Inspection
FLIGHT MANUAL TSA-M, VARIANT S6 Pre-Flight-Inspection ___________________________ 4.6.1 Exterior Inspection The external inspection of the entire A/C should be performed as a walk-around. Check the following items: A/C Documents CHECK Daily inspection Completed? Loading and CG CHECK and within acceptable limits...
Page 101: Interior Inspection
FLIGHT MANUAL TSA-M, VARIANT S6 Right aileron at flap-setting CHECK for transmission of force, „NEUTRAL“ maximum deflection and play Right air-brake CHECK for transmission of force, maximum deflection and play Constant-Speed Propeller CS-Propeller CHECK function 4.6.2 Interior Inspection CHECK before engine-start...
Page 102: Normal Operating Procedures And Recommended Airspeeds
FLIGHT MANUAL TSA-M, VARIANT S6 Normal Operating Procedures and recommended Airspeeds _________________________ Do not operate the throttle abruptly, but always gradually. When the throttle is operated abruptly, the propeller-pitch does not adjust as quickly as the engine- power changes. There is the risk of briefly exceeding the maximum allowed RPM, before the variable-pitch-propeller has adjusted the RPM back to normal.
Page 103 FLIGHT MANUAL TSA-M, VARIANT S6 Auxiliary-fuel-pump ACTIVATE briefly to check function. CHECK for operating-noise, fuel- pressure-gauge still 2.5 ±1.0 (250 ± 100 hPa) / 3.6 ± 1.5 psi. Fuel-transfer-pump ACTIVATE briefly to check function. (only with optional auxiliary-tank) CHECK for operating-noise.
Page 104: Take-Off And Climb
FLIGHT MANUAL TSA-M, VARIANT S6 Warm-up SET engine-RPM to approx. 2200 RPM until oil-temperature and CHT are in the green range. This is faster if the cowl-flaps are closed for the time of the warm-up. 4.7.1.2 Taxiing Avionic-main-switch COM/NAV/XPDR ON and SET (XPDR to STBY)
Page 105 FLIGHT MANUAL TSA-M, VARIANT S6 to 115%, then set propeller-RPM to 2100 RPM. Engine-RPM should be RPM and manifold-air- 5600 − pressure (MAP) should be 39 inHg. At the same time, CHECK wheel- brakes. The a/c may not move. Warning: THROTTLE UP too fast can result in exceeding the engines maximum allowed RPM.
Page 106 FLIGHT MANUAL TSA-M, VARIANT S6 Seatbelts FASTENED Wind-conditions CHECK Parking-brake RELEASE when ready for take-off Wings CHECK if dry or wet. Mind higher lift-off-speed and longer take-off run with wet wings! 4.7.2.2 Take-Off Motorglider ALIGN on RWY Brakes Propeller CHECK settings: must be left switch...
Page 107 FLIGHT MANUAL TSA-M, VARIANT S6 pressure 2.5 ±1.0 (250 ± 100 hPa) / 3.6 ± 1.5 psi. All caution-lights and warning- OFF (only the green indication-lights lights may be ON) Brakes RELEASE Take-off-run Rotation and take-off The A/C takes off by itself from all three wheels at approx.
Page 108: Cruise / Cross-Country-Flying
FLIGHT MANUAL TSA-M, VARIANT S6 4.7.3 Cruise / Cross-Country-Flying 4.7.3.1 Cruise (Powered) Throttle SET cruise-power according to MAP Propeller-RPM ADJUST according to manifold-air- pressure-gauge ==> see RPM-table in section 4.1 Flaps Set to „CRUISE“ for fast cruise. Set to „NEUTRAL“ for normal cruise...
Page 109 FLIGHT MANUAL TSA-M, VARIANT S6 Note: low-fuel-caution-light (yellow LED) indicates malfunction of the pumps. When the light goes ON permanently, the amount of fuel in the feeder-compartment is below the critical amount. The remaining fuel in the feeder- compartment then is 1.3-1.9 US gal / 5-7 l.
Page 110 FLIGHT MANUAL TSA-M, VARIANT S6 4.7.3.4 Soaring Flaps Circling in thermals: „TO / LDG 1“ Flight between thermals: „NEUTRAL“ Warning: The voltage must not fall below the minimum of 11.5V during soaring flight. If the minimum voltage is reached the engine has to be restarted with windmilling immediately.
Page 111 FLIGHT MANUAL TSA-M, VARIANT S6 Engine-master-switch Propeller-RPM SET propeller-RPM to 2100 RPM Propeller-switch left switch MANU, right switch HIGH Note: propeller reaches full pitch after 90 seconds Fuel-shut-off-valve OPEN TCU-self-test CHECK if red MAP-warning-light and yellow TCU-caution-light go ON for approx.
Page 112 FLIGHT MANUAL TSA-M, VARIANT S6 Note: The engine can be started if the propeller has pitched halfway (after approx. 30 seconds). Throttle-up only when the propeller is fully pitched to the T/O-position. (green indication-light is ON). Note: The stopped propeller (in the T/O-position) begins to windmill above approx.
Page 113: Landing In Powered-Configuration
FLIGHT MANUAL TSA-M, VARIANT S6 4.7.4 Landing in Powered-Configuration If the optional left auxiliary-tank is installed, it is recommended to turn ON the fuel-transfer-pump. This makes certain that the feeder-compartment is completely filled. If the fuel-transfer-pump is OFF during the approach and the yellow low-fuel- caution-light goes ON, then the fuel-transfer-pump must be turned ON.
Page 114 FLIGHT MANUAL TSA-M, VARIANT S6 4.7.4.2 Glideslope-Control with Low Engine-Power 60 kts / 110 km/h (recommended Approach-speed for MTOM) keep constant until beginning of flare Trim SET according to approach-speed Flaps SET to „TO / LDG 1„ Cowl-flaps fully OPEN...
Page 115 FLIGHT MANUAL TSA-M, VARIANT S6 Note: If the air-brakes are retracted too quickly when the A/C is on the ground, the A/C may lift off again if it has enough speed. Throttle carefully FULL POWER Warning: THROTTLE UP too fast can result in exceeding the engines maximum allowed RPM.
Page 116: Landing In Glider-Configuration
FLIGHT MANUAL TSA-M, VARIANT S6 Air-brakes RETRACT and LOCK Flaps once the safety-altitude (approx. 50 ft / 15 m) is reached, carefully set to „TO / LDG 1“ (if flaps were set to „LDG 2“ before) Warning: Setting the flaps from „LDG 2“ to „TO / LDG 1“ too quickly can cause the A/C to plunge down unintentionally.
Page 117: After Landing And Parking
FLIGHT MANUAL TSA-M, VARIANT S6 Note: The approach and landing can alternatively be flown with the flaps set to „LDG 2“. However, it is recommended to set this flap-setting only during final approach. 4.7.6 After Landing and Parking 4.7.6.1 After Landing Flaps SET to „NEUTRAL“...
Page 118: Flights At High Altitude
FLIGHT MANUAL TSA-M, VARIANT S6 4.7.7 Flights at High Altitude The actual air-speed (TAS) at high altitudes is above the indicated air-speed (IAS). There is no restriction to the allowed flight-envelope below FL65 (2000m). Above this altitude, the never-exceed speed v is decreased according to the decrease in air-density.
Page 119: Flights In Rain
FLIGHT MANUAL TSA-M, VARIANT S6 Flying at high altitude can cause ice to form on the airframe. This can cause significant disadvantages in the aerodynamic behavior, aircraft mass and CG- position. A considerable decline of flight performance and behavior is possible.
Page 120: Flights In Strong Turbulence
FLIGHT MANUAL TSA-M, VARIANT S6 Land with FLAPS set to NEUTRAL. The A/C has the tendency to float longer than normal and touch-down with a higher speed. The landing- gear’s directional-stability reduces the A/C’s sensitivity to crosswind during the ground-roll.
Page 121: Flights In Icing-Conditions
FLIGHT MANUAL TSA-M, VARIANT S6 4.7.11 Flights in Icing-Conditions Ice and hoar-frost significantly influence the air-flow around the A/C. The mass will increase and flight performance and behavior will decrease significantly. Avoid flights in icing-conditions. In the case of an unintended flight into an area of icing-conditions, leave the area immediately by turning around or reducing altitude.
Page 122: Aerobatics
FLIGHT MANUAL TSA-M, VARIANT S6 4.7.13 Aerobatics Aerobatics are not allowed! Doc.-No.:P400-006.000 E Page: 4-36 Revision: --- Date of Issue: 07. October 2008 Agency approved Date of Rev.: --.--.----...
Page 123: Spins
FLIGHT MANUAL TSA-M, VARIANT S6 4.7.14 Spins Intentional Spins are not allowed! If the aircraft spins unintentionally, follow the emergency procedures according to chap. 3.6. Doc.-No.:P400-006.000 E Page: 4-37 Revision: 2 Date of Issue: 07. October 2008 Agency approved Date of Rev.: 20.05.2011...
Page 124: Chapter 5 - Flight Performance
Flight Manual STEMME S6 Chapter 5 – Flight Performance Introduction ..................5-2 Usage of Performance Tables and Diagrams ........ 5-3 Performance Tables and Diagrams ..........5-4 5.3.1 Corrections of Air-Speed-Indicator / Indication-Error ....5-4 5.3.2 Pressure Altitude and Density Altitude ........5-6 5.3.3...
Page 125: Introduction
Introduction ____________________________________ This chapter contains data about the flight performance which can be expected of the STEMME S6 motorglider in the „S6-T“-version. This data is approved by the appropriate authorities. Also, additional data is given which does not need to be approved.
Page 126: Usage Of Performance Tables And Diagrams
Flight Manual STEMME S6 Usage of Performance Tables and Diagrams _________ The influence of the different variables on the flight performance is shown in the tables and diagrams. This allows for good flight planning when the pilot knows all outside influences and available information.
Page 127: Performance Tables And Diagrams
Flight Manual STEMME S6 Performance Tables and Diagrams _________________ 5.3.1 Corrections of Air-Speed-Indicator / Indication-Error The following air-speed-indicator-correction takes into account the installation error. It does NOT take into account the instrument error of the air-speed- indicator. All air-speed values in this Flight Manual are indicated air-speeds (IAS).
Page 128 Flight Manual STEMME S6 Illustration 5-1: Corrections of Air-Speed-Indicator (For information) This airspeed calibration is valid for powered as well as unpowered flight and also for all flap settings. Doc.-No.:P400-006.000 E Page: 5-5 Revision: 1 Date of Issue: 07. October 2008 Agency approved Date of Rev.: 28.01.2011...
Page 129: Pressure Altitude And Density Altitude
Flight Manual STEMME S6 5.3.2 Pressure Altitude and Density Altitude The flight performance of the aircraft depends on the air density or density altitude. To determine the density altitude, the following diagram can be used. (This may be needed to determine the engine power.) If the QNH is known (this can be read from the altimeter), the density altitude can be calculated with the temperature.
Page 130: Isa (International Standard Atmosphere)
Flight Manual STEMME S6 5.3.3 ISA (International Standard Atmosphere) ISA +30°C / 54°F ISA +20°C / 36°F ISA +10°C / 18°F ISA -10°C / 18°F ISA -20°C / 36°F Illustration 5-3: International Standard Atmosphere 5.3.4 Stall Speed and Minimum Air-Speeds The stall speed and lowest flying speed of the motorglider depends on the configuration of the aircraft and the mode of operation.
Page 131 Flight Manual STEMME S6 Caution: Stall speed increases with weight and g-load. In turns stall speed depends on bank angle and corresponding g-load. 5.3.4.1 Stall Speed and Minimum Air-Speed in Powered Flight • Configuration: 8.86 in / 225 mm behind Most Forward CG-Location •...
Page 132 Flight Manual STEMME S6 Note: If the throttle is set to IDLE and the CG-location is far aft, then slightly lower stall speeds might be reached. The aircraft might drop a wing, even if the flight controls are not against the aft stop.
Page 133: Wind-Components
Flight Manual STEMME S6 Caution: In the glider-configuration stall warning for the pilot is ONLY through aerodynamic buffeting. The onset of buffeting begins about 3 to 4 kts / 5 to 8 km/h above the stall. Note: If the CG-location is far aft, then slightly lower stall speeds might be reached.
Page 134: T/O-Ground-Roll And T/O-Distance At Mtom
Flight Manual STEMME S6 5.3.6 T/O-Ground-Roll and T/O-Distance at MTOM • Conditions: FULL POWER / MTOP Throttle (115%) • „TO / LDG 1“ Flaps • = 43 kts / 80 km/h at Rotating Speed (IAS) 1874 lbs / 850 kg •...
Page 135 Flight Manual STEMME S6 Pressure Alt T/O-Distance Temperature T/O-Ground-Roll above MSL (50 ft / 15m) [ft] [°F] [°C] [ft] [ft] 1115 1279 1369 1135 1640 1310 1083 1499 1112 1606 1149 1335 3280 1000 1066 1542 1219 1762 1305 1889...
Page 136: Climb Performance
Flight Manual STEMME S6 5.3.7 Climb Performance • Conditions: FULL POWER / MTOP Throttle (115%) • „NEUTRAL“ Flaps • = 62 kts / 115 km/h at Air-speed, best rate-of-climb 1874 lbs / 850 kg (IAS) • 0 - 16400 ft / 0 – 5000 m...
Page 137: Landing-Distance
Flight Manual STEMME S6 5.3.10 Landing-Distance • Conditions: IDLE Throttle • 2000 RPM Engine-RPM • „TO / LDG 1“ Flaps • v = 60 kts / 110 km/h at Approach-speed (IAS) 1874 lbs / 850 kg • low pitch, Propeller...
Page 138: Polars For Soaring Flight
Flight Manual STEMME S6 5.3.11 Polars for Soaring Flight Not yet available Doc.-No.:P400-006.000 E Page: 5-15 Revision: --- Date of Issue: 07. October 2008 Date of Rev.: --.--.----...
Page 139: Maximum Endurance And Range
Flight Manual STEMME S6 5.3.12 Maximum Endurance and Range • Conditions: Throttle • „NEUTRAL“ Flaps • 97kts / 180 km/h Speed • 1874 lbs / 850 kg A/C-Mass • 5.4 gal/h / 20.4 l/h Fuel-consumption • 17.2 US gal / 65 l...
Page 140 Flight Manual STEMME S6 Chapter 6 – Mass and Balance / Equipment Introduction ..................6-2 Aircraft Weights ................6-3 6.2.1 State during Weighing ..............6-3 Empty-Mass and CG-Location ............6-5 6.3.1 Logsheet for Report of Empty-Mass and CG-Location ....6-5 Operating-Mass and Operating-CG ..........
Page 141: Introduction
Flight Manual STEMME S6 Introduction ____________________________________ The motorglider will only reach the flight performance and handling characteristics described in this operations manual if it is operated in the safe limits for loading and for the center-of-gravity (CG). The pilot-in-command is responsible for the correct loading of the aircraft within the loading-limits and CG-limits.
Page 142: Aircraft Weights
Flight Manual STEMME S6 Aircraft Weights _________________________________ If ANY changes to the delivery-configuration of the aircraft are made, the empty- mass must be determined again. This is needed for all of the following calculations. The state of the aircraft and its equipment when weighing must be defined precisely.
Page 143 Flight Manual STEMME S6 The reference plane (RP) is located at the leading-edge of the inner-wing at • the wing-root. It is aligned vertically to the longitudinal-axis. This plane creates a reference line on the ground. Longitudinal-inclination: Place a wedge 1000:42 (2,4° = 2°26‘) on the rear •...
Page 144: Empty-Mass And Cg-Location
Flight Manual STEMME S6 Empty-Mass and CG-Location ______________________ The current empty mass and empty-CG-location must be documented chronologically in a report of empty-mass and CG-location (section 6.3.1). Every change in the empty-mass or empty-CG-location (which might be caused by changes in equipment, repainting, repairs or similar) must be documented in this report.
Page 145 Flight Manual STEMME S6 Report of Empty-Mass and CG-Location (continuous report of changes to the aircraft structure and/or equipment) Registration No.: Serial-No.: Sheet No.: ....STEMME S6 Current Empty-Mass Cleared by Authorized Personnel Con. Description of Mass Lever to Moment...
Page 146: Operating-Mass And Operating-Cg
Flight Manual STEMME S6 Operating-Mass and Operating-CG __________________ Only operate the aircraft within the loading-limits and limits for the CG-location. The current operating-mass and operating-CG can only be calculated by determining the payload for the planned flight. To determine the operating-mass and operating-CG graphically and/or through calculations, use the tables and diagrams given in the following sections: 6.4.1 Mass-Moments and Payload: Loading-diagram...
Page 147 Flight Manual STEMME S6 Divide the results from row 7 to determine the lever of the CG in the T/O- configuration. These values must be within the allowed limits. If this is not the case, payload and fuel must be adjusted.
Page 148: Mass-Moments And Payload
Flight Manual STEMME S6 6.4.1 Mass-Moments and Payload Doc.-No: P400-006.000 E Page: 6-9 Revision: --- Date of Issue: 07. October 2008 Date of Rev.: --.--.----...
Page 149: Calculation Of Proper Loading For Flight
Flight Manual STEMME S6 6.4.2 Calculation of Proper Loading for Flight STEMME S6 Calculation of the proper loading for Reg.-No.: .... flight Mass Moment [kg] [kgm] Example: 675 kg Example: 306 kgm Empty-Mass and Empty-Mass- Moment (from current Report of...
Page 150 Flight Manual STEMME S6 Note: When calculating the CG-position without including the change of fuel-weight during flight, the CG must be within the following limits: 8,82 (+ 1,26) in to 16,10 (- 1,30) in / (behind RP). 224 (+ 32) mm to 409 (- 33) mm Doc.-No: P400-006.000 E...
Page 151: Equipment List And Installed Equipment List
Flight Manual STEMME S6 Equipment List and Installed Equipment List ________ The equipment list is a list of all certified equipment which can be installed in the STEMME S6. The installed equipment list is a list of all equipment which is actually installed in the aircraft.
Page 152: Equipment List
Flight Manual STEMME S6 6.5.1 Equipment List Serial-No.: Reg. No.: Date: STEMME S6 Lever Manu- Description Type Spec. No. Mass facturer [kg] + or - Altimeter Winter 4FGH40 Altimeter Unit. Instr. 5934 Ser. Air Speed Winter 7FMS443 Indicator Compass Airpath...
Page 153 Flight Manual STEMME S6 Serial-No.: Reg. No.: Date: STEMME S6 Lever Manu- Description Type Spec. No. Mass facturer [kg] + or - I 24 I 25 I 26 I 27 I 28 I 29 I 30 I 31 I 32...
Page 154 Flight Manual STEMME S6 Serial-No.: Reg. No.: Date: STEMME S6 Lever Manu- Description Type Spec. No. Mass facturer [kg] + or - COM/NAV/GPS Garmin GNS 430W Electronic Flight Dynon EFIS Information Sys. D-10A Transponder Garmin GTX 330 Audio Panel Garmin...
Page 155 Flight Manual STEMME S6 Serial-No.: Reg. No.: Date: STEMME S6 Lever Manu- Description Type Spec. No. Mass facturer [kg] + or - Safety Belts Gadringer Stall Warning STEMME Cabin Heating STEMME Aerotow Tail Tost Clutch Tow Bar STEMME Release STEMME...
Page 156: Chapter 7 - Description Of The Motorglider And Its Systems And Equipment
FLIGHT MANUAL TSA-M, VARIANT S6 Chapter 7 – Description of the Motorglider and its Systems and Equipment Introduction................. 7-3 Airframe ..................7-4 7.2.1 Fuselage ................. 7-4 7.2.2 Wing-System ................7-4 7.2.3 Empennage ................7-4 Flight-Controls ................7-5 7.3.1 Ailerons ................... 7-5 7.3.2...
Page 157 FLIGHT MANUAL TSA-M, VARIANT S6 7.11.5 Fire-Warning ................. 7-26 7.11.6 Engine-Cooling-System ............7-27 7.11.7 Lubrication-System ............... 7-30 7.11.8 Load-Transmission and Transmissions ........ 7-31 7.12 Fuel-System ................7-33 7.12.1 Design of the Fuel-System ........... 7-33 7.12.2 Control-Elements and Gauges in the Cockpit ....... 7-34 7.12.3...
Page 158: Introduction
There are also user-notes for each system. The description of installed non-standard systems is given in chapter 9. Additional explanations of the components and systems of the Stemme S6 are given in the maintenance manual (Stemme Doc.-No.: P500-006.000). Doc.-No.: P400-006.000 E...
Page 159: Airframe
FLIGHT MANUAL TSA-M, VARIANT S6 Airframe _______________________________________ 7.2.1 Fuselage The front section of the fuselage – including the cockpit – is constructed from carbon-fiber-composites. For additional stiffness and a decrease in mass, it is reinforced with longitudinal-stringers and circular-frames. The mid-section is made of a steel-tube-framework with fairings made of carbon-fiber-composites.
Page 160: Flight-Controls
FLIGHT MANUAL TSA-M, VARIANT S6 Flight-Controls __________________________________ The control-forces are transmitted to the flight-controls with control-rods or control-cables. Control-brackets – made of rust-proof coated steel – are laminated into each flight-control. The bearings are prepared for easy movement at all times.
Page 161: Rudder And Nose-Wheel-Steering
FLIGHT MANUAL TSA-M, VARIANT S6 7.3.3 Rudder and Nose-Wheel-Steering Design: CFC-Sandwich Mounting: Rudder mounted on top and bottom, 1 control-connector on bottom Operation: The rudder-movement is transmitted in the front section and mid-section of the fuselage by control-cables. In the rear section this changes to control-rods.
Page 162: Adjustable Rudder-Pedals
FLIGHT MANUAL TSA-M, VARIANT S6 7.3.5 Adjustable Rudder-Pedals The position of the rudder-pedals can be adjusted. This allows for a safe and comfortable operation of the rudder-pedals, even if the seating position and size of the pilot changes. Note: The rudder-pedals must be locked properly after they have been...
Page 163: Air-Brakes
FLIGHT MANUAL TSA-M, VARIANT S6 Air-Brakes _____________________________________ The Schempp-Hirth -style air-brakes are located at the inner-section of the outer-wing. Design: Air-brake designed as aluminum-section, sealing-plates made of CFC, placed at top ends of air-brakes Mounting: 2 rotational-shafts in each air-brake-box...
Page 164: Operating-Elements
Crew Operation Manual as well as in the maintenance manual. For operation instructions of the installed equipment refer to the maintenance manual of the STEMME S6 (STEMME Doc.-No.: P500-006.000) and to the operation manuals of the manufacturer provided for the installed equipment.
Page 165 FLIGHT MANUAL TSA-M, VARIANT S6 Illustration 7-1: Overview of the Control-Elements in the Cockpit Doc.-No.: P400-006.000 E Page: 7-10 Revision: 1 Date of Issue: 07. October 2008 Date of Rev.: 28.01.2011...
Page 166 FLIGHT MANUAL TSA-M, VARIANT S6 Canopy-Locks White handles on left and right side of canopy-frame (additional rear-canopy-hook at upper rear middle of canopy-end) Air-Brake-Lever Blue lever on left cockpit-wall and on left side of center-console Cabin-Ventilation Black pull-button, one at each seat to control cabin-...
Page 167: Instrument-Panel
FLIGHT MANUAL TSA-M, VARIANT S6 Instrument-Panel ________________________________ 7.6.1 Layout of the Instrument-Panel The illustration shows the layout and position of the most important control- elements and instruments on the instrument-panel in the standard-configuration. Illustration 7-2: Standard Layout of the Instrument-Panel Doc.-No.: P400-006.000 E...
Page 168 FLIGHT MANUAL TSA-M, VARIANT S6 Instruments and indicators on the instrument-panel: Air-Speed-Indicator (15) Manifold-Air-Pressure-Gauge Winter 7FMS443 Spare (opt. Soaring-Computer) (16) ASI (optional Fuel-Flow-Indicator) Electronic-Flight-Information- (17) Fire Warning System (EFIS) Dynon D-10A VOR/ILS Indicator (CDI) (18) Oil-Temperature-Gauge Garmin Gl-106A Vertical-Speed-Indicator /...
Page 169: Control-Elements Of The Instrument-Panel
Control-Elements of the Instrument-Panel The following illustration shows the layout of the additional control-elements of the instrument-panel in the standard-configuration. S1 S2 S3 S4 S5 S6 S7 Illustration 7-3: Control-Elements of the Instrument-Panel Control-elements of the instrument-panel: (1) Master-Switch (Batt) and Switch for...
Page 170: Landing-Gear
FLIGHT MANUAL TSA-M, VARIANT S6 Landing-Gear ___________________________________ The landing-gear is a non-retractable tricycle-configuration with steerable nose- wheel. To reduce drag and noise, all struts and wheels have aerodynamic fairings. 7.7.1 Nose-Gear and Steering The nose-gear is made of a steel-strut which is stiff to torque. It is attached to the forward fuselage-section at an attachment-plate by screws.
Page 171: Seats And Safety-Belts
FLIGHT MANUAL TSA-M, VARIANT S6 Seats and Safety-Belts ___________________________ The seats are made of cushioned seat-pans, which are integrated into the cockpit-floor. Their positions are adjustable at the top and bottom (optional), so that they can be positioned ergonomically. The upper sections of each backrest are designed as head-rests.
Page 172: Baggage-Compartment
FLIGHT MANUAL TSA-M, VARIANT S6 Baggage-Compartment ___________________________ The baggage-compartment is located at the front of the tail-boom, just behind the connector-frame between the mid-section and rear section of the fuselage. A maximum payload of 44 lbs / 20 kg may be loaded into the compartment. It can be loaded through a forward-opening door at the top of the fuselage.
Page 173: 7.10 Canopy And Cockpit
FLIGHT MANUAL TSA-M, VARIANT S6 7.10 Canopy and Cockpit _____________________________ 7.10.1 Canopy The canopy is made of plexiglas and framed by a thin canopy-frame made of CFC. This setup allows for good all-round-visibility. The canopy is hinged at the front of the cockpit and opens in a forward direction. A convenient entry is therefore possible.
Page 174: Entry
FLIGHT MANUAL TSA-M, VARIANT S6 7.10.2 Entry The method of entry varies individually and depends on the size and agility of the pilot. The following procedure is a convenient and comfortable method of entering the aircraft: Stand with your back facing the cockpit.
Page 175: 7.11 Propulsion-System And Engine
FLIGHT MANUAL TSA-M, VARIANT S6 7.11 Propulsion-System and Engine ____________________ 7.11.1 Engine and General Information The installed engine is a model ROTAX 914 F2: 4-cylinder 4-stroke Otto-engine in opposed-cylinder design including • turbocharger with electronic manifold-air-pressure (MAP) control and integrated reduction-gear Liquid-cooled cylinder-heads and ram-air-cooled cylinders •...
Page 176: Propeller
FLIGHT MANUAL TSA-M, VARIANT S6 7.11.2 Propeller The installed propeller is a model MTV 7-A / 170-51 with constant-speed- control-unit. Electrically-adjustable 3-Blade Constant-Speed Propeller, continuously • adjustable from T/O-setting to glider-setting, electronic constant-speed control, control unit: P120-A (DB) Forged/milled hub made of light-alloys. Blasted and anodized surface-finish •...
Page 177 FLIGHT MANUAL TSA-M, VARIANT S6 Illustration 7-4: Control-Elements for the Propeller-Control-Unit (Illustration by mt-Propeller) The standard position of the left flip-switch is „AUTO“, for the right flip-switch it is „STOP“. The propeller-RPM set with the rotary-switch will be held constant during the flight.
Page 178: Operation Of The Engine
FLIGHT MANUAL TSA-M, VARIANT S6 Warning: Before rotating the propeller by hand (for example to pump oil through the engine before a cold-start), REMOVE the ignition-key and set the master-switch to OFF! Warning: Do NOT turn the propeller against its regular direction of motion! Caution: Avoid high propeller-RPM on the ground.
Page 179: Turbo-Charger And Control-System
FLIGHT MANUAL TSA-M, VARIANT S6 Caution: The throttle settings of 100% and 115% power can be set without looking at the throttle. 100% power is set once the first detent is reached. To set 115% power, the throttle needs to be pushed past the first detent and against the forward stop.
Page 180 FLIGHT MANUAL TSA-M, VARIANT S6 The inducted air is compressed (and warmed to some extent) in the turbo- charger. Therefore, a carburator-heat-system is not necessary because ice will not form in any flight-conditions. Warning: Just before reaching the setting for take-off-power (between 108% and 110% power), the target-MAP will rise in a step.
Page 181: Fire-Warning
7.11.5 Fire-Warning The engine compartment of the STEMME S6 is equipped with a fire detecting system which in case of an engine fire gives a clear warning signal by a red warning light in combination with an acoustic alarm signal.
Page 182: Engine-Cooling-System
FLIGHT MANUAL TSA-M, VARIANT S6 7.11.6 Engine-Cooling-System The heat dissipation of the liquid-cooling-system for the cylinder-heads occurs in a aluminum-gill-radiator. An oil-cooler for the lubrication-circuit is placed below the aluminum-gill-radiator. Both coolers are placed below the engine and are supplied with ram-air from the central NACA-inlet between the main-landing- gear-legs on the bottom of the fuselage.
Page 183 FLIGHT MANUAL TSA-M, VARIANT S6 Information about the Liquid-Cooling-System: The following illustration shows the schematics of the liquid-cooling-system: Illustration 7-5: Schematics of the Liquid-Cooling-System (Illustration by ROTAX) Expansion-Tank The expansion-tank (1) is located at the top of the engine. It has a overpressure-valve and breather-valve which lead to the overflow-bottle (4).
Page 184 FLIGHT MANUAL TSA-M, VARIANT S6 The coolant-circuit is a closed system. A camshaft-driven water-pump circulates the coolant through the system. To allow coolant to escape into the overflow- bottle when warming up, an overpressure-valve is installed. When the coolant contracts again during the cool-down-phase, coolant is sucked into the circuit again.
Page 185: Lubrication-System
FLIGHT MANUAL TSA-M, VARIANT S6 7.11.7 Lubrication-System The ROTAX 914 F2 is lubricated by a pressurized dry-sump lubrication-system. Its main-oil-pump has an integrated pressure-control-mechanism. Additionally, a suction-pump is installed. Both oil-pumps are driven by the camshaft. Illustration 7-6: Schematics of the Engine’s Lubrication-System...
Page 186: Load-Transmission And Transmissions
The RPM of the long-shaft is reduced to the propeller-RPM with the front-drive, which is located in the nose of the A/C. The drive-shaft of the front-drive is screwed to the propeller-hub. The drive is a belt-drive (model: STEMME 050.251), which is encased in cast-magnesium. The gear-belt-discs are made of aluminum and have a transmission-ratio of i = 1.100.
Page 187 FLIGHT MANUAL TSA-M, VARIANT S6 7.11.8.2 Long-Shaft The power-transmission between the engine and the front-drive is realized with a long-shaft made of carbon-fiber-composites (CFC). It runs from the front-end of the fuselage through a tunnel in the center-console to the output-gear of the engine.
Page 188: 7.12 Fuel-System
FLIGHT MANUAL TSA-M, VARIANT S6 7.12 Fuel-System ____________________________________ 7.12.1 Design of the Fuel-System The main-tank is the integral-tank in the front area of the right wing. It has a fuel- capacity of 17.2 US gal / 65 l, of which 2.1 US gal / 8 l are designed as a separate feeder-compartment.
Page 189: Control-Elements And Gauges In The Cockpit
FLIGHT MANUAL TSA-M, VARIANT S6 Caution: Keep the aircraft leveled during fueling! Also, do NOT fill the tanks to the top-edge in warm weather-conditions (keep in mind the thermal-expansion of the fuel). Else fuel might leak through the fuel-tank-vents. The fuel-tank-vents end at the wing-joints between the inner-wing and outer- wings.
Page 190 FLIGHT MANUAL TSA-M, VARIANT S6 Illustration 7-8: Layout of Fuel-System Doc.-No.: P400-006.000 E Page: 7-35 Revision: 1 Date of Issue: 07. October 2008 Date of Rev.: 28.01.2011...
Page 191: Measurement Of The Amount Of Fuel
FLIGHT MANUAL TSA-M, VARIANT S6 If the optional left fuel-tank is installed, then fuel can be moved from the left auxiliary-tank to the right main-tank by operating the fuel-transfer-pump. Operation of the fuel-transfer-pump is monitored by the amount of fuel in the right tank (automatic fuel-transfer): •...
Page 192 FLIGHT MANUAL TSA-M, VARIANT S6 Wet length of the dip stick: Fuel level in the tank: 100 … 110 mm 100 % 60 … 70 mm 75 % 30 … 40 mm 50 % 2 … 5 mm 25 % A fuel amount of less than 25% cannot be determined by using the dip stick.
Page 193: 7.13 Electrical-System
FLIGHT MANUAL TSA-M, VARIANT S6 7.13 Electrical-System _______________________________ 7.13.1 Power-Supply and Battery-System The rated-voltage of the electrical-system is 12V. The starter-battery is designed as a maintenance-free lead-battery with AGM- technology. The required minimum-capacity is 16Ah. The battery-mounting is located in the rear area of the engine-compartment, outside of the fire-wall.
Page 194: Electrical Consumers And Circuit-Breaker-System
FLIGHT MANUAL TSA-M, VARIANT S6 Avionics-Bus: supplies all avionics and is connected to the main-bus with the „Avionics“-isolation-switch. The avionics-bus is made up of the circuit-breakers A4 – A10 (Ill. 7-2). Internal-Generator-Bus: supplies main-fuel-pump independently from the remaining electrical system. The internal-generator-bus is designed as a distribution-box with fuses and is located on the control-board in the engine-compartment (at the rear of the fire-wall).
Page 195 FLIGHT MANUAL TSA-M, VARIANT S6 Circuit Circuit-Breaker Fuse (A) Isolation-Switch Cons. int. Generator Fuel-Pressure-Difference- Gauge Tachometer Ignition-Delay Fuel-Flow-Gauge Fuel-Gauge L Fuel-Gauge R Fuel-Transfer-Pump Auxiliary-Fuel-Pump Avionics-Bus The ratings of the circuit-breakers used depend on the information given by the manufacturers of the installed equipment.
Page 196 FLIGHT MANUAL TSA-M, VARIANT S6 Subordinated Switches: Engine-Master- Turns ON or OFF all electrical devices needed for Switch: engine-operation (starter, propeller-pitch-control, engine-instruments and similar) by connecting them to the battery or external-alternator. This switch is mechanically coupled to the „Batt“-Master-Switch. To turn ON the engine-bus with the „Gen“-master-switch,...
Page 197: Gauges And Indicator-Lights
FLIGHT MANUAL TSA-M, VARIANT S6 7.13.6 Gauges and Indicator-Lights Voltmeter indicates the voltage at the main-bus Ampèremeter indicates the electric-current drawn from the battery (discharge) or flowing into the battery (charge) Internal-Generator- The yellow light goes ON if the output-voltage of...
Page 198: 7.14 Static-Pressure- And Dynamic-Pressure-System
FLIGHT MANUAL TSA-M, VARIANT S6 7.14 Static-Pressure- and Dynamic-Pressure-System ______ A tubular probe measures the total-pressure, static-pressure and total-energy- compensated-pressure (TEC-pressure). It is located at the left wing-joint between the inner-wing and outer-wing. The pressure-sensing-lines lead to the center of the wing. There, they need to be connected to the adapters of the mid- section of the fuselage.
Page 199: 7.15 Stall-Warning
FLIGHT MANUAL TSA-M, VARIANT S6 7.15 Stall-Warning ___________________________________ If the air-speed drops to less than 1.1 times the stall-speed at any flap-setting, then stall-horn will sound. The horn is installed in the instrument-panel. The stall-warning-system is designed as a small wind-vane with a trigger-switch. It is mounted at the leading-edge of the left wing, near the wing-joint.
Page 200: Chapter 8 - Handling, Servicing And Maintenance
Flight Manual STEMME S6 Chapter 8 – Handling, Servicing and Maintenance Introduction ..................8-2 Maintenance-Intervals of the Motorglider ........8-3 Changes or Repairs ................. 8-4 Ground-Handling and Road-Transport .......... 8-5 8.4.1 Taxiing and Towing on the Ground ..........8-5 8.4.2 Parking..................
Page 201: Introduction
Flight Manual STEMME S6 Introduction ____________________________________ This section describes procedures recommended for the correct handling of the motorglider on the ground as well as for the servicing of the motorglider. Certain check-regulations and maintenance-regulations are mentioned. They need to be observed if the motorglider is to retain the performance and reliability of a new aircraft.
Page 202: Maintenance-Intervals Of The Motorglider
Engine (see maintenance-manual STEMME S6): • lowest interval: 50 h To retain the airworthiness of the A/C, an ANNUAL check (see maintenance- manual S6) must be performed at least once per year. This is independent of the operating-hours of the A/C. Caution: Unscheduled maintenance...
Page 203: Changes Or Repairs
Flight Manual STEMME S6 Changes or Repairs _____________________________ Changes Changes which may affect the airworthiness of the certified aircraft-model need to be authorized by the appropriate authorities. A statement from the manufacturer must be obtained. This is to ensure the continuing airworthiness of the motorglider.
Page 204: Ground-Handling And Road-Transport
Flight Manual STEMME S6 Ground-Handling and Road-Transport _______________ 8.4.1 Taxiing and Towing on the Ground When towing the motorglider behind a car, a person must be seated at the pilot’s seat. Otherwise, the front-wheel-steering will not be engaged. Only drive with walking-speed.
Page 205: Storage/Hangaring
Flight Manual STEMME S6 8.4.3 Storage/Hangaring The motorglider should only be parked or stored in well-ventilated rooms. Closed and weather-proof transport-trailers need to be equipped with adequate ventilation-openings. Keep in mind, that the motorglider and its compontens should be stored in a tension-free manner.
Page 206 Flight Manual STEMME S6 • The outer-wings should be transported standing on their leading-edges. Use the method previously described for the inner wing. Make sure each outer- wing is placed on two large, cushioned areas of contact. • All parts must be secured against shifting and rotation.
Page 207: Cleaning And Care
Even though the surfaces of composite-aircraft are robust and tough, they should be cared for. Keep the following information about the cleaning and care of the A/C in mind (see the maintenance-manual of the S6 for additional information): If the motorglider will be operated year-round, then it must be cared in such a manner that no rust will form on the connecting elements of the fuselage, wings and horizontal stabilizer.
Page 208: Canopy
Flight Manual STEMME S6 • Keep the static-pressure-ports and dynamic-pressure-ports free of dirt and water. Check regularly. • Use commercial rinsing-agents or soap-suds only rarely to remove tough dirt. • Benzines and alcohols may be used briefly (for example to remove contamination exhaust-gas-outlet).
Page 209: Propeller
Flight Manual STEMME S6 8.5.3 Propeller Damage to the propeller and operational malfunctions need to be inspected by a knowledgeable person. The surface (PU-finish and acrylic-finish) can be cleaned using commercial • cleaning-agents and preserving-agents intended for cars. Prevent moisture from reaching the wooden core. When in doubt, let the •...
Page 210: Trouble-Shooting Of The Engine
Flight Manual STEMME S6 Trouble-Shooting of the Engine ____________________ Warning: Maintenance and servicing must only be performed by qualified technicians who have received specific training for this engine-model. If the following procedures are not successful, contact an authorized business. The engine must...
Page 211 Flight Manual STEMME S6 Difficulties in cold weather: PRE-HEAT engine idle-RPM too low • INSTALL fully-charged battery, battery-power too low • PERFORM jump-start. When performing a cold-start oil- high oil-pressure • pressure up to 102 psi / 7 bar is not an indication of engine-problems.
Page 212: Chapter 9 - Supplements
Flight Manual STEMME S6 Chapter 9 – Supplements Introduction ..................9-2 List of Supplemental and Alternative Equipment ......9-3 Doc.-No.:P400-006.000 E Page: 9-1 Revision: 1 Date of Issue: 07. October 2008 Date of Rev.: 28.01.2011...
Page 213 Flight Manual STEMME S6 Introduction ____________________________________ This section gives supplemental information about supplemental or alternative equipment installed in the motorglider, which has not been covered in the previous text of the Flight Manual (chapters 1 through 8). This information is also needed for a safe operation of the A/C.
Page 214 This applies to alternative equipment already installed at delivery as well as for equipment later installed. This directory serves as a table of contents for chapter 9. Serial-No.: ……………. Supplements Stemme TSA-M, variant S6 Registration: ……………. Title Pages Revision Date Inst.
Page 215 Flight Manual STEMME S6 < page intentionally left blank > Doc.-No.:P400-006.000 E Page: 9-4 Revision: --- Date of Issue: 07. October 2008 Date of Rev.: --.--.----...
