Page 1 FLUGPL ATZSTRASSE F2, NR. 6-7 • GERMANY • 15344 STRAUSBERG ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DOCUMENT NUMBER • L530-912830 DATE OF ISSUE • JANUARY 31, 2020 C. 01 DOCUMENT NUMBER: REVISION: 01 L530-912830 ISSUE JANUARY 31, 2020 DATE: AUG 03, 2020...
Page 2 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 This Illustrated Parts Catalog (IPC) is applicable for the Aircraft STEMME S10, Variant S12. CONTACT STEMME AG Flugplatzstrasse F2, Nr. 6-7 15344 Strausberg, Germany Phone: +49.3341.3612-0 E-mail: sevice@stemme.com Web: www.stemme.com All rights reserved.
Page 3 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 RECORD OF REVISIONS The latest revisions have to be part of the catalog. The effective pages of any revision, including the list of revision levels, must be inserted into the catalog upon receipt.
Page 4 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 5 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 LIST OF EFFECTIVE PAGES * This page is intentionally left blank. CHAPTER PAGE REV. NO. DATE EFFECTIVITY Titel Page D.01 AUG 03, 2020 Titel Page D.02 JAN 31, 2020 D.01 APR 14, 2021...
Page 6 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY CHAPTER 10 10-TOC D.01 JAN 31, 2020 10-10-00 P.01 JAN 31, 2020 10-10-00 D.01 JAN 31, 2020 10-10-00 P.02 JAN 31, 2020 10-10-00 D.02 JAN 31, 2020 10-10-00 P.03...
Page 7 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY CHAPTER 12 12-TOC D.01 JAN 31, 2020 12-12-13 P.01 JAN 31, 2020 12-12-13 D.01 JAN 31, 2020 12-17-00 P.01 JAN 31, 2020 12-17-00 D.01 JAN 31, 2020 12-50-00 P.01...
Page 8 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY 24-00-30 P.01 JAN 31, 2020 24-00-30 D.01 JAN 31, 2020 24-00-30 P.02 JAN 31, 2020 24-00-30 D.02 JAN 31, 2020 Aircraft equipped with Second Main 24-32-25 P.01...
Page 9 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY 25-71-34 P.01 JAN 31, 2020 25-71-34 D.01 JAN 31, 2020 CHAPTER 27 27-TOC D.01 JAN 31, 2020 27-10-23 P.01 JAN 31, 2020 27-10-23 D.01 JAN 31, 2020 27-10-23 P.02...
Page 10 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY 27-62-13 D.04 JAN 31, 2020 27-62-23 P.01 JAN 31, 2020 27-62-23 D.01 JAN 31, 2020 27-62-23 P.02 JAN 31, 2020 27-62-23 D.02 JAN 31, 2020 27-62-23 P.03...
Page 11 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY 28-00-20 P.06 SEP 14, 2020 S/N 12-001, 12-035 - 12-999 28-00-20 D.06 SEP 14, 2020 S/N 12-001, 12-035 - 12-999 28-00-20 P.07 SEP 14, 2020 S/N 12-001, 12-035 - 12-999 28-00-20 D.07...
Page 12 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY S/N 12-019 - 12-031, 12-033 - 12-999 32-40-10 D.01 AUG 31, 2020 OR SB 980051 32-44-35 P.01 JAN 31, 2020 32-44-35 D.01 JAN 31, 2020 CHAPTER 33 33-TOC D.01...
Page 13 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY CHAPTER 52 52-TOC D.01 JAN 31, 2020 52-10-10 P.01 JAN 31, 2020 52-10-10 D.01 JAN 31, 2020 CHAPTER 53 53-TOC D.01 JAN 31, 2020 53-00-00 P.01 JAN 31, 2020 53-00-00 D.01...
Page 14 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY 57-20-46 D.01 JAN 31, 2020 Aircraft equipped with 25 Meter Wing 57-20-47 P.01 JAN 31, 2020 Aircraft equipped with 25 Meter Wing 57-20-47 D.01 JAN 31, 2020...
Page 15 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 CHAPTER PAGE REV. NO. DATE EFFECTIVITY 71-84-13 P.01 JAN 31, 2020 71-84-13 D.01 JAN 31, 2020 71-84-13 P.02 JAN 31, 2020 71-84-13 D.02 JAN 31, 2020 71-84-13 P.03 JAN 31, 2020 71-84-13 D.03...
Page 16 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 17: Table Of Contents
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 TABLE OF CONTENTS Record of Revisions List of Effective Pages Table of Contents Introduction General ATA 100 Numbering System Explanation of used IPC Symbols Ordering Effectivity Revisions Abbreviations Life Limit Components 10 ......Parking, Storage, Return to Service 10-10-00 ....Parking and Rigging...
Page 18 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 25 ......Equipment / Furnishings 25-00-10 ....Cabin Equipment 25-20-15 ....Seatrest - Assembly 25-62-23 ....Emergency Locator Beacon - Middle Fuselage 25-71-34 ....Battery Box Structure 27 ......Flight Controls 27-10-23 ....Aileron Control System - Fuselage 27-10-40 ....Aileron Control System - Inner Wing 27-10-46 ....Aileron Control System - Outer Wing LH...
Page 19 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 53-80-03 ....Compartment Door 53-80-03 ....Battery Box 53-80-03 ....NEW Battery Box 56 ......Windows 56-00-13 ....Windows - Canopy 57 ......Wings 57-00-40 ....Wing Locking Device 57-20-46 ....Winglet LH 57-20-47 ....Winglet RH 57-20-48 ....Wing Extension LH 57-20-49 ....Wing Extension RH 57-70-40 ....Wing folding System...
Page 20 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 21: Life Limit Components
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 INTRODUCTION 00-00-00 GENERAL 00-00-00 ATA 100 NUMBERING SYSTEM 00-00-00 EXPLANATION OF USED IPC SYMBOLS 00-00-00 ORDERING 00-00-00 EFFECTIVITY 00-00-00 REVISIONS 00-00-00 ABBREVATIONS 00-00-00 LIFE LIMIT COMPONENTS ATA 00-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: --...
Page 22 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 23 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 GENERAL The Illustrated Parts Catalog (IPC) provided for Type STEMME S12 is made to identify life-limited parts of the S10-variant S12. Illustrations only show and specify parts which are subject to life limitations. The assemblies shown may contain additional life-limited parts not displayed and/or parts which have to be taken into consideration for assembling/disassembling but which are not life-limited (e.g.
Page 24 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 Further differentiations are: Chapter / System Section / Subsystem Unit/ Position CENTER LEFT RIGHT CENTER LEFT CENTER RIGHT FRONT FUSELAGE LEFT OUTSIDE RIGHT OUTSIDE REAR FUSELAGE WING FUSELAGE FRONT WING FRONT FRONT REAR...
Page 25 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 EXPLANATION OF USED IPC SYMBOLS This symbol shows the line of sight. This symbol shows the position number. ORDERING The listed item numbers of the illustrations are enumerated in the column Fig. of the following parts lists.
Page 26 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 EFFECTIVITY This additional information limits the validity of pages if necessary, e. g.: EFFECTIVITY S/N 12 003 Displayed parts are valid for the variant S12 with serial number (S/N) 003. REVISIONS Illustrated Parts Catalog revisions will be published regularly. The IPC has been prepared in loose- leaf form fore ease in inserting revisions.
Page 27: Parking, Storage, Return To Service
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 PARKING, STORAGE, RETURN TO SERVICE 10-10-00 PARKING AND RIGGING 10-10-04 MOORING ADAPTOR ATA 10-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 28 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION GROUND-BASED EQUIPMENT ASSEMBLY-NO. 121939 10-10-00 PARKING AND RIGGING NOTICE Position 3 - not displayed. For more details please refer to the following pages. ATA 10-10-00 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: --...
Page 29 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION GROUND-BASED EQUIPMENT ASSEMBLY-NO. 121939 POS. PART-NO. NOMENCLATURE QTY. REMARKS 121920 TOW BAR 121940 TAIL DOLLY 121959 WEATHER COVER EFFECTIVITY ATA 10-10-00 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 30 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION GROUND-BASED EQUIPMENT - TOW BAR ASSEMBLY-NO. 121939 7, 9 13, 10 10, 5 ATA 10-10-00 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 31 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION GROUND-BASED EQUIPMENT - TOW BAR ASSEMBLY-NO. 121920 POS. PART-NO. NOMENCLATURE QTY. REMARKS 121929 LIFTING DEVICE 121921 PULL BAR MODIFIED 831348 BALL COUPLING 831322 WHEEL 121922 BUSHING FOR WHEEL 810146 WASHER - 10...
Page 32 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION GROUND-BASED EQUIPMENT - TAIL DOLLY ASSEMBLY-NO. 121940 1, 13, 14 2, 13, 14 ATA 10-10-00 EFFECTIVITY PAGE P.03 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 33 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION GROUND-BASED EQUIPMENT - TAIL DOLLY ASSEMBLY-NO. 121940 POS. PART-NO. NOMENCLATURE QTY. REMARKS 121941 UPPER SHELL TAIL DOLLY 121942 LOWER SHELL TAIL DOLLY 121904 BASE PLATE 121913 COUPLING PLATE 121916 121917 WHEEL MODIFIED...
Page 34 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION GROUND-BASED EQUIPMENT - WEATHER COVER ASSEMBLY-NO. 121959 ATA 10-10-00 EFFECTIVITY PAGE P.04 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 35 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION GROUND-BASED EQUIPMENT - WEATHER COVER ASSEMBLY-NO. 121959 POS. PART-NO. NOMENCLATURE QTY. REMARKS 121970 COVER TAIL BOOM 121971 COVER FUSELAGE 121972 COVER INNER WING 121973 COVER OUTER WING 121974 COVER HORIZONTAL TAIL 121975...
Page 36 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION MOORING ADAPTOR ASSEMBLY-NO. 810447 10-10-04 MOORING ADAPTOR NOTICE Corresponding hard point located at lower survace of inner wing NOTICE Please refer also to chapter 12-72-10 SPECIAL TOOLS. ATA 10-10-04 EFFECTIVITY PAGE P.01...
Page 37 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION MOORING ADAPTOR ASSEMBLY-NO. 810447 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to 810447 EYE BOLT 12-72-10 EFFECTIVITY ATA 10-10-04 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 38 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 39 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 PLACARDS AND MARKINGS 11-00-00 PLACARDS AND MARKINGS 11-20-00 DESIGN 11-30-00 PLACARDS S12 ENGLISH ATA 11-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 40: Placards And Markings
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS AND MARKINGS ASSEMBLY-NO. 11-00-00 PLACARDS AND MARKINGS NOTICE For further information about the S12 PLACARDS AND MARKINGS please refer to the S12 Aircraft Maintenance Manual (AMM) and also the S12 Aircraft Flight Manual (AFM) and its Supplements (AFMS).
Page 41 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS AND MARKINGS ASSEMBLY-NO. POS. PART-NO. NOMENCLATURE QTY. REMARKS EFFECTIVITY ATA 11-00-00 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 42: Exterior Placards
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION DESIGN ASSEMBLY-NO. 121900 11-20-00 EXTERIOR PLACARDS D-KXXX Example for Germany Example for Germany NOTICE Position 7,8 - Not displayed. ATA 11-20-00 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 43 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION DESIGN ASSEMBLY-NO. 121900 POS. PART-NO. NOMENCLATURE QTY. REMARKS 121130 CALL SIGN - TAIL 121130 CALL SIGN - UNDER THE LEFT WING 121130 FLAG 121145 STEMME LOGO 121146 PRODUCT - S12 121147 PRODUCT - S12 SW...
Page 44: Interior Placards
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS S12 ENGLISH ASSEMBLY-NO. 121995 11-30-00 INTERIOR PLACARDS ATA 11-30-00 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 45 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS S12 ENGLISH ASSEMBLY-NO. 121995 POS. PART-NO. NOMENCLATURE QTY. REMARKS 121995 PLACARDS S12 ENGLISH EFFECTIVITY ATA 11-30-00 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 46 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS S12 ENGLISH ASSEMBLY-NO. 121995 FAA-Version EASA-Version ATA 11-30-00 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 47 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS S12 ENGLISH ASSEMBLY-NO. 121995 POS. PART-NO. NOMENCLATURE QTY. REMARKS 121995 PLACARDS S12 ENGLISH EFFECTIVITY ATA 11-30-00 PAGE D.02 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 48 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS S12 ENGLISH ASSEMBLY-NO. 121995 ATA 11-30-00 EFFECTIVITY PAGE P.03 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 49 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS S12 ENGLISH ASSEMBLY-NO. 121995 POS. PART-NO. NOMENCLATURE QTY. REMARKS 121995 PLACARDS S12 ENGLISH EFFECTIVITY ATA 11-30-00 PAGE D.03 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 50 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS S12 ENGLISH ASSEMBLY-NO. 121995 ATA 11-30-00 EFFECTIVITY PAGE P.04 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 51 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PLACARDS S12 ENGLISH ASSEMBLY-NO. 121995 POS. PART-NO. NOMENCLATURE QTY. REMARKS 121995 PLACARDS S12 ENGLISH EFFECTIVITY ATA 11-30-00 PAGE D.04 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 52 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 53: Servicing
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 SERVICING 12-12-13 OIL SERVICING 12-17-00 BATTERY SERVICING 12-50-00 CONSUMPTION MATERIAL 12-60-00 MATERIAL BY METER 12-72-10 SPECIAL TOOLS DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 54: Oil Servicing
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION OIL SERVICING ASSEMBLY-NO. 12-12-13 OIL SERVICING ATA 12-12-13 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 55 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION OIL SERVICING ASSEMBLY-NO. POS. PART-NO. NOMENCLATURE QTY. REMARKS *as required HUB302 PROPELLER GEARBOX OIL Refer to ATA 71-84-13 *as required 830264 AEROSHELL SPORT PLU 4 max. 3.5 ltr EFFECTIVITY ATA 12-12-13 PAGE D.01...
Page 56: Battery Servicing
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION BATTERY SERVICING ASSEMBLY-NO. 12-17-00 BATTERY SERVICING ATA 12-17-00 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 57 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION BATTERY SERVICING ASSEMBLY-NO. POS. PART-NO. NOMENCLATURE QTY. REMARKS 831780 1 CHANNEL LIFEPO4-CHARGER (EUROPE) *as required 1 CHANNEL LIFEPO4-CHARGER 832390 *as required (USA/CANADA) 832146 4 CHANNEL LIFEPO4-CHARGER (EUROPE) *as required 4 CHANNEL LIFEPO4-CHARGER...
Page 58: Consumption Material
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION CONSUMPTION MATERIAL ASSEMBLY-NO. 12-50-00 CONSUMPTION MATERIAL NOTICE For further information about the Castrol® LMX Grease please refer to the manufacturer’s specification. https://msdspds.castrol.com ATA 12-50-00 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: --...
Page 59 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION CONSUMPTION MATERIAL ASSEMBLY-NO. POS. PART-NO. NOMENCLATURE QTY. REMARKS A319 FIRE BARRIER SILICONE SEALANT *as required *as required CASTROL® LMX GREASE HUB301 Refer to (PROPELLER GEARBOX) ATA 71-84-13 EFFECTIVITY ATA 12-50-00 PAGE D.01...
Page 60: Material By Meter
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PERFORMANCE KIT ASSEMBLY-NO. 121129 12-60-00 MATERIAL BY METER ATA 12-60-00 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 61 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PERFORMANCE KIT ASSEMBLY-NO. 121129 POS. PART-NO. NOMENCLATURE QTY. REMARKS A212 TESA® TAPE - WHITE 38mm A213 TESA® TAPE - WHITE 25mm 10D-15 3D TURBULATOR TAPE 10D-16 TESA® CLOTH TAPE - WHITE 38mm...
Page 62: Special Tools
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION TOOL KIT ASSEMBLY-NO. 10CW 12-72-10 SPECIAL TOOLS NOTICE Position 2-6, 8,9, 13 - Not displayed. ATA 12-72-10 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 63 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION TOOL KIT ASSEMBLY-NO. 10CW POS. PART-NO. NOMENCLATURE QTY. REMARKS 10C-35 INSTALLATION TOOL FOR ELEVATOR TOOL WING BOLT 10CF *not displayed INNER/OUTER WING 10C-30 TOOL BAG *not displayed 10C-33 SLOTTED SCREWDRIVER *not displayed 10C-39 TESAFLEX®...
Page 64 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 65: Air Conditioning
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 AIR CONDITIONING 21-00-14 VENTILATION COCKPIT 21-00-14 VENTILATION CANOPY DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 66 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION VENTILATION COCKPIT ASSEMBLY-NO. 125877 21-00-14 VENTILATION COCKPIT ATA 21-00-14 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 67 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION VENTILATION COCKPIT ASSEMBLY-NO. 125877 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10CL-IF NOZZLE D985-04 HEXAGON NUT - M4 D7985-04018 PAN HEAD SCREW - M4x18 D125-04 WASHER - 4,3 EFFECTIVITY ATA 21-00-14 PAGE D.01 DOCUMENT NUMBER:...
Page 68 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION VENTILATION CANOPY ASSEMBLY-NO. 125878 21-00-14 VENTILATION CANOPY ATA 21-00-14 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 69 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION VENTILATION CANOPY ASSEMBLY-NO. 125878 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10CL-H10 AIR TUBE 10CL-HV FLAP 10CL-H01 KNURLED KNOB 10CL-H02 PUSH ROD EXTENSION 10CL-H03 GUIDANCE BOLT 10CL-H04 PUSH ROD 10CL-H05 CLEVIS 10CL-H06 COLLAR D551-04006...
Page 70 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 71: Electrical Power
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 ELECTRICAL POWER 24-00-10 ELECTRICAL POWER SYSTEM - FORWARD FUSELAGE 24-00-20 ELECTRICAL POWER SYSTEM – CENTER FUSELAGE 24-00-30 ELECTRICAL POWER SYSTEM - TAIL BOOM 24-32-25 BATTERY / CHARGER SYSTEM - BACKWARD FUSELAGE 24-40-25 INSTALLATION EXTERNAL POWER RECEPTACLE...
Page 72 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRIC FORWARD FUSELAGE ASSEMBLY-NO. 124200 24-00-10 ELECTRICAL POWER SYSTEM - FORWARD FUSELAGE NOTICE Position 1 - Is an Individual Instrument List. Please order the Part -No. 124 and add your S/N. For example:...
Page 73 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRIC FORWARD FUSELAGE ASSEMBLY-NO. 124200 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to 124000 INDIVIDUAL INSTRUMENTATION NOTICE 10FO-W AIRBRAKES OPEN SENSOR 124230 PLAINFLAP SENSOR ASSEMBLY 10ES-50 PUSH-BUTTON 10ES-52 PUSH-BUTTON 831796 SPEAKER 10M.120 RIVET NUT - M5...
Page 74 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRICAL POWER SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 124600 24-00-20 ELECTRICAL POWER SYSTEM - CENTER FUSELAGE NOTICE Position 2, 11...17, 44, 45, 46 - Not displayed. For detailed information please refer to the following pages.
Page 75 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRICAL POWER SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 124600 POS. PART-NO. NOMENCLATURE QTY. REMARKS 124627 ELECTRIC DISTRIBUTOR 124670 MAIN WIRE BUNDLE S12 not displayed 124630 TCU BOX 124614 SWITCHING BOX 7 x 7,5A...
Page 76 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRICAL POWER SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 124600 NOTICE Position 2, 11...17, 44, 45, 46 - Not displayed. For detailed information please refer the pages before. ATA 24-00-20 EFFECTIVITY PAGE P.02 S/N 12-031 - S/N 12-999...
Page 77 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRICAL POWER SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 124600 POS. PART-NO. NOMENCLATURE QTY. REMARKS INSTALLATION EXERNAL POWER 124646 RECEPTACLE 831723 MIDIVAL FUSE HOLDER 831727 MIDIVAL FUSE 50 A 832456 SOLAR CHARGER CONTROLLER 124661...
Page 78 ELECTRICAL POWER SYSTEM - TAIL BOOM NOTICE The Main BATTERY SB12V19E-EC (STEMME p/n: 831489) is not available anymore! Please refer to the STEMME SERVICE BULLETIN P062-980028 Please refer also the following pages for the NEW BATTERY (STEMME p/n: 832828). ATA 24-00-30 EFFECTIVITY PAGE P.01...
Page 79 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION MAIN BATTERY SB12V19E-EC ASSEMBLY-NO. 831489 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to 831489 MAIN BATTERY SB12V19E-EC ATA 53-80-03 EFFECTIVITY ATA 24-00-30 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 80 DESCRIPTION MAIN BATTERY SB12V20P-FC ASSEMBLY-NO. 832828 NOTICE Please refer to the STEMME SERVICE BULLETIN P062-980028 For further details about the BATTERY BOX (STEMME p/n: 125999) please refer to chapter 53-80-03. ATA 24-00-30 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: --...
Page 81 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION MAIN BATTERY SB12V20P-FC ASSEMBLY-NO. 832828 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to 832828 MAIN BATTERY SB12V20P-FC ATA 53-80-03 EFFECTIVITY ATA 24-00-30 PAGE D.02 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 82 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION CHARGE PLUGS - SECOND MAIN SYSTEM BATTERY ASSEMBLY-NO. 124637 24-32-25 BATTERY/CHARGER SYSTEM - BACKWARD FUSELAGE NOTICE Position 12, 14-16 - Not displayed. Connect the main battery charge plug always in forward position! For further information about the SECOND MAIN SYSTEM BATTERY please refer to the S12 Aircraft Maintenance Manual Supplement S08 (Stemme p/n: 912818).
Page 83 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION CHARGE PLUGS - SECOND MAIN SYSTEM BATTERY ASSEMBLY-NO. 124637 POS. PART-NO. NOMENCLATURE QTY. REMARKS 124638 BASEPLATE 832028 SAE CONNECTOR PANEL MOUNT E250 CIRCUIT BREAKER 10M-160 PIPE CLAMP - 20/15 10M-161 PIPE CLAMP - 25/15...
Page 84: External Power System - Backward Fuselage
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION EXTERNAL POWER RECEPTACLE ASSEMBLY-NO. 124646 24-40-25 EXTERNAL POWER SYSTEM - BACKWARD FUSELAGE NOTICE Position 1, 2, 3 - Not displayed. ATA 24-40-25 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 85 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION EXTERNAL POWER RECEPTACLE ASSEMBLY-NO. 124646 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10EM-S02 EXTERNAL POWER RECEPTACLE CABLE EXTERNAL SUPPLY PLUG 124607 not displayed RELAY 124605 CABLE EXTERNAL SUPPLY PLUG not displayed PLUS CABLE EXTERNAL SUPPLY PLUG...
Page 86: Dc Power/Distribution System - Middel Fuselage
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRIC DISTRIBUTOR ASSEMBLY-NO. 124601 24-60-23 DC POWER/DISTRIBUTION SYSTEM - MIDDEL FUSELAGE 10, 14 10, 14 10, 14 10,14 23, 14 23, 14 10, 12 23, 14 23, 14 10, 12 19, 16...
Page 87 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRIC DISTRIBUTOR ASSEMBLY-NO. 124601 POS. PART-NO. NOMENCLATURE QTY. REMARKS 124602 BASEPLATE 124610 DISTRIBUTOR BOX - MAIN 124614 7 CHANNEL MOSFET BOX 124620 DISTRIBUTOR BOX - ENGINE D6912-06020 CYLINDER BOLT - M6x20 D985-06...
Page 88 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRIC DISTRIBUTOR ASSEMBLY-NO. 124601 10, 14 10, 14 10, 14 10,14 23, 14 23, 14 10, 12 23, 14 23, 14 10, 12 19, 16 19, 16 17, 16 10, 14 10, 12...
Page 89 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ELECTRIC DISTRIBUTOR ASSEMBLY-NO. 124601 POS. PART-NO. NOMENCLATURE QTY. REMARKS D963-05035 COUNTERSUNK BOLT - M5x35 10M-160 PIPE CLAMP - 20/15 10M-163 PIPE CLAMP - 40/20 10M-161 PIPE CLAMP - 25/15 D6912-05020 CYLINDER BOLT - M5x20...
Page 90: Solar System - Middle Fuselage
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION SOLAR SYSTEM ENGINE COWLING ASSEMBLY-NO. 124648 24-70-23 SOLAR SYSTEM - MIDDLE FUSELAGE NOTICE Position 1 bonded on outer surface, Position 2 bonded on inner surface, Position 3 - Not displayed. ATA 24-70-23 EFFECTIVITY PAGE P.01...
Page 91 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION SOLAR SYSTEM ENGINE COWLING ASSEMBLY-NO. 124648 POS. PART-NO. NOMENCLATURE QTY. REMARKS 11ED-03 SOLAR MODUL 250112 ELECTRICAL BOARD SOLAR SYSTEM ADHESIVE TAPE 4104-08-66-25 A213 8.5m not displayed (WHITE, 25MM) EFFECTIVITY ATA 24-70-23 PAGE D.01...
Page 92 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 93: Equipment / Furnishings
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 EQUIPMENT / FURNISHINGS 25-00-10 CABIN EQUIPMENT 25-20-15 PASSENGER COMPARTMENT EQUIPMENT 25-62-23 INSTALLATION ELT ANTENNA ENGINE COWLING 25-71-34 BATTERY BOX STRUCTURE ATA 25-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 94 Position 3 - Not displayed. For detailed information please refer to the following pages. Position 4, 5, 6, 7, 8, 9 ,10 - Not displayed. Position 9 - INERTIAL REEL (STEMME p/n: 121134) is optionally available. ATA 25-00-10 EFFECTIVITY PAGE P.01...
Page 95 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION COCKPIT EQUIPMENT ASSEMBLY-NO. 121100 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10C-08 SHOULDER BELT 10C-09 LAP BELT 121142 INTERIOR *not displayed 121109 AIRCRAFT LOGBOOK *not displayed AIRCRAFT FLIGHT MANUAL 912810 Powered Sailplane *not displayed...
Page 96 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INTERIOR ASSEMBLY-NO. 121142 ATA 25-00-10 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 97 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INTERIOR ASSEMBLY-NO. 121142 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10C-01 SEAT CUSHION RIGHT 121135 SEAT CUSHION LEFT 121137 BACK CUSHION 10C-16 NECK CUSHION 10C-17 CONTROL STICK COVER 121138 SIDE POCKET RIGHT 10CT-LKG SIDE POCKET LEFT...
Page 98 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SEATS ASSEMBLY-NO. 122000 ATA 25-00-10 EFFECTIVITY PAGE P.03 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 99 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SEATS ASSEMBLY-NO. 122000 POS. PART-NO. NOMENCLATURE QTY. REMARKS Please refer 122015 SEATREST RIGHT, ASSEMBLY ATA 25-20-15 Please refer 122014 SEATREST LEFT, ASSEMBLY ATA 25-20-15 EFFECTIVITY ATA 25-00-10 PAGE D.03 DOCUMENT NUMBER: REVISION: --...
Page 100: Seatrest - Assembly
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SEATREST LEFT, ASSEMBLY ASSEMBLY-NO. 122014 25-20-15 SEATREST - ASSEMBLY ATA 25-20-15 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 101 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SEATREST LEFT, ASSEMBLY ASSEMBLY-NO. 122014 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10CE-SV16 NOTCH 833010 FIXED CYLINDER HANDLE - M6 10M-243 TENSION SPRING 15x1,2x65 D1474-04020-N GROOVED PIN - 4x20 EFFECTIVITY ATA 25-20-15 PAGE D.01...
Page 102 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SEATREST RIGHT, ASSEMBLY ASSEMBLY-NO. 122015 ATA 25-20-15 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 103 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SEATREST RIGHT, ASSEMBLY ASSEMBLY-NO. 122015 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10CE-SV16 NOTCH 833010 FIXED CYLINDER HANDLE - M6 10M-243 TENSION SPRING 15x1,2x65 D1474-04020-N GROOVED PIN - 4x20 EFFECTIVITY ATA 25-20-15 PAGE D.02...
Page 104: Emergency Locator Beacon - Middle Fuselage
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION ELT ANTENNA ENGINE COWLING ASSEMBLY-NO. 124647 25-62-23 EMERGENCY LOCATOR BEACON - MIDDLE FUSELAGE NOTICE Position 3 - Not displayed. ATA 25-62-23 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 105 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION ELT ANTENNA ENGINE COWLING ASSEMBLY-NO. 124647 POS. PART-NO. NOMENCLATURE QTY. REMARKS IE-C011 ELT ANTENNA 406 MHZ IC-B017M A214 ALUMINIUM TAPE 1.5m *not displayed EFFECTIVITY ATA 25-62-23 PAGE D.01 DOCUMENT NUMBER: REVISION: --...
Page 106: Battery Box Structure
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SECOND MAIN SYSTEM BATTERY, ASSEMBLY ASSEMBLY-NO. 369010 25-71-34 BATTERY BOX STRUCTURE View of the electrical components without battery cover. 3, 4 NOTICE Check length of CAMLOC STUD before ordering. ATA 25-71-34 EFFECTIVITY AIRCRAFT EQUIPPED WITH SECOND MAIN SYSTEM BATTERY PAGE P.01...
Page 107 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SECOND MAIN SYSTEM BATTERY, ASSEMBLY ASSEMBLY-NO. 369010 POS. PART-NO. NOMENCLATURE QTY. REMARKS 369011 COVER BATTERY CASE Refer to the 341472 CAMLOC - STUD NOTICE 10M-141 CAMLOC - GUIDE RING 10M-142 CAMLOC - CIRCLIP...
Page 108 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 109: Flight Controls
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 FLIGHT CONTROLS 27-10-23 AILERON CONTROL SYSTEM - FUSELAGE 27-10-40 AILERON CONTROL SYSTEM - INNER WING 27-10-46 AILERON CONTROL SYSTEM - OUTER WING LH 27-10-47 AILERON CONTROL SYSTEM - OUTER WING RH 27-51-13 INSTALLATION FLAP SENSOR...
Page 110 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL FUSELAGE ASSEMBLY-NO. 129550 27-10-23 AILERON CONTROL SYSTEM - FUSELAGE 33, 38 29, 32 16, 26, 32 31, 12,7, 34 31, 12, 7, 34 ATA 27-10-23 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER:...
Page 111 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL FUSELAGE ASSEMBLY-NO. 129550 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10M-038 BEARING BUSHING 10M-039 RING 10M-051 BEARING 10M-085 BLIND RIVET 10M-233 CLEVIS BOLT 10M-241 COVER DISK 10M-270 COVER DISK 10M-272 LOCK PLATE...
Page 112 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL FUSELAGE ASSEMBLY-NO. 129550 31, 12 NOTICE Position 24 - Not displayed The AUTOPILOT is optionally available. ATA 27-10-23 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 113 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL FUSELAGE ASSEMBLY-NO. 129550 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10SQ-RMC CONNECTING ROD MIXER 10SQ-RMF BELL CRANL RH 10SQ-RMG BELL CRANK LH 10SQ-RMW MIXER TORSION LINK Optional 129700 AUTOPILOT *not displayed 129713...
Page 114 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL FUSELAGE ASSEMBLY-NO. 129550 26, 29, 32 NOTICE Position 39 - Not displayed ATA 27-10-23 EFFECTIVITY PAGE P.03 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 115 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL FUSELAGE ASSEMBLY-NO. 129550 POS. PART-NO. NOMENCLATURE QTY. REMARKS L9037-06070 LN BOLT - M8x70 L9037-08075 LN BOLT - M8x75 AUTOPILOT LATERAL CONTROL 129720 *not displayed GARMIN GSA 28 10M-2745 CLEVIS BOLT...
Page 116 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL INNER WING ASSEMBLY-NO. 129800 27-10-40 AILERON CONTROL SYSTEM - INNER WING ATA 27-10-40 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 117 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL INNER WING ASSEMBLY-NO. 129800 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10M-098 BALL JOINT FOR L’HOTELLIER 054002 JOINT HEAD COMPLETE - M8 D439-08 HEXAGON NUT - M8 D440-06 WASHER M622 LOCK WASHER - NL8sp...
Page 118 27-10-46 AILERON CONTROL SYSTEM - OUTER WING LH NOTICE The complete part list of the AILERON CONTROL OUTER WING LH (STEMME p/n: 129900) is not displayed. Mirrord - Please refer to the AILERON CONTROL OUTER WING RH (STEMME p/n: 129950) chapter 27-10-47.
Page 119 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL OUTER WING LH ASSEMBLY-NO. 129900 POS. PART-NO. NOMENCLATURE QTY. REMARKS 129957 AILERON CONTROL ROD *not displayed 10SQ-TAG BEARING SUPPORT *not displayed 129959 AILERON CONTROL ROD *not displayed 10SQ-TAS AILERON CONTROL ROD...
Page 120 AILERON CONTROL OUTER WING LH ASSEMBLY-NO. 129900 NOTICE The complete part list of the AILERON CONTROL OUTER WING LH (STEMME p/n: 129900) is not displayed. Mirrord - Please refer to the AILERON CONTROL OUTER WING RH (STEMME p/n: 129950) chapter 27-10-47.
Page 121 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL OUTER WING LH ASSEMBLY-NO. 129900 POS. PART-NO. NOMENCLATURE QTY. REMARKS D985-06 HEXAGON NUT - M6 *not displayed L9037-06028 LN BOLT - M6X28 *not displayed D440-06 WASHER *not displayed EFFECTIVITY ATA 27-10-46 PAGE D.02...
Page 122 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL OUTER WING RH ASSEMBLY-NO. 129950 27-10-47 AILERON CONTROL SYSTEM - OUTER WING RH ATA 27-10-47 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 123 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL OUTER WING RH ASSEMBLY-NO. 129950 POS. PART-NO. NOMENCLATURE QTY. REMARKS 129957 AILERON CONTROL ROD 10SQ-TAG BEARING SUPPORT 129959 AILERON CONTROL ROD 10SQ-TAS AILERON CONTROL ROD 129952 BELL CRANK - RH...
Page 124 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL OUTER WING RH ASSEMBLY-NO. 129950 ATA 27-10-47 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 125 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AILERON CONTROL OUTER WING RH ASSEMBLY-NO. 129950 POS. PART-NO. NOMENCLATURE QTY. REMARKS D985-06 HEXAGON NUT - M6 L9037-06028 LN BOLT - M6X28 D440-06 WASHER EFFECTIVITY ATA 27-10-47 PAGE D.02 DOCUMENT NUMBER: REVISION: --...
Page 126 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION FLAP SENSOR ASSEMBLY-NO. 124230 27-51-13 INSTALLATION FLAP SENSOR 2, 3, 4 ATA 27-51-13 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 127 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION FLAP SENSOR ASSEMBLY-NO. 124230 POS. PART-NO. NOMENCLATURE QTY. REMARKS IR-F044 FLAP SENSOR D7985-03010-N PAN HEAD SCREW - M3x10 D125-03 WASHER - 3,2 D985-03 HEXAGON NUT - M3 HZ-SDR003 WIRE *as required...
Page 128 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - FRONT FUSELAGE ASSEMBLY-NO. 10SB-RV 27-62-13 AIR BRAKES CONTROL SYSTEM - FRONT FUSELAGE ATA 27-62-13 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 129 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - FRONT FUSELAGE ASSEMBLY-NO. 10SB-RV POS. PART-NO. NOMENCLATURE QTY. REMARKS 10SB-RV01 BEARING SUPPORT D125-06 WASHER - 6,4 D985-06 HEXAGON NUT - M6 L9037-06022 LN BOLT - 6X22 10SB-RVW...
Page 130 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - FRONT FUSELAGE ASSEMBLY-NO. 10SB-RV 62, 67 62, 67 ATA 27-62-13 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 131 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - FRONT FUSELAGE ASSEMBLY-NO. 10SB-RV POS. PART-NO. NOMENCLATURE QTY. REMARKS 10SB-RV24 AIR BRAKE LEVER, LH L9037-06018 LN BOLT - M6x18 10SB-RVG HANDLE (BLUE) D6912-05035 CYLINDER SCREW - M5x35...
Page 132 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - FRONT FUSELAGE ASSEMBLY-NO. 10SB-RV C - C D - D 22, 2, 3 22, 2, 3 H - H J - J ATA 27-62-13 EFFECTIVITY PAGE P.03...
Page 133 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - FRONT FUSELAGE ASSEMBLY-NO. 10SB-RV POS. PART-NO. NOMENCLATURE QTY. REMARKS 10SB-RVA CONTROL ROD L9037-06028 LN BOLT - M6X28 10M-216 FELT RING - 21X8,5X2,5 10SB-RVS ROCKER 10M-033 HOLLOW AXLE...
Page 134 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - FRONT FUSELAGE ASSEMBLY-NO. 10SB-RV ATA 27-62-13 EFFECTIVITY PAGE P.04 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 135 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - FRONT FUSELAGE ASSEMBLY-NO. 10SB-RV POS. PART-NO. NOMENCLATURE QTY. REMARKS 10M-270 COVER PLATE 10M294 WASHER - 5,3X10X2,5 129029 FLAP SENSOR BRACKET L9037-05024 LN BOLT - M5X24 D1587-05-A2S COVER NUT...
Page 136: Air Brakes Control System - Center Fuselage
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 10SB-RM 27-62-23 AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE NOTICE For further details about the AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE please refer the following pages.
Page 137 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 10SB-RM POS. PART-NO. NOMENCLATURE QTY. REMARKS 10M-271 COVER PLATE 10M-272 LOCK PLATE 10M-290 EYE BOLT - M8 10M-294 WASHER - 5,3X10X2,5 10SB-RMA CONTROL ROD...
Page 138 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 10SB-RM A - A TOP VIEW CENTER FUSELAGE G - G D - D ATA 27-62-23 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: --...
Page 139 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 10SB-RM POS. PART-NO. NOMENCLATURE QTY. REMARKS D985-08 HEXAGON NUT - M8 L9037-05022 LN BOLT - M5X22 L9037-05024 LN BOLT - M5X24 L9037-05026 LN BOLT - M5X26...
Page 140 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 10SB-RM C - C E - E H - H F - F K - K J - J ATA 27-62-23 EFFECTIVITY PAGE P.03...
Page 141 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 10SB-RM POS. PART-NO. NOMENCLATURE QTY. REMARKS EFFECTIVITY ATA 27-62-23 PAGE D.03 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 142 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 10SB-RM ATA 27-62-23 EFFECTIVITY PAGE P.04 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 143 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - CENTER FUSELAGE ASSEMBLY-NO. 10SB-RM POS. PART-NO. NOMENCLATURE QTY. REMARKS EFFECTIVITY ATA 27-62-23 PAGE D.04 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 144 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - INNER WING ASSEMBLY-NO. 10SB-TI Bottom view inner wing A - A B - B 3, 5 ATA 27-62-40 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 145 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL SYSTEM - INNER WING ASSEMBLY-NO. 10SB-TI POS. PART-NO. NOMENCLATURE QTY. REMARKS 10SB-TIH AIR BRAKES CONTROL ROD 10M-294 WASHER - 5,3x10x2,5 D985-05 HEXAGIN NUT - 5 L9037-05022 LN BOLT - M5x22...
Page 146 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL ROD ASSEMBLY-NO. 10SB-TIH ATA 27-62-40 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 147 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES CONTROL ROD ASSEMBLY-NO. 10SB-TIH POS. PART-NO. NOMENCLATURE QTY. REMARKS 10SB-TIH01 ROD END PIECE 10SB-TIH02 10SB-TIH03 BEARING BUSHING M617 LOCK WASHER - NL8 D439-08 HEXAGON NUT - M8 10M-290 EYE BOLT - M8...
Page 148: Air Brakes Control System - Assembly
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES FINAL ASSEMBLY ASSEMBLY-NO. 12TI-D 27-62-40 AIR BRAKES CONTROL SYSTEM - ASSEMBLY A - A B - B C - C ATA 27-62-40 EFFECTIVITY PAGE P.03 REVISION: DOCUMENT NUMBER: DATE: --...
Page 149 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES FINAL ASSEMBLY ASSEMBLY-NO. 12TI-D POS. PART-NO. NOMENCLATURE QTY. REMARKS 12 TI-RDA AIR BRAKE COVER - RH 12TI-LDA AIR BRAKE COVER - LH D439-08 HEXAGON NUT - M8 12TI-RD10 SLEEVE 12TI-RD07...
Page 150 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES FINAL ASSEMBLY ASSEMBLY-NO. 12TI-D D - D 1, (2 LH) 12, (13 LH) 10, (11 LH) ATA 27-62-40 EFFECTIVITY PAGE P.04 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 151 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIR BRAKES FINAL ASSEMBLY ASSEMBLY-NO. 12TI-D POS. PART-NO. NOMENCLATURE QTY. REMARKS D9021-05 WASHER - 5,3x15x1,2 12TI-RD01 WASHER PVC 12TI-RD02 SPRING - 1,2x10x15 12TI-RD03 SPRING - 1,2x10x20 12TI-RD04 SPRING - 1,2x10x26 D125-06-M WASHER - 6,4...
Page 152 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 153: Fuel System
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 FUEL SYSTEM 28-00-20 FUEL SYSTEM - FUSELAGE 28-00-24 FUEL SYSTEM - PUMP SET FUSELAGE 28-00-40 FUEL SYSTEM - WINGS S12 28-20-41 FUEL DISTRIBUTION SYSTEM - PUMP SET RIGHT WING 28-20-42 FUEL DISTRIBUTION SYSTEM - PUMP SET LEFT WING ATA 28-TOC PAGE D.01...
Page 154 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 28-00-20 FUEL SYSTEM - FUSELAGE 10, 30, 48, 54 10, 30,48, 54 42, 45, 50, 85 31, 33, 51, 52, 81 26, 31, 34, 42, 46...
Page 155 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to 128201 PUMP SET FUSELAGE ATA 28-00-24 128202 RETURN LINE TO RESERVOIR 128203 RESERVOIR LINE TO PUMPS PUMP LINES TO...
Page 156 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 94, 95 89, 74 10, 30, 48, 54 32, 92, 93 94, 95 90, 74 47, 58, 66 63, 76 32, 36, 78 47, 80 58, 63 75...
Page 157 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 POS. PART-NO. NOMENCLATURE QTY. REMARKS 11AB-M07 ELBOW RETURN LINE FUEL DIFFERENTIAL PRESSURE 200174 SENSOR 11AM-WU03 HOSE NOZZLE L9424-0.8 LOCK WIRE - 0,8 1,5m To Pos.48 D985-05...
Page 158 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 10, 30, 48, 54 10, 30,48, 54 42, 45, 50, 85 31, 33, 51, 52, 81 26, 31, 34, 42, 46 47, 80 31, 33, 51, 55, 81...
Page 159 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 POS. PART-NO. NOMENCLATURE QTY. REMARKS D6912-05025 CYLINDER BOLT - M5x25 M541 PIPE CLAMP - 37/20 D7603-12016-CU SEALING RING - 12x16x1,5 To all fuel hoses HZ-KSL021 FIRE PROTECTION HOSE 5,0m in the engine bay.
Page 160 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 10, 30, 48, 54 10, 30,48, 54 42, 45, 50, 85 31, 33, 51, 52, 81 26, 31, 34, 42, 46 47, 80 31, 33, 51, 55, 81...
Page 161 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10AB-73 HOSE CONNECTOR E-18 GROUND CABLE 3,0m M475 BANJO BOLT - M10x1x30 831078 HOSE NIPPLE 831087 FUEL LEVEL FLOAT SWITCH M428...
Page 162 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 10, 30, 48, 54 10, 30,48, 54 42, 45, 50, 85 31, 33, 51, 52, 81 26, 31, 34, 42, 46 47, 80 31, 33, 51, 55, 81...
Page 163 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 128200 POS. PART-NO. NOMENCLATURE QTY. REMARKS M473 PIPE CLAMP M-429 BANJO BOLT - M12x1,5x28 D6912-05016 CYLINDER SCREW - M5x16 D980-04 HEXAGON NUT - M4 D933-04012 HEXAGON SCREW - M4x12...
Page 164 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 200326 10, 30, 100, 54 10, 30, 100, 54 42, 45, 50, 85 47, 80 31, 33, 51, 52, 81 31, 33, 51, 55, 81 31, 34, 42, 46...
Page 165 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 200326 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to 128201 PUMP SET FUSELAGE ATA 28-00-24 128202 RETURN LINE TO RESERVOIR 128203 RESERVOIR LINE TO PUMPS PUMP LINES TO...
Page 166 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 200326 94, 95 89, 74 10, 30, 100, 54 32, 93 94, 95 90, 74 63, 76 32, 36, 55, 78 47, 80 58, 63 75 14, 48, 54...
Page 167 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 200326 POS. PART-NO. NOMENCLATURE QTY. REMARKS FUEL DIFFERENTIAL PRESSURE 200174 SENSOR 11AM-WU03 HOSE NOZZLE 125188 FEEDER TANK VENT NOZZLE when Pos.48 or L9424-0.8 LOCK WIRE - 0,8 1,5m Pos.
Page 168 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 200326 10, 30, 100, 54 10, 30, 100, 54 42, 45, 50, 85 47, 80 31, 33, 51, 52, 81 31, 33, 51, 55, 81 31, 34, 42, 46...
Page 169 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 200326 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10M-165 PIPE CLAMP - 8/12 10M-120 PIPE CLAMP - 20/15 no spare part To all fuel hos- 10M-181 1-EAR CLAMP es in the engine compartment.
Page 170 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 200326 10, 30, 100, 54 10, 30, 100, 54 42, 45, 50, 85 47, 80 31, 33, 51, 52, 81 31, 33, 51, 55, 81 31, 34, 42, 46...
Page 171 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - FUSELAGE ASSEMBLY-NO. 200326 POS. PART-NO. NOMENCLATURE QTY. REMARKS E-333 RING CABLE LUG - M6 128281 ENGINE FUEL SHUT-OFF VALVE D933-06025 HEXAGON SCREW - M6x25 M473 PIPE CLAMP D7643-8-3 BANJO BOLT - M12x1,5x24...
Page 172 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PUMP SET FUSELAGE ASSEMBLY-NO. 128201 28-00-24 FUEL SYSTEM - PUMP SET FUSELAGE 22,23 33, 35 NOTICE Position 12 - Not displayed. Position 14-19 - Not displayed. Position 20 - Not displayed. Connection of the pumps to the conductor.
Page 173 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PUMP SET FUSELAGE ASSEMBLY-NO. 128201 POS. PART-NO. NOMENCLATURE QTY. REMARKS 11AB-M02 ELECTRICAL FUEL PUMP 128228 FUEL DISTRIBUTOR - 8/12/M12 128229 FUEL DISTRIBUTOR - 8/8/M12 128236 FUEL HOSE Length 90mm 128237 FUEL HOSE...
Page 174 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PUMP SET FUSELAGE ASSEMBLY-NO. 128201 22,23 33, 35 NOTICE Position 20 - Not displayed. Connection of the pumps to the conductor. Position 28-31 - Not displayed. Position 37,38 - Not displayed. Position 45 - Not displayed. Swathe round Pos. 4-11...
Page 175 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PUMP SET FUSELAGE ASSEMBLY-NO. 128201 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10M-181 1-EAR CLAMP - 14,5 *not displayed M618 1-EAR CLAMP - 19,5 E-330 RING CABLE LUG - M3 10AB-TR43 HOSE CLAMP - D8...
Page 176 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - WINGS ASSEMBLY-NO. 128400 28-00-40 FUEL SYSTEM - WINGS S12 NOTICE This view shows the bottom side of the wing. View “A” shows the PUMP SET LEFT WING (STEMME p/n: 128510).
Page 177 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - WINGS ASSEMBLY-NO. 128400 POS. PART-NO. NOMENCLATURE QTY. REMARKS 11AB-RD FUEL FILLER CAP 10AB-R09 VENTILATION PIPE 128457 FUEL LINE - STAINLESS STEEL 128458 FUEL LINE - STAINLESS STEEL SPRING MOUNTED IN VENTILATION...
Page 178 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - WINGS ASSEMBLY-NO. 128400 24, 33 NOTICE View “A” shows the PUMP SET LEFT WING (STEMME p/n: 128510). Please refer also to ATA 28-20-42. ATA 28-00-40 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER:...
Page 179 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION FUEL SYSTEM - WINGS ASSEMBLY-NO. 128400 POS. PART-NO. NOMENCLATURE QTY. REMARKS D6912-05010 CYLINDER SCREW - M5x10 D85-04030 FLAT HEAD SCREW - M4x30 D985-06 HEXAGON NUT - M6 D985-05 HEXAGON NUT - M5...
Page 180 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PUMP SET RIGHT WING ASSEMBLY-NO. 128509 28-20-41 FUEL DISTRIBUTION SYSTEM - PUMP SET RIGHT WING 6, 7 6, 7 6, 7 6, 7 6, 7 6, 7 ATA 28-20-41 EFFECTIVITY PAGE P.01...
Page 181 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PUMP SET RIGHT WING ASSEMBLY-NO. 128509 POS. PART-NO. NOMENCLATURE QTY. REMARKS 128503 BRACKET RH 128440 DRAINER RH 830521 FUEL PUMP 11AB.MP02 FUEL FILTER 11AB-M08 CHECK VALVE Length HZ-KSL008 FUEL HOSE 0,76m 2x330mm...
Page 182 FUEL DISTRIBUTION SYSTEM - PUMP SET LEFT WING NOTICE The complete part list of the PUMP SET LEFT WING (STEMME p/n: 128510) is not displayed. Mirrord - Please refer to the PUMP SET RIGHT WING (STEMME p/n: 128509) chapter 28-20-41.
Page 183 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PUMP SET LEFT WING ASSEMBLY-NO. 128510 POS. PART-NO. NOMENCLATURE QTY. REMARKS 128504 BRACKET LH 128453 DRAINER LH 830521 FUEL PUMP 11AB.MP02 FUEL FILTER 11AB-M08 CHECK VALVE Length HZ-KSL008 FUEL HOSE 0,76m 2x330mm...
Page 184 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 185: Landing Gear
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 LANDING GEAR 32-13-20 MAIN LANDING GEAR 32-20-35 TAIL LANDING GEAR 32-40-10 LANDING GEAR BRAKE SYSTEM 32-44-35 TAIL WHEEL WITH TIRE ATA 32-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 186 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION MAIN LANDING GEAR SUSPENSION ASSEMBLY-NO. 123330 32-13-20 MAIN LANDING GEAR ATA 32-13-20 EFFECTIVITY PAGE P.01 REVISION: 03 DOCUMENT NUMBER: DATE: APR 14, 2021 L530-912830 ISSUE JANUARY 31, 2020...
Page 187 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION MAIN LANDING GEAR SUSPENSION ASSEMBLY-NO. 123330 POS. PART-NO. NOMENCLATURE QTY. REMARKS 831410 ELASTOMER DAMPER (831437)* BELLOWS In every quanti- ty the necessary 832520 BELLOWS amount of parts for the left and 831411...
Page 188 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION TAIL LANDING GEAR ASSEMBLY-NO. A20-10FS-E 32-20-35 TAIL LANDING GEAR 8, 5 8, 5 8, 5 8, 5 ATA 32-20-35 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 189 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION TAIL LANDING GEAR ASSEMBLY-NO. A20-10FS-E POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to 10FS-08-K TAIL WHEEL WITH TIRE ATA 32-44-35 10FS-A-K MOUNT 10FS-N-K TAIL WHEEL FORK D6912-08120 CYLINDER SCREW M8x120 D985-08 HEXAGON NUT - M8...
Page 190 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION LANDING GEAR BRAKE ASSEMBLY-NO. 10FO-B LH SHOWN. RH SIMILAR 32-40-10 LANDING GEAR BRAKE SYSTEM LH SHOWN. RH SIMILAR ATA 32-40-10 EFFECTIVITY PAGE P.01 S/N 12-002 - 12-018, 12-032 REVISION: 01 DOCUMENT NUMBER:...
Page 191 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION LANDING GEAR BRAKE ASSEMBLY-NO. 10FO-B POS. PART-NO. NOMENCLATURE QTY. REMARKS Flight Control 831730 HYDRAULIC BRAKE HANDLE Stick dia. 20mm Flight Control 10FO-B16 HYDRAULIC BRAKE HANDLE Stick dia. 18mm 10FO-B17 RESERVOIR 10FO-B20 HYDRAULIC LINE...
Page 192 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION LANDING GEAR BRAKE ASSEMBLY-NO. 10FO-B LH SHOWN. RH SIMILAR 32-40-10 LANDING GEAR BRAKE SYSTEM LH SHOWN. RH SIMILAR ATA 32-40-10 EFFECTIVITY PAGE P.01 S/N 12-019 - 12-031, 12-033 - 12-999 OR SB 980051...
Page 193 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION LANDING GEAR BRAKE ASSEMBLY-NO. 10FO-B POS. PART-NO. NOMENCLATURE QTY. REMARKS Flight Control 831730 HYDRAULIC BRAKE HANDLE Stick dia. 20mm Flight Control 10FO-B16 HYDRAULIC BRAKE HANDLE Stick dia. 18mm 10FO-B17 RESERVOIR 10FO-B20 HYDRAULIC LINE...
Page 194 TAIL WHEEL WITH TIRE ASSEMBLY-NO. 10FS-08-K 32-44-35 TAIL WHEEL WITH TIRE NOTICE Position 2 - BUSHING (STEMME p/n: 10FS-04-K) is included in Position 1 - TAIL WHEEL WITH TIRE (STEMME p/n: 10FS-08-K) ATA 32-44-35 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER:...
Page 195 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION TAIL WHEEL WITH TIRE ASSEMBLY-NO. 10FS-08-K POS. PART-NO. NOMENCLATURE QTY. REMARKS 10FS-08 TAIL WHEEL COMPLETE- 210x65 10FS-04 SPACER Included in Pos.1 10FS-20 TYRE 210 X65 Spare Part 10FS-21 TUBE 210X65 Spare Part...
Page 196 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 197: Lights
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 LIGHTS 33-40-46 EXTERIOR LIGHTING - WINGLET LH 33-40-47 EXTERIOR LIGHTING - WINGLET RH ATA 33-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 198 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION EXTERIOR LIGHTING - WINGLET LH ASSEMBLY-NO. 126812 LH 33-40-46 EXTERIOR LIGHTING - WINGLET LH NOTICE Position 2 - Not displayed. ATA 33-40-46 EFFECTIVITY AIRCRAFT EQUIPPED WITH WEHLEN LIGHT SYSTEM PAGE P.01 REVISION:...
Page 199 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION EXTERIOR LIGHTING - WINGLET LH ASSEMBLY-NO. 126812 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer 126811 WINGLET LIGHT SHELL LH ATA 57-20-46 10EA-L03 POSITION LIGHT RED *not displayed EFFECTIVITY ATA 33-40-46 AIRCRAFT EQUIPPED WITH WEHLEN LIGHT SYSTEM PAGE D.01...
Page 200 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION EXTERIOR LIGHTING - WINGLET RH ASSEMBLY-NO. 126882 33-40-47 EXTERIOR LIGHTING - WINGLET RH NOTICE Position 2 - Not displayed. ATA 33-40-47 EFFECTIVITY AIRCRAFT EQUIPPED WITH WEHLEN LIGHT SYSTEM PAGE P.01 REVISION: DOCUMENT NUMBER:...
Page 201 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION EXTERIOR LIGHTING - WINGLET RH ASSEMBLY-NO. 126882 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer 126876 WINGLET LIGHT SHELL RH ATA 57-20-47 10EA-R13 POSITION LIGHT GREEN *not displayed EFFECTIVITY ATA 33-40-47 AIRCRAFT EQUIPPED WITH WEHLEN LIGHT SYSTEM PAGE D.01...
Page 202 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 203: Navigation
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 NAVIGATION 34-14-00 AIRSPEED INDICATOR - (kph) 34-14-00 AIRSPEED INDICATOR - (kt) ATA 34-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 204: Airspeed / Mach Indicator - (Kph)
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIRSPEED INDICATOR STEMME S12 (0-300kph, 57mm) ASSEMBLY-NO. 832302 34-14-00 AIRSPEED / MACH INDICATOR - (kph) ATA 34-14-00 EFFECTIVITY PAGE P.01 AIRCRAFT EQUIPPED WITH AIRSPEED INDICATOR (0-300kph, 57mm) REVISION: DOCUMENT NUMBER: DATE: --...
Page 205 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIRSPEED INDICATOR STEMME S12 (0-300kph, 57mm) ASSEMBLY-NO. 832302 POS. PART-NO. NOMENCLATURE QTY. REMARKS AIRSPEED INDICATOR STEMME S12 832302 (0-300kph, 57mm) EFFECTIVITY ATA 34-14-00 AIRCRAFT EQUIPPED WITH PAGE D.01 AIRSPEED INDICATOR (0-300kph, 57mm)
Page 206: Airspeed / Mach Indicator - (Kt)
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIRSPEED INDICATOR STEMME S12 (0-160kt, 57mm) ASSEMBLY-NO. 832303 34-14-00 AIRSPEED / MACH INDICATOR - (kt) ATA 34-14-00 EFFECTIVITY PAGE P.02 AIRCRAFT EQUIPPED WITH AIRSPEED INDICATOR (0-160kt, 57mm) REVISION: DOCUMENT NUMBER: DATE: --...
Page 207 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION AIRSPEED INDICATOR STEMME S12 (0-160kt, 57mm) ASSEMBLY-NO. 832303 POS. PART-NO. NOMENCLATURE QTY. REMARKS AIRSPEED INDICATOR STEMME S12 832303 (0-160kt 57mm) EFFECTIVITY ATA 34-14-00 AIRCRAFT EQUIPPED WITH PAGE D.02 AIRSPEED INDICATOR (0-160kt, 57mm)
Page 208 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 209: Oxygen
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 OXYGEN 35-00-00 CYLINDER MOUNTING ATA 35-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 210 CYLINDER MOUNTING ASSEMBLY-NO. 10ZO-H 35-00-00 CYLINDER MOUNTING NOTICE Please refer to the AFM Supplement S04 - OXYGEN CYLINDER MOUNTING (Stemme p/n: 912814). NOTICE Manufacturer CYLINDER TYPE KF-022: Mountain High Equipment & Supply Company 516 12 Ave, Salt Lake City Utah. 84103-3209, USA...
Page 211 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION CYLINDER MOUNTING ASSEMBLY-NO. 10ZO-H POS. PART-NO. NOMENCLATURE QTY. REMARKS 10ZO-HF CYLINDER MOUNTING FOR KF-022 10ZO-H02 PLATE 10ZO-H01 CLAMPING D6912-06020 CYLINDER SCREW - M6x20 D985-06 HEXAGON NUT - M6 D125-06 WASHER - 6,4...
Page 212 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 213: Doors
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DOORS 52-10-10 PASSENGER/CREW DOORS ATA 52-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: 01 L530-912830 ISSUE JANUARY 31,2020 DATE: AUG 03, 2020...
Page 214 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION CANOPY ASSEMBLY-NO. 369101 52-10-10 PASSENGER/CREW DOORS NOTICE For further details about the CANOPY and its SLIDING WINDOWS please refer to chapter 56-00-13. ATA 52-10-10 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: --...
Page 215 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION CANOPY ASSEMBLY-NO. 369101 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to C003 CANOPY ACRYLIC GLASS GREEN ATA 56-00-13 369100 CANOPY FRAME 369062 CANOPY FRAME COVER RH 369063 CANOPY FRAME COVER LH EFFECTIVITY ATA 52-10-10 PAGE D.01...
Page 216 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 217: Fuselage
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 FUSELAGE 53-00-00 PROPULSION SYSTEM 53-80-00 BAGGAGE COMPARTMENT 53-80-03 COMPARTMENT DOOR 53-80-03 BATTERY BOX 53-80-03 NEW BATTERY BOX ATA 53-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 218 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPULSION SYSTEM ASSEMBLY-NO. 127200 53-00-00 PROPULSION SYSTEM NOTICE Position 5, 6 - Not diplayed. NOTICE For further details about the PROPELLER ASSEMBLY please refer to chapter 61-10-13. For further details about the PROPELLER BRAKE SYSTEM please refer to chapter 61-30-13.
Page 219 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPULSION SYSTEM ASSEMBLY-NO. 127200 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to 11AP-V PROPELLER ATA 61-10-13 Refer to 11AG PROPELLER GEARBOX ATA 71-84-13 Refer to 11AA PROPELLER GEARBOX MOUNTING ATA 71-84-13 Refer to...
Page 220 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION BAGGAGE COMPARTMENT ASSEMBLY-NO. 125590 53-80-00 BAGGAGE COMPARTMENT NOTICE For further details about the COVER BAGGAGE COMPARTMENT please refer to chapter 53-80-03 4, 5 ATA 53-80-00 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: --...
Page 221 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION BAGGAGE COMPARTMENT ASSEMBLY-NO. 125590 POS. PART-NO. NOMENCLATURE QTY. REMARKS 125587 OPENING CENTER PANEL * If Second Main 125798 OPENING CENTER PANEL System Battery is installed. 125588 OPENING REAR PANEL 10M-130 COUNTERSUNK WASHER...
Page 222 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION COVER BAGGAGE COMPARTMENT ASSEMBLY-NO. 125340 53-80-03 COMPARTMENT DOOR NOTICE Position 2 - Included in Pos 1 Position 4 and 5 - Included in Position 3 ATA 53-80-03 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER:...
Page 223 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION COVER BAGGAGE COMPARTMENT ASSEMBLY-NO. 125340 POS. PART-NO. NOMENCLATURE QTY. REMARKS 125342 COVER BAGGAGE COMPARTMENT 830916 LOCK FOR COVER Included in Pos.1 125343 AXIS 831065 DOUBLE LEG SPRING Included in Pos.3 810299 COTTER PIN Included in Pos.3...
Page 224 53-80-03 BATTERY BOX NOTICE The BATTERY (STEMME p/n: 831489) is not available anymore! For further details about the NEW BATTERY (STEMME p/n: 832828) please refer to chapter 24-00-00. Please also refer to the STEMME SERVICE BULLETIN P062-980028 ATA 53-80-03 EFFECTIVITY PAGE P.02...
Page 225 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION BATTERY BOX ASSEMBLY-NO. 125386 POS. PART-NO. NOMENCLATURE QTY. REMARKS 125388 BATTERY BOX UPPER PART 125387 BATTERY BOX LOWER PART Bonded with 125390 BULKHEAD FOR BATTERY BOX Pos.2 125389 GUIDE TUBE 823080 THREADED ROD - M6...
Page 226 NEW BATTERY BOX ASSEMBLY-NO. 125999 53-80-03 NEW BATTERY BOX NOTICE For further details about the BATTERY (STEMME p/n: 832828) please refer to chapter 24-00-00. Please also refer to the STEMME SERVICE BULLETIN P062-980028 ATA 53-80-03 EFFECTIVITY PAGE P.03 REVISION: DOCUMENT NUMBER:...
Page 227 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION BATTERY BOX ASSEMBLY-NO. 125999 POS. PART-NO. NOMENCLATURE QTY. REMARKS 126000 BATTERY BOX UPPER PART 125998 THREADED ROD - M6 D6334-06018 HEXAGON NUT - M6x3d D985-06 HEXAGON NUT - M6 D137-06_B SPRING WASHER - 6,4...
Page 228 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 229: Windows
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 WINDOWS 56-00-13 WINDOWS - CANOPY ATA 56-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 230 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION CANOPY ASSEMBLY-NO. 125800 56-00-13 WINDOWS - CANOPY 8, 6 NOTICE Pos. 3 - Not displayed. Pos. 7 - Not displayed. One LOCKSET FOR THE CANOPY includes 2 keys and 1 lock. ATA 56-00-13 EFFECTIVITY PAGE P.01...
Page 231 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION CANOPY ASSEMBLY-NO. 125800 POS. PART-NO. NOMENCLATURE QTY. REMARKS 369101 CANOPY Includes Pos. 9 125842 CANOPY HINGE 10VH-F RETAINING ROPE *not displayed 10VH-Y3 CANOPY EMERGENCY JETTISON 126077 GAS SPRING D963-03008-Pa COUNTERSUNK SCREW - M3x8...
Page 232 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 233: Wings
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 WINGS 57-00-40 WING LOCKING DEVICE 57-20-46 WINGLET LH 57-20-47 WINGLET RH 57-20-48 WING EXTENSION LH 57-20-49 WING EXTENSION RH 57-70-40 WING FOLDING SYSTEM ATA 57-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020...
Page 234 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WING LOCKING DEVICE ASSEMBLY-NO. 125599 57-00-40 WING LOCKING DEVICE 12, 13 9, 7, 6 11, 6 ATA 57-00-40 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 235 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WING LOCKING DEVICE ASSEMBLY-NO. 125599 POS. PART-NO. NOMENCLATURE QTY. REMARKS 12T-002 MAIN BOLT 12TI-RTA01 ANGLE BRACKET LH 12TI-RTA02 ANGLE BRACKET RH 12TI-RTA03 PIVOT PIN RETAINER 12TI-RTS SAFETY PIN MAIN BOLT *as required...
Page 236 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WINGLET LH ASSEMBLY-NO. 012406 57-20-46 WINGLET LH ATA 57-20-46 EFFECTIVITY PAGE P.01 AIRCRAFT EQUIPPED WITH 25 METER - WING REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 237 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WINGLET LH ASSEMBLY-NO. 012406 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer to 126812 WINGLET LIGHT ASSEMBLY - LH ATA 33-40-46 12TA-WG TAIL SKID D85-03006 FLAT HEAD SCREW - M3x6 D125-03-KST WASHER - 3,2...
Page 238 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WINGLET RH ASSEMBLY-NO. 012407 57-20-47 WINGLET RH ATA 57-20-47 EFFECTIVITY PAGE P.01 AIRCRAFT EQUIPPED WITH 25 METER WING REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 239 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WINGLET RH ASSEMBLY-NO. 012407 POS. PART-NO. NOMENCLATURE QTY. REMARKS Refer 126882 WINGLET LIGHT ASSEMBLY - RH ATA 33-40-47 12TA-WG TAIL SKID D85-03006 FLAT HEAD SCREW - M3x6 D125-03-KST WASHER - 3,2 *Order...
Page 240 012404 57-20-48 WING EXTENSION LH NOTICE The complete part list of the WING EXTENSION LH (Stemme p/n: 012404) is not displayed. Mirrored - Please refer to the WING EXTENSION RH (STEMME p/n: 012405) chapter 57-20-47. ATA 57-20-48 EFFECTIVITY PAGE P.01...
Page 241 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WING EXTENSION LH ASSEMBLY-NO. 012404 POS. PART-NO. NOMENCLATURE QTY. REMARKS 125900 STRUCTURE EXTENSION WING LH *not displayed 126900 AILERON EXTENSION WING LH *not displayed 125927 GUIDING MANDREL *not displayed D471-060,7 RETAINING RING *not displayed To Pos.
Page 242 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WING EXTENSION RH ASSEMBLY-NO. 012405 57-20-49 WING EXTENSION RH 3, 5 NOTICE Position 5 - Not displayed. 3, 5 ATA 57-20-49 EFFECTIVITY PAGE P.01 AIRCRAFT EQUIPPED WITH 25 METER WING REVISION: DOCUMENT NUMBER:...
Page 243 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WING EXTENSION RH ASSEMBLY-NO. 012405 POS. PART-NO. NOMENCLATURE QTY. REMARKS 125950 STRUCTURE EXTENSION WING RH 126950 AILERON EXTENSION WING RH 125927 GUIDING MANDREL D471-060,7 RETAINING RING To Pos. 3 A061 THREAD LOCKING...
Page 244 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WING FOLDING DEVICE ASSEMBLY-NO. 121500 57-70-40 WING FOLDING SYSTEM Flap and aileron - Not displayed Flight Direction Flight Direction View displayed without pivot tube 12, 13 NOTICE For further information about the WING FOLDING DEVICE please refer to the S12 Aircraft Maintenance Manual (AMM) and the S12 Aircraft Flight Manual (AFM) and its Supplement S05 - WING FOLDING DEVICE (AFMS).
Page 245 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WING FOLDING DEVICE ASSEMBLY-NO. 121500 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10ZK-T05 PIN TO JOINT 10ZK-T06 BUSHING TO CARDAN JOINT 10ZK-T07 CROSS FITTING CARDAN JOINT TO 10ZK-T08 OUTER WING - RIGHT CARDAN JOINT TO...
Page 246 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WING FOLDING DEVICE S12 ASSEMBLY-NO. 121500 10, 9(LH) 8, 7(LH) NOTICE 4, 5(LH) When wing is folded, lock guiding tube with locking bolt 10M-299 Refer to chapter 12-72-10 20, 21 19, 21...
Page 247 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION WING FOLDING DEVICE S12 ASSEMBLY-NO. 121500 POS. PART-NO. NOMENCLATURE QTY. REMARKS D923-06005 FLAT HEAD SCREW - M6x5 Pos. 21 is needed D427-08016 SET SCREW - M8x16 Pos. 21 is needed *as required...
Page 248 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 249: Propeller
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 PROPELLER 61-10-13 PROPELLER ASSEMBLY 61-20-13 PROPELLER CONTROL SYSTEM 61-30-13 PROPELLER BRAKE SYSTEM ATA 61-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 250 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER ASSEMBLY ASSEMBLY-NO. 11AP-V 61-10-13 PROPELLER ASSEMBLY ATA 61-10-13 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 251 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER ASSEMBLY ASSEMBLY-NO. 11AP-V POS. PART-NO. NOMENCLATURE QTY. REMARKS 11AP-V VARIABLE PITCH PROPELLER Assembly 10AP-V01 PROPELLER HUB 10AP-V88 PROPELLER FORK 10AP-V77 BOLT 10AP-V78 10AP-VU BASE 10AP-V76 SCREW-BASE EFFECTIVITY ATA 61-10-13 PAGE D.01...
Page 252 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER CONTROL SYSTEM ASSEMBLY-NO. 125880 61-20-13 PROPELLER CONTROL SYSTEM ATA 61-20-13 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 253 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER CONTROL SYSTEM ASSEMBLY-NO. 125880 POS. PART-NO. NOMENCLATURE QTY. REMARKS 10AP-BA PULL CABLE ASSEMBLY 10AP-B01 ANGLE BRACKET M669 CLEVIS 10FO-A03 EXTENSION SPRING EFFECTIVITY ATA 61-20-13 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020...
Page 254 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER BRAKE SYSTEM ASSEMBLY-NO. 11AP-S 61-30-13 PROPELLER BRAKE SYSTEM ATA 61-30-13 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 255 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER BRAKE SYSTEM ASSEMBLY-NO. 11AP-S POS. PART-NO. NOMENCLATURE QTY. REMARKS 10AP-S02 BUSHING 10AP-S04 CABLE CONNECTOR 10AP-S05 PLAIN BEARING BUSHING 11AP-SB BRAKE BAND 10AP-SS PULL CABLE ASSEMBLY EFFECTIVITY ATA 61-30-13 PAGE D.01 DOCUMENT NUMBER:...
Page 256 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 257: Powerplant
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 POWERPLANT 71-00-00 POWERPLANT 71-30-00 ENGINE FIRESEALS 71-81-13 DRIVETRAIN 71-84-13 PROPELLER GEARBOX MOUNTING ATA 71-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 258 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION POWERPLANT ASSEMBLY-NO. 11AM-M 71-00-00 POWERPLANT ATA 71-00-00 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 259 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION POWERPLANT ASSEMBLY-NO. 11AM-M POS. PART-NO. NOMENCLATURE QTY. REMARKS STEMME / ROTAX 11AM-M ROTAX 914 F2/S1 Engine *not displayed Various RUBBER PARTS OF THE ENGINE Refer to ROTAX MML-914. EFFECTIVITY ATA 71-00-00 PAGE D.01...
Page 260 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE FIRESEALS ASSEMBLY-NO. 71-30-00 ENGINE FIRESEALS ATA 71-30-00 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 261 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE FIRESEALS ASSEMBLY-NO. POS. PART-NO. NOMENCLATURE QTY. REMARKS HZ-KSL019 FUEL HOSE *as required EFFECTIVITY ATA 71-30-00 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 262: Drivetrain
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION DRIVETRAIN ASSEMBLY-NO. 11AS 71-81-13 DRIVETRAIN ATA 71-81-13 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 263 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION DRIVETRAIN ASSEMBLY-NO. 11AS POS. PART-NO. NOMENCLATURE QTY. REMARKS 10AS-F DRIVE SHAFT 11AS-09 FLEXIBLE DISK 11AG REDUCTION GEAR 12AK FLYWHEEL CLUTCH EFFECTIVITY ATA 71-81-13 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020...
Page 264: Propeller Gearbox
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER GEARBOX ASSEMBLY-NO. 11AG 71-84-13 PROPELLER GEARBOX ATA 71-84-13 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 265 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER GEARBOX ASSEMBLY-NO. 11AG POS. PART-NO. NOMENCLATURE QTY. REMARKS 11AG PROPELLER GEARBOX Refer to HUB302 GEARBOX OIL ATA 12-12-13 EFFECTIVITY ATA 71-84-13 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020...
Page 266: Propeller Gearbox Mounting
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER GEARBOX MOUNTING ASSEMBLY-NO. 11AA 71-84-13 PROPELLER GEARBOX MOUNTING 3, 4 ATA 71-84-13 EFFECTIVITY PAGE P.02 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 267 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION PROPELLER GEARBOX MOUNTING ASSEMBLY-NO. 11AA POS. PART-NO. NOMENCLATURE QTY. REMARKS 10AA-30 EXTENSION SPRING 10AA-19 10AA-21 BUSHING 10AA-22 BUSHING 10AA-36 RUBBER SLEEVE Refer to the 10AA-S SHOCK MOUNT ASSEMBLY following pages EFFECTIVITY ATA 71-84-13 PAGE D.02...
Page 268: Shock Mount Assembly
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SHOCK MOUNT ASSEMBLY ASSEMBLY-NO. 11AA-S 71-84-13 SHOCK MOUNT ASSEMBLY ATA 71-84-13 EFFECTIVITY PAGE P.03 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 269 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION SHOCK MOUNT ASSEMBLY ASSEMBLY-NO. 11AA-S POS. PART-NO. NOMENCLATURE QTY. REMARKS 11AA-S SHOCK MOUNT ASSEMBLY EFFECTIVITY ATA 71-84-13 PAGE D.03 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 270 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 271: Air
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 75-20-00 ENGINE COOLING 75-20-02 ENGINE COOLING 75-20-03 INTERCOOLER ATA 75-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 272 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE COOLING ASSEMBLY-NO. 127310 75-20-00 ENGINE COOLING Overflow Bottle Expansion Tank Engine Stemme Coolant Collector 4 (8x) ATA-CHAPTER 75-20-00 EFFECTIVITY PAGE P.01 Radiator 11AM-WKM REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 273 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE COOLING ASSEMBLY-NO. 127310 POS. PART-NO. NOMENCLATURE QTY. REMARKS HZ-KSL015 COOLANT HOSE HZ-KSL018 COOLANT HOSE HZ-KSL041 SILICONE HOSE HZ-KSL043 COOLANT HOSE HZ-KSL025 COOLANT HOSE 11AM-WKM COOLANT RADIATOR * as required EFFECTIVITY ATA-CHAPTER 75-20-00 Radiator 11AM-WKM PAGE D.01...
Page 274 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE COOLING ASSEMBLY-NO. 127310 ATA-CHAPTER 75-20-00 EFFECTIVITY PAGE P.02 S/N 12-002; 12-009 - 12-999 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 275 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE COOLING ASSEMBLY-NO. 127310 POS. PART-NO. NOMENCLATURE QTY. REMARKS 831717 COOLANT HOSE HZ-KSL043 COOLANT HOSE HZ-KSL025 COOLANT HOSE HZ-KSL015 COOLANT HOSE HZ-KSL041 SILICONE HOSE 831812 COOLANT RADIATOR * as required EFFECTIVITY ATA-CHAPTER 75-20-00 S/N 12-002;...
Page 276 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE COOLING ASSEMBLY-NO. 11AM-C 75-20-02 ENGINE COOLING ATA-CHAPTER 75-20-02 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 277 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE COOLING ASSEMBLY-NO. 11AM-C POS. PART-NO. NOMENCLATURE QTY. REMARKS HZ-KSL022 NEOPRENE HOSE * as required EFFECTIVITY ATA-CHAPTER 75-20-02 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 278 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INTERCOOLER ASSEMBLY-NO. 11AM-E 75-20-03 INTERCOOLER ATA-CHAPTER 75-20-03 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 279 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INTERCOOLER ASSEMBLY-NO. 11AM-E POS. PART-NO. NOMENCLATURE QTY. REMARKS HZ-KSL023 NEOPRENE HOSE * as required EFFECTIVITY ATA-CHAPTER 75-20-03 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 280 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 281: Engine Indicating System
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 ENGINE INDICATING SYSTEM 77-00-23 INSTALLATION ENGINE PROBES S12 ATA 77-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 282: Engine Indicating System - Middle Fuselage
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION ENGINE PROBES S12 ASSEMBLY-NO. 124645 77-00-23 ENGINE INDICATING SYSTEM - MIDDLE FUSELAGE NOTICE Position 6...15 - Not displayed. ATA-CHAPTER 77-00-23 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 283 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION INSTALLATION ENGINE PROBES S12 ASSEMBLY-NO. 124645 POS. PART-NO. NOMENCLATURE QTY. REMARKS 831116 PRESSURE PROBE Oil Pressure 831243 TEMPERATURE PROBE TYP RTD Oil Temperature Cylinder Head Temperature, only for aircraft 831243 TEMPERATURE PROBE TYP RTD...
Page 284 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 285: Engine Oil
ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 ENGINE OIL 79-20-02 ENGINE OIL DISTRIBUTION ATA 79-TOC PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020 DATE: --...
Page 286 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE OIL ASSEMBLY-NO. 11AM-O 79-20-02 ENGINE OIL DISTRIBUTION Engine Oil Tank Turbo Charger Air Vent Oil Cooler ATA-CHAPTER 79-20-02 EFFECTIVITY PAGE P.01 REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...
Page 287 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 DESCRIPTION ENGINE OIL ASSEMBLY-NO. 11AM-O POS. PART-NO. NOMENCLATURE QTY. REMARKS HZ-KSL015 LUBRICATION HOSE * as required HZ-KSL016 LUBRICATION HOSE * as required EFFECTIVITY ATA-CHAPTER 79-20-02 PAGE D.01 DOCUMENT NUMBER: REVISION: -- L530-912830 ISSUE JANUARY 31,2020...
Page 288 ILLUSTRATED PARTS CATALOG STEMME S10, VARIANT S12 THIS PAGE IS INTENTIONALLY LEFT BLANK REVISION: DOCUMENT NUMBER: DATE: -- L530-912830 ISSUE JANUARY 31, 2020...

This manual is also suitable for:

Variant s12

STEMME VARIANT S10 Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STEMME VARIANT S10

Summary of Contents for STEMME VARIANT S10

This manual is also suitable for:

Table of Contents
