Bradford White PDX-65S-65FB-3N Specification Sheet

Light Duty Commercial Power Direct Vent
Energy Saver Gas Water Heater
Photo is of
PDX-65S-65FB-3N
Bradford White received the highest numerical score among water heater/boiler manufacturers in the proprietary J.D. Power and Associates/ McGraw-Hill Construction 2006 HVAC and Water Heater/Boiler Subcontractor Satisfaction Study
Study based on 882 responses measuring 3 water heater/boiler manufacturers and measures opinions of subcontractors. Proprietary study results are based on experiences and perceptions of subcontractors surveyed in May through July 2006. Your
experiences may vary. Visit jdpower.com
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 7,063,133 B2; 5,954,492; 5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385; 5,574,822; 5,372,185;
5,485,879; 5,277,171; (B1)5,341,770; 5,660,165; 5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448; 4,829,983; 4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968;
4,672,919; Re. 34,534. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS: 1,272,914; 1,280,043; 1,289,832; 2,045,862; 2,112,515; 2,108,186; 2,107,012; 2,092,105.
Defender Safety System ® , Vitraglas ® and Hydrojet
"Highest in Subcontractor Satisfaction among Water Heater/Boiler Manufacturers"
The LD Power Direct Vent FVIR Defender Safety System
Closed Combustion Venting System—Power Direct Vent closed
I
combustion system utilizes external air for combustion and exhausts directly
to the outside through a separate two-pipe system. The air intake and exhaust
vent are 3" connections. The equivalent feet of intake venting cannot be
greater than the equivalent feet of exhaust venting.
Flammable Vapor Sensor—Electronic sensor prevents water heater
I
operation if flammable vapors are detected.
Factory Installed Hydrojet
I
sediment reducing device helps prevent sediment build up in tank. Increases
first hour delivery of hot water while minimizing temperature build up in tank.
Vitraglas ®
I
corrosive effects of hot water by an exclusive ceramic porcelain-like coating.
Electronic Gas Control—The integrated, immersion gas control offers more
I
precise temperature control for higher first hour delivery and also allows water
temperature adjustment without removing the cover. The control is equipped
with an LED display to aid in start-up and diagnostics.
More Precise Temperature Control—With an adjustable temperature up to
I
180ºF. (Not recommended for 180ºF sanitization.)
Spark to Pilot Ignition System—Eliminates the constant burning pilot used
I
on other water heaters.
Powerful Blower Motor—Our design has higher torque for greater resistance
I
to outside winds and the power to eliminate problems with difficult venting
situations. This significantly quieter motor runs cooler for a considerably
longer operational life.
Optional Concentric Vent Kit Termination—3" termination fitting provides
I
for only one exit opening through a wall or roof. (Subtract 10ft. for intake pipe
and 10ft. for exhaust pipe when calculating total vent length.)
Horizontal and Vertical Venting—With 3" or 4" PVC, ABS, or CPVC
I
(Maximum equivalent vent length for each pipe on reverse side).
Side Connections—3/4" NPT tappings allow easy connections for space
I
heating applications (Potable water only).
2" Non-CFC Foam Insulation—Surrounds the tank surface, saving energy
I
by retarding loss of heat (PDX-65S has 1" Non-CFC Insulation).
Water Connections— 3⁄4" NPT factory installed true dielectric fittings extend
I
water heater life and eases installation.
Factory Installed Heat Traps—Design incorporates a flexible disk that
I
reduces heat loss in piping and eliminates the potential for noise generation.
Protective Magnesium Anode Rod—Provides added protection against
I
corrosion for long trouble-free service.
Stainless Steel Flue Baffle—Maximizes the amount of heat absorbed by the
I
tank and reduces heat loss during standby periods.
Steel Tank—Heavy gauge steel automatically formed, rolled and welded.
I
T&P Relief Valve—Included.
I
Brass Drain Valve.
I
Design Certified by CSA International (formerly AGA and CGA).
I
3 or 5-Year Limited Tank Warranties / 1-Year Limited Warranty on Component Parts.
For more information on warranty, please visit www.bradfordwhite.com
For products installed in USA, Canada and Puerto Rico. Some states do not allow limitations on warranties. See complete
copy of the warranty included with the heater.
® are registered trademarks of Bradford White
® Total Performance System—Cold water inlet
Lining—Bradford White water heater tanks are protected from the
® Corporation.
® Models Feature:
SM .
755-B-0807-A
