Summary of Contents for Moretti Forni NEAPOLIS Series
- Page 1 Manuale di istruzioni Instructions manual Manuel d’instructions Bedienungsanleitung Manual instrucciones NEAPOLIS Forno elettrico Electric oven Four electrique Elektrische Ofen Horno Electrico Numeri di matricola / Serial numbers : Cod.73303170 Ver.: A01...
-
Page 2: Table Of Contents
INDEX TECHNICAL DATA INSTALLATION OPERATION ROUTINE MAINTENANCE SPECIAL MAINTENANCE SPARE PARTS CATALOGUE Note: This manual is printed in five different languages. Original instructions in Italian and translations of the original instructions in English, French, German and Spanish. For better clarity and reading this manual, it could be provided in several separate parts and can be sent by mail by contacting the Manufacturer. WARRANTY Standards and rules Warranty only covers the replacement free to factory of pieces eventually broken or damaged because of faulty materials or manufacture. -
Page 3: Technical Data
TECHNICAL SPECIFICATIONS 1.10 NOISE This appliance is a technical work tool and normally, the noise level DESCRIPTION OF THE APPLIANCE threshold at the operator station does not exceed 70 dB (A). The appliance comprises several units positioned one on top of the other: INSTALLATION - Baking chamber(s) complete with hood... - Page 4 2.5.2.1 ELECTRICAL CONNECTION OF THE BAKING WARNING! The appliance must be installed on a firm and CHAMBER levelled surface, perfectly leveled. The equipment must never come WARNING! For each baking element, it is necessary to fit into contact with flammable or combustible materials. a main four-pole switch with fuses or an automatic switch suitable NOTE: Position the oven in such a way that there are no...
-
Page 5: Operation
a) Turn the main switch (Fig. 12 item 1) on the central control panel WARNING! It is essential that the appliance be properly to ON. Both the switch itself and the electronic panel on the right earthed. will light up. A special earth terminal has been provided for this purpose on the The control unit allows you to use the oven in “MANUAL”... - Page 6 The use of the ceiling and floor heating elements, is highlighted by To turn the oven off, simply turn off the main switch (fig. 12 item a dot in the lower right corner of the display (figure 12 item 6) and (figure 12 item 8).
- Page 7 By pressing the Timer button for the third time it is possible to - Set the oven approximately between 430°C and 485°C with the return to the desired program. Ceiling set to 8 and Floor about to 3 and turn on the oven. Hold down the “P”...
-
Page 8: Routine Maintenance
c) To turn the leavening compartment off, turn the thermostat (item 3.7.5 STARTING THE TIMER FOR DAILY PROGRAMMED 3) back to zero. START-UP - To enable programmed start-up it is necessary to set the temperature WARNING! Avoid contact with the heating element required and the ceiling and floor values, then enter the start-up time (resistors) located inside the leavening compartment to avoid function (press the “Timer”... - Page 9 Every day, at the end of operations and after leaving the appliance to cool down, carefully remove from all parts of the oven, except from the biscuit-ware, any residues that might have collected during cooking, using a damp sponge or cloth and a little soapy water, if necessary. Rinse and dry the areas, being sure to wipe parts with satin finish in the direction of the finish.
-
Page 10: Special Maintenance
WARNING FOLLOWING INSTRUCTIONS, WHICH CONCERN “SPECIAL MAINTENANCE” ARE STRICTLY RESERVED TO SPECIALIST TECHNICIANS WITH THE RELEVANT LICENSE AS WELL AS BEING APPROVED BY THE MANUFACTURER. SPECIAL MAINTENANCE TOUCHED WITH BARE HANDS, BUT WITH GLOVES OR A CLOTH IN ORDER TO AVOID COMPROMISING ITS PRELIMINARY SAFETY OPERATIONS FUNCTIONALITY. -
Page 11: Spare Parts Catalogue
After carrying out the operations described in 5.1 for the - Unscrew the locking ringnut of the thermostat; replacement/removal of the surface, proceed as follows: - Open the compartment doors, remove the right tray holder guides, - Using a blade as leverage, lift and remove the 2 mouth biscuit-ware remove the bulb thermostat protection cover (figure 5A item N) and elements (fig.5 item I) remove the safety bulb thermostat from its seat (figure 5A item M)
