Bradford White LD-12UT3-1 Specification Sheet

Light Duty Commercial Utility
Energy Saver Electric Water Heater
Photo is of
LD-12UT3-1
Copper Screw Type Immersion Element
(Incoloy type immersion element available upon request)
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385; 5,574,822; 5,372,185; 5,485,879; 5,277,171;
(B1)5,341,770; 5,660,165; 5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448; 4,829,983; 4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968; 4,672,919; Re. 34,534;
7,270,087 B2. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS: 1,272,914; 1,280,043; 1,289,832; 2,045,862; 2,112,515; 2,108,186; 2,107,012; 2,092,105; 2,409,271.
Vitraglas ® is a registered trademark of Bradford White
The Light Duty Utility Electric Models Feature:
Fully Automatic Controls—Fast acting surface-mount thermostat for
I
automatic temperature control. Factory installed sensitive manual reset
energy cut-off for safety to prevent overheating. (Maximum thermostat
setting is 160°F.)
Direct Heat Transfer With a Single Immersed Element—Transfers heat
I
directly and efficiently to the water. Screw-in style element.
Vitraglas ® Lining—Bradford White water heater tanks are protected from
I
the corrosive effects of hot water by an exclusive ceramic porcelain-like
coating. The Bradford White high silica Vitraglas
interior surface for our hot water tanks.
1" Non-CFC Foam Insulation—Surrounds the tank surface, saving energy
I
by retarding loss of heat.
Water Connections—3/4" NPT factory installed true dielectric fittings
I
extend water heater life and eases installation. Located on the side for
easier installation.
Alternate Top Water Connections—The 6 and 12 gallon models have
I
alternate 3/4" water connection tappings on top.
Protective Magnesium Anode Rod—Provides added protection against
I
corrosion for long trouble-free service.
Steel Tank—Heavy gauge steel automatically formed, rolled and welded.
I
Voltages Available—120V, 208V, 240V, 277V, 480V.
I
Single Phase Operation Only.
I
T&P Relief Valve Installed—All models have special tapping on side
I
of tank.
3 or 5-Year Limited Tank Warranties / 1-Year Limited Warranty on Component Parts.
For more information on warranty, please visit www.bradfordwhite.com
For products installed in USA, Canada and Puerto Rico. Some states do not allow limitations on warranties.
See complete copy of the warranty included with the heater.
® Corporation.
® lining provides a tough
412-B-0408-A
