- Page 1 2021 Owner’s Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS • Important Safety Instructions Personal Safety Precautions Installation and Set-Up Instructions Electrical Requirements Wiring Installation (220v) GFCI Wiring Installation (220v) Electrical Specifications • Spa Startup Directions • Plug and Play Cord Location • Operation Instructions Topside Control Instructions Waterfall djustability LED Lighting Feature Spa Jets and ir Controls... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When installing and using this electrical equipment, basic safety precau- tions should always be followed, including the following: READ AND FOLLOW ALL INSTRUCTIONS WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. - Page 4 DANGER: Risk of Electric Shock. Do not permit any electrical appliance, such as a light, telephone, radio or television within 5 feet (1.5m) of a spa. WARNING: To Reduce the Risk of Injury: a) Before using your spa you should check the water temperature with a thermometer that is known to be accurate.
-
Page 5: Personal Safety Precautions
• Fetal injury in pregnant women • Physical inability to exit the spa or hot tub • Unconsciousness resulting in the potential of drowning WARNING: The use of alcohol, drugs or medication can greatly increase the risk of fatal hyperthermia. If you suspect hyperthermia, immediately get medical help, lay the victim on their back with the head slightly elevated for easier breathing, cover the body with a blanket and apply ice packs to the... -
Page 6: Installation And Set-Up Instructions
NOTE: Name badge on rub rail indicates equipment location 15 amp GFCI Rating Viking 1P 120v, Viking 2P 120v, urora P 120v, urora P+ 120v, Royale P 120v, Royale P+ 120v, Regal P 120v, Regal P+ 120v 50 amp GFCI Rating Viking 3, urora 3, Royale, Regal, Royale ETS, Regal ETS, Legacy 1 &... -
Page 7: Wiring Installation (220V)
220-VOLT WHITE BL CK GREEN* *Green ground connection located on left side of control panel. -
Page 8: Gfci Wiring Installation (220V)
GFCI WIRING INSTALLATION (220V) -
Page 9: Electrical Specifications
SPA STARTUP DIRECTIONS ll Viking Spas require a solid, flat surface.* This is to ensure that the spa cabinet is not exposed to a pressure stress condition that may result in cabinet damage and shell cracking. -
Page 10: Plug And Play Cord Location
POWER CORD ACCESS LOCATION Viking Spas has provided three access points located in the bottom corner to assist in running the electrical conduit to the power system. Simply remove the plug to access the opening. -
Page 11: Operation Instructions
TOPSIDE CONTROL OPERATION INSTRUCTIONS Use the Accompanying QR code for instructions that best matches the control panel on your spa Controller Installed on Viking 1, Viking 2, urora P, urora P+, Royale P, Royale P+, Regal P, Regal P+ USE QR on left or go to: http://www.vikingspas.com/ftp/tp500userguide.pdf Controller Installed on... -
Page 12: Waterfall Djustability
WATERFALL ADJUSTABILITY The urora P, urora P+and the urora 3 feature a Waterfall, which allows the user to regulate the flow of water to the jet by simply turn- ing the valve for the waterfall from “off” to “on”. (See illustration below) LED LIGHTING FEATURE The urora P+, Royale P+, Regal P+, Viking 3, urora 3, Royale,... -
Page 13: Spa Jets And Ir Controls
SPA JETS AND AIR CONTROLS SPA JETS djustable Spa Jets may be turned off and on by rotating jet faceplate left or right. Note DO NOT TURN LL SP JETS OFF T THE S ME TIME. THIS M Y C USE D M GE TO THE PUMP ND MOTOR. - Page 14 TURBO/WHIRLPOO JET (Viking 2P & 3 only) VOLCANO Jet (Heritage & Tradition only) The Turbo jet is located on the filter cavity wall is the Turbo jet. This jet is a combination valve and high capacity jet. To turn the Turbo jet on, simply turn the face counter-clockwise to the first stop position.
-
Page 15: Vibrosonic Jet Operation
STEREO INFORMATION If your spa is equiped with a bluetooth stereo you will find the operating instructions in the warranty package. VIBROSONIC JET SYSTEM If your spa is equiped with a Vibrosonic system you will find the operat- ing instructions in the warranty package. FILL THE SPA WITH WATER a. -
Page 16: Skimmer Side Filter
SKIMMER SIDE FILTER ll Viking spas have a skimmer side filter that does not require “air bleeding” on initial startup. If an air lock develops, loosen the union on return side of pump. See Diagram ( ) below. Let small amount of water drain from connection while the pump is running. -
Page 17: Maintenance
MAINTENANCE SPA DRAINING Every 90 days, depending upon water condition, you may need to renew the spa water. To drain your spa, power must be disconnected at the circuit breaker. Locate the drain faucet inside the spa cabinet (for Viking IP, 2P & 3 models) or on the corner near the bottom of the side panel next to the equipment (for all other models). -
Page 18: Spa Surface Care
SPA SURFACE CARE Do not use abrasive solvents or cleaners to clean spa surfaces. Only use the following: Lemon Juice, Amonia, Vinegar or Soap and Water. LONG-TERM STORAGE (90 days or more) We strongly urge you to contact your dealer to winterize your spa. -
Page 19: Filter Cleaning
• lways leave the cover open for 15 minutes every 30 days to prevent off gas from damaging your spa pillows, cover and other critical compo- nents. Signs of off gas damage include but are not limited to pillow peel- ing and bubbling, discoloration, cover failing prematurely, plastics or jet inserts failing. - Page 20 FILTER CLEANING (ALL SPAS except Viking 1P, Viking 2P & Viking 3) Remove filter face cover by pulling straight up and slightly toward the spa on front plate/face cover. ( s shown below.) Remove access bas- ket and unscrew filter cartridge(s) from housing. To reinstall weir door assembly, door must be placed through throat of skimmer prior to slid- ing assembly into place.
-
Page 21: Spa Cabinet & Cover Maintenance
SPA CABINET MAINTENANCE Your Viking spa cabinet is designed to be maintenance free. However, if dirt or grime should appear simply use a mild soap solution and clean with a rag. SPA COVER MAINTENANCE Please refer to the cover manufacturer’s care and maintenance form included in the cover box. -
Page 22: Spa Situations & Solutions
SPA SITUATIONS & SOLUTIONS Situation Cause or Result Product to use Solution Calcium deposits Hard water Stain n Scale dd 1oz. of Stain n Scale on surfaces of heater, fittings pH/total alkalinity pH Up Test water - adjust with or plumbing out of adjustment pH Down pH Up or pH Down. -
Page 23: Trouble Shooting
TROUBLE SHOOTING Caution: Viking Spas have slide type water shut off valves referred to as Gate Valves. The spa should never be operated with the Gate Valves in the closed position, as this will cause severe damage to the pump and/or heater. - Page 24 “Warning: Children should not use spas or hot tubs without adult supervision” and “ vertissement: Ne pas laisser les enfants utiliser une cuve de relaxation sans surveillance” “Warning: Do not use spas or hot tubs unless all suction guards are installed to prevent body and hair entrapment”...
- Page 25 2725 Prairie St. SW • Wyoming MI 49519 www.vikingspas.com • Email: info@vikingspas.com © 2020 Viking Spas, Inc...
