Samsung LE32R82B Owner's Instructions Manual
  1. Manuals
  2. Brands
  3. Samsung Manuals
  4. LCD TV
  5. LE32R82B
  6. Owner's instructions manual

Samsung LE32R82B Owner's Instructions Manual

On-screen menus pc display picture in picture (pip) teletext
Hide thumbs Also See for LE32R82B:
Table of Contents

Advertisement

Quick Links

Contact SAMSUNG WORLD-WIDE
If you have any questions or comments relating to Samsung products,
please contact the SAMSUNG customer care centre.
Country
Customer Care Centre
REPUBLIC OF IRELAND
0818 717 100
U.K
0870 SAMSUNG (7267864)
Web Site
www.samsung.com/uk
www.samsung.com/uk
BN68-01166E-01
Owner's Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
PC DISPLAY
PICTURE IN PICTURE (PIP)
TELETEXT
Register your product at www.samsung.com/global/register
Record your Model and Serial number here for future reference.
▪ Model _______________ ▪ Serial No. _______________
LCD TV
LE32R8
LE37R8
LE40R8

Advertisement

Table of Contents
loading

Related Manuals for Samsung LE32R82B

Summary of Contents for Samsung LE32R82B

  • Page 1 Contact SAMSUNG WORLD-WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Customer Care Centre REPUBLIC OF IRELAND 0818 717 100 0870 SAMSUNG (7267864) Web Site www.samsung.com/uk www.samsung.com/uk BN68-01166E-01 LE32R8...
  • Page 2 IMPORTANT: Image retention issues are not covered by your Samsung® warranty. • Do not display a still image on the LCD panel for more than 2 hours as it can cause screen image retention.

  • Page 3: Table Of Contents

    Contents CONNeCTING AND PRePARING YOuR TV List of Parts ...2  Installing the Stand ...2  Installing the Wall Mount Kit ...2  Viewing the Control Panel ...3  Viewing the Connection Panel ...4  Viewing the Remote Control ...6 ...

  • Page 4: List Of Parts

    Wall Mount items. Contact a technician for assistance when installing the wall mounted bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own.

  • Page 5: Viewing The Control Panel

    Viewing the Control Panel [LE32R81, LE37R81, LE40R81, LE32R83, LE37R83, LE40R83] [LE32R82, LE37R82, LE40R82, LE32R84, LE37R84, LE40R84] The product colour and shape may vary depending on the model. 1 SOuRCe Toggles between all the available input sources (TV, Ext.1, Ext.2, AV, S-Video, Component, PC, HDMI1, HDMI2, HDMI3).

  • Page 6: Viewing The Connection Panel

    Viewing the Connection Panel The product colour and shape may vary depending on the model. Whenever you connect an external device to your TV, make sure that power on the unit is turned off. When connecting an external device, match the colour of the connection terminal to the cable. 1 Connecting Set-Top box, VCR or DVD Connector Video...

  • Page 7: Kensington Lock

    4 Connecting an Aerial or Cable Television Network To view television channels correctly, a signal must be received by the set from one of the following sources: - An outdoor aerial / A cable television network / A satellite network 6 Connecting external A/V Devices - Connect RCA or S-VIDEO cable to an appropriate external A/V device such as VCR, DVD or Camcorder.

  • Page 8: Viewing The Remote Control

    Viewing the Remote Control 1 Selects a target device to be controlled by the Samsung remote control (TV, DVD, STB, CABLE, VCR) (Refer to page 34~36) 2 Television Standby button 3 Number buttons for direct channel access 4 One/Two-digit channel selection 5 It display "Channel List"...

  • Page 9: Installing Batteries In The Remote Control

    Installing batteries in the Remote Control 1. Lift the cover at the back of the remote control upward as shown in the figure. . Install two AAA size batteries. Make sure to match the "+" and "–" ends of the batteries with the diagram inside the compartment.

  • Page 10: Plug & Play

    Plug & Play When the TV is initially powered on, several basic settings proceed automatically and subsequently. The following settings are available. 1. Press the POWeR button on the remote control. The message "Start Plug & Play" is displayed with "OK" selected.

  • Page 11: Storing Channels Automatically

    If you want to reset this feature... 1. Press the MeNu button to display the menu. Press the ▲ or ▼ button to select "Setup", then press the eNTeR/OK button. . Press the eNTeR/OK button again, to select "Plug & Play". 3.

  • Page 12: Storing Channels Manually

    Storing Channels Manually You can store up to 100 channels, including those received via cable networks. When storing channels manually, you can choose: Whether or not to store each of the channels found. The programme number of each stored channel which you wish to identify. 1.

  • Page 13: Setting The Channel Lists

    Setting the Channel lists Set the channels according to your preference. You can easily delete, add, or lock the channel you want. 1. Press the MeNu button to display the menu. Press the ▲ or ▼ button to select "Channel", then press the eNTeR/OK button.

  • Page 14: Sorting The Stored Channels

    Sorting the Stored Channels You can exchange the numbers of two channels, in order to:  Modify the numeric order in which the channels have been automatically stored.  Give easily remembered numbers to the channels that you watch most often. 1. Press the MeNu button to display the menu. Press the ▲ or ▼ button to select "Channel", then press the eNTeR/OK button.

  • Page 15: Fine Tuning Channel Reception

    Fine Tuning Channel Reception use fine tuning to manually adjust a particular channel for optimal reception. 1. Use the number buttons to directly select the channel that you want to fine tune. . Press the MeNu button to display the menu. Press the ▲...

  • Page 16: Adjusting The Custom Picture

    Adjusting the Custom Picture Your set has several settings which allow you to control picture quality. 1. To select the desired picture effect, follow the "Changing the Picture Standard" instructions number 1 to 3. . Press the ▲ or ▼ button to select a particular item. Press the eNTeR/OK button.

  • Page 17: Activating Backlight

    Activating backlight You can adjust the screen brightness by adjusting the lCD backlight brightness. (0~10) 1. To select the desired picture effect, follow the "Changing the Picture Standard" instructions number 1 to 3. (On page 13) . Press the ▲ or ▼ button to select “Backlight”, then press the eNTeR/OK button.

  • Page 18: Configuring Detailed Settings On The Picture

    Configuring Detailed Settings on the Picture You can set detailed picture settings. 1. Press the MeNu button to display the menu. . Press the eNTeR/OK button, to select "Picture". 3. Press the ▲ or ▼ button to select "Detailed Settings", then press the eNTeR/OK button.

  • Page 19: Changing The Picture Size

    Changing the Picture Size You can select the picture size which best corresponds to your viewing requirements. 1. Press the MeNu button to display the menu. Press the eNTeR/OK button, to select "Picture". . Press the ▲ or ▼ button to select "Size", then press the eNTeR/OK button.

  • Page 20: Freezing The Current Picture

    Freezing the Current Picture Press the STILL button to freeze a moving picture into a still one. Press again to cancel. Selecting the Screen Mode When setting the picture size to Auto Wide in a 16:9 wide TV, you can determine the picture size you want to see the 4:3 WSS (Wide Screen Service) image or nothing.

  • Page 21: Digital Nr / Active Colour / Dnie / Movie Plus

    Digital NR / Active Colour / DNIe / Movie Plus If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction feature to help reduce any static and ghosting that may appear on the screen. 1.

  • Page 22: Viewing The Picture In Picture (Pip)

    Viewing the Picture In Picture (PIP) You can display a sub picture within the main picture of set programme or video input. In this way, you can watch the picture of set programme or video input from any connected equipment while watching the main picture. 1.

  • Page 23: Hdmi Black Level

    HDMI Black Level You can directly select the black level on the screen to adjust the screen depth. 1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select "Setup", then press the ENTER/OK button. 2. Press the ▲ or ▼ button to select "HDMI Black Level", then press the ENTER/OK button. 3. Press the ▲ or ▼ button to select "Normal" or "Low", then press the ENTER/OK button. 4. Press the EXIT button to exit. This Function is active only when the externel input connects HDMI(RGB siginal).  Normal: The screen gets brighter.  Low: The screen gets darker. Changing the Sound Standard You can select the type of the special sound effect to be used when watching a given broadcast.

  • Page 24: Adjusting The Sound Settings

    Adjusting the Sound Settings The sound settings can be adjusted to suit your personal preferences. 1. Press the MeNu button to display the menu. Press the ▲ or ▼ button to select "Sound", then press the eNTeR/OK button. . Press the ▲ or ▼ button to select "Equalizer", then press the eNTeR/OK button.

  • Page 25: Connecting Headphones

    Connecting headphones You can connect a set of headphones to your set if you wish to watch a TV programme without disturbing the other people in the room. When you insert the head set jack into the corresponding port, you can operate only "SRS TS XT"...

  • Page 26: Selecting The Internal Mute

    Selecting the Internal Mute If you want to hear the sound through separate speakers, cancel the internal amplifier. 1. Press the MeNu button to display the menu. Press the ▲ or ▼ button to select "Sound", then press the eNTeR/OK button. .

  • Page 27: Resetting The Sound Settings To The Factory Defaults

    Resetting the Sound Settings to the Factory Defaults If Game Mode is On, the Reset Sound function is activated. Selecting the Reset function after setting the equalizer resets the equalizer setting to the factory defaults. 1. Press the MeNu button to display the menu. Press the ▲...

  • Page 28: Setting The Sleep Timer

    Setting the Sleep Timer You can select a time period of between 30 and 10 minutes after which the television automatically switches to standby mode. 1. Press the MeNu button to display the menu. Press the ▲ or ▼ button to select "Setup", then press the eNTeR/OK button.

  • Page 29: Choosing Your Language

    Choosing Your language When you start using your set for the first time, you must select the language which will be used for displaying menus and indications. 1. Press the MeNu button to display the on-screen menu. Press the ▲ or ▼ button to select "Setup", then press the eNTeR/OK button.

  • Page 30: Setting The Blue Screen Mode / Selecting The Melody

    Setting the blue Screen Mode / Selecting the Melody blue Screen: If no signal is being received or the signal is very weak, a blue screen automatically replaces the noisy picture back- ground. If you wish to continue viewing the poor picture, you must set the "blue Screen"...

  • Page 31: Setting The Light Effect

    Setting the light effect You can turn on/off the blue leD on the front of TV according to the situation. use it for saving power or when the leD dazzles your eyes. 1. Press the MeNu button to display the on-screen menu. Press the ▲...

  • Page 32: Selecting The Source

    Selecting the Source You can select among external sources connected to your TV’s input jacks. 1. Press the MeNu button to display the menu. Press the ▲ or ▼ button to select "Input", then press the eNTeR/OK button. . Press the eNTeR/OK button again, to select "Source List". When no external device is connected to your set, only "TV", "Ext.1", "Ext.2"...

  • Page 33: Teletext Decoder

    Teletext Decoder Most set channels carry " teletext ", pages of written information that provide information such as: Television programme times. News bulletins and Weather forecasts. Sports results. Subtitles for the hard of hearing. The teletext pages are organized according to six categories: Contents Part Selected page number.

  • Page 34: Displaying The Teletext Information

    Displaying the Teletext Information You can display teletext information at any time, but signal reception must be good. Otherwise: Information may be missing. Some pages may not be displayed. To activate the teletext mode and display the contents page: 1. Using the P ) or P the teletext service.

  • Page 35: Using Fastext To Select A Teletext Page

    using Fastext to Select a Teletext Page The various topics included in the teletext pages are colour-coded, and can be selected by pressing the coloured buttons on the remote control. 1. Display the teletext contents page by pressing the TexT/MIx ( button.

  • Page 36: Remote Control Codes

    Remote Control Codes brand Code SAMSUNG 000 001 002 003 004 005 077 078 079 ADMIRAL AIWA AKAI 004 027 032 AUDIO DYNAMICS 007 026 BELL&HOWELL BROKSONIC CANDLE 002 003 006 008 015 055 CANON 021 056 CITIZEN 002 003 006 008 015 055...

  • Page 37: Cable Box

    019 023 028 PANASONIC 003 022 027 037 044 PHILIPS 019 021 023 028 PIONEER 004 018 020 044 014 022 040 REGAL SAMSuNG DVD Product Code 000 001 002 DVDR 003 004 BD Record 005 006 VCR COMBO 007 008 009 010 011...
  • Page 38 026 029 126 127 128 129 130 141 SHERWOOD 039 041 SYLVANIA 043 093 SHARP SANSUI SANYO 062 090 SHINSONIC SAMSuNG SeT-TOP bOx Product Ground wave STB Satellite STB CABLE STB STB DVD COMBO Satellite STB HDD COMBO Standard SeT-TOP bOx brand Code...

  • Page 39: Setting Up Your Pc Software (Based On Windows Xp)

    Windows and your particular video card. even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) 1. First, click on "Control Panel" on the Windows start menu.

  • Page 40: Setting The Pc

    Setting the PC Coarse and Fine Tuning of the Image (Image lock): The purpose of picture quality adjustment is to remove or reduce picture noise. If the noise is not removed by Fine-tuning alone, then adjust the frequency as best as possible (coarse) and Fine-tune again.

  • Page 41: Wall-Mount Adjustment (Le40R8) (Sold Separately)

    Wall-Mount Adjustment (le0R) Once the wall mount is installed, the position of your TV can be easily adjustable. 1. Press the MeNu button to display the menu. Press the ▲ or ▼ button to select “Setup”, then press the eNTeR/OK button. .

  • Page 42: What Is Anynet

    What is Anynet + ? Anynet+ is an AV network system that enables an easy-to-use AV interface for users by controlling all connected AV devices through the Anynet+ menu when Samsung Electronics AV devices are connected. Connecting Anynet + Devices The Anynet+ system supports AV devices supporting Anynet+ only.

  • Page 43: Setting Up Anynet

    Setting up Anynet + The following settings are to use Anynet+ functions. using the Anynet+ Function 1. Press the Anynet+ button. Press the ▲ or ▼ button to select Setup, then press the eNTeR/OK button. . Press the eNTeR/OK button to select Anynet+ (hDMI-CeC), then press the eNTeR/OK button.

  • Page 44: Recording

    Anynet+ Menu The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the TV. Anynet+ Menu View TV Select Device Record Menu on Device Device Operation Receiver Setup TV Remote Control buttons Available in Anynet+ Mode Device Type Anynet+ Device Device with built-in Tuner...

  • Page 45: Listening Through A Receiver

    Listening through a Receiver You can listen to sound through a receiver instead of the TV speaker. 1. Press the Anynet+ button. Press the ▲ or ▼ button to select Receiver, then press the ENTER/OK button. 2. Press the ◄ or ► button to select to On, then press the ENTER/OK button.

  • Page 46: Using The Anti-Theft Kensington Lock

    using the Anti-Theft Kensington lock The Kensington lock is a device used to physically fix the system when using it in a public place. The locking device has to be purchased separately. The appearance and locking method may dif- fer from the illustration depending on the manufacturer. Please refer to the manual provided with the Kensington lock for proper use.

  • Page 47: Technical And Environmental Specifications

    Technical and Environmental Specifications Model Name Screen Size (Diagonal) Power Consumption 1360 x 768 @ 60 Hz PC Resolution Sound Output Dimension (WxDxh) 874 x 81 x 531 mm Body 874 x 291 x 577 mm With stand Weight With stand environmental Considerations 10 °C to 40 °C (50 °F to 104 °F) Operating Temperature...
  • Page 48 Warning! Important Safety Instructions Please read the appropriate section that corresponds to the marking on your Samsung product before attempting to install the product. CAuTION RISK OF eleCTRIC ShOCK DO NOT OPeN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

  • Page 49: Warranty Card

    LETTER E OR BY THE EARTH SYMBOL Warranty Card This Samsung product is warranted for a period of twelve (12) months from the original date of purchase, against defective materials and workmanship. In the event that warranty service is required, you should return the product to the retailer from whom it was purchased.
  • Page 50 This page is intentionally left blank.
